Sennheiser K 6 P Datasheet

K6P
Microphones |
General Description
The K6P powering module is at the heart of Sennheiser's professional
modular condenser microphone system. It is similar to the K6 powering
module but is powered by 12 – 48 V phantom power only, for use where
battery power is not required (e.g. permanent installations). The K6P can
be combined with various microphone heads to produce microphones
with a variety of pick-up patterns. Matt black, anodised, scratch-resis-
tant finish.
Cable pictured is an accessory not supplied with the powering module
Features
Switchable bass roll-off filter protects against rumble, handling,
pop and wind noise
On/off switch
High output, low noise
Transformerless balanced output on 3-pin XLR connector
Delivery includes: 1 K6P powering module
1 MZQ 200 microphone clamp
1 protective carrying case
Recommended Accessories
ME 62 microphone head, omni-directional
ME 64 microphone head, cardioid
ME 65 microphone head, super-cardioid
ME 66 microphone head, short gun
ME 67 microphone head, long gun
MKE 2-60 Gold-C clip-on microphone, omni-directional
ME 102/104/105 mini-modular system
MZS 6 shock mount
MZQ 6 quick release clamp
Product Variants
K6P-C: as K6P, but without accessories
Powering Module
Cat. No. 003281
Cat. No. 003282
Cat. No. 003283
Cat. No. 003284
Cat. No. 003285
Cat. No. 004733
Cat. No. 003287
Cat. No. 003288
Cat. No. 003862
Technical Data
Frequency response ..................................... 30 – 20,000 Hz - 1 dB
Transmission factor (1 kHz).......................................................0 dB
Nominal impedance ................................................................. 200 Ω
Min. terminating impedance ..................................................... 1 kΩ
Max. output voltage................................................... 2 V (at 1 kHz)
Power supply ........................................ phantom 12 - 48 V (± 4 V)
Supply current..........................................................................2.2 mA
Dimensions in mm............................................................ 118 x Ø 22
Resultant length in mm* .............................................................. 52
Weight ............................................................................. approx. 30 g
* Resultant length: this is the figure you need to add to the microphone head
length to give the overall length of the complete microphone.
Profile
Powering module for phantom powering with switchable roll-
off filter, suitable for ME 62 – ME 67 microphone heads and
-60 versions of MKE microphones, transmission factor 0 dB at
1 kHz, nominal impedance 200 Ω, min. terminating impedance
1 kΩ, max. output voltage 2 V (at 1 kHz), phantom powering
12 V – 48 V, supply current 2.2 mA, dimensions: Ø 22 x 118 mm,
resultant length 52 mm, weight approx. 30 g.
Cat. No. 003280
