Summary of Contents for Mopec BF100
- Page 1 USER MANUAL BF100 Ventilated Formalin Cube Station Rev 4-19-17 © www.mopec.com...
- Page 2 P a g e...
-
Page 3: Table Of Contents
TABLE OF CONTENTS UNPACKAGING YOUR PRODUCT..…………………………………………….……4 INSTALLATION………..…………………………………………………………….…..5 INTRODUCTION ………………………………………………………………………..7 FEATURES………………………………………………………………………………8 AIR HANDLING………………………………………………………………………….9 CLEANING AND MAINTENANCE Disinfecting and Cleaning………………………………..…………………..10 Filter information and evaluation…………………………………..……….11 Stainless Steel Care and Maintenance…………………………………..12 Parts…………………………………………………………………………..….14 Preventive Maintenance………………………………………………..…….15 WARRANTY………………………………………………………………………..…….16 SAFETY LABELS………………………………………………………………..………17 TROUBLE SHOOTING GUIDE……………………………………………………..….18 P a g e... -
Page 4: Unpackaging Your Product
Have the delivery driver note any suspected damage on the Bill of Lading and sign it. Mopec will help assist in filing a claim for product repair and/or replacement. -
Page 5: Installation
INSTALLATION 1. Place on counter. 2. Unsnap straps. This will allow drip shelf to hang down. When not in use, fold up and snap back in place to securely hold shelf. 3. Place pad on drip shelf. Place pad here P a g e... - Page 6 4. Plug unit into 110V wall socket (requires 3 amp power). 5. On/off switch is located on backside of unit 6. Insert BF005 Potassium Permanganate Filter where shown. Place the fiber filter on the bottom and the potassium permanganate filter on top of the fiber filter 7.
-
Page 7: Introduction
INTRODUCTION The BF100 is a ventilated gravity fed formalin dispensing system that holds one five gallon cube of formalin. It is a self-contained recirculation unit. A high speed fan pulls the formalin fumes away from the user. Two filters catch particles and formalin fumes. The BF100 includes an audio and visual alarm to notify the user of a leak or spill. -
Page 8: Features
FEATURES Designed to safely evacuate fumes while filling containers • Recirculating Filtration System with Pull-Out Filter Drawer contains: 1 BF005 - Potassium Permanganate Filter 1 BF003 - Particle Filter 1 BF101 Formalin Neutralization Pad • Drip and Spill Containment in Hinged Pan can hold a spill up to 1.6 gallon. Includes a formalin absorbing •... -
Page 9: Air Handling
BF100 Ventilated Formalin Cube Station Design Parameters: The BF100 is designed with the basis of fulfilling one goal and that is to adequately ventilate the work area. An adverse effect of ventilation is noise that has been considered but does not govern the ultimate design criteria. -
Page 10: Cleaning And Maintenance
CLEANING AND MAINTENANCE DISINFECTING STAINLESS STEEL SURFACES All stainless steel surfaces can be cleaned with soap and water, which will remove debris. The stainless steel surfaces can be disinfected with a non caustic disinfectant. We suggest using BE045 Path Cloud or BE047 Bench Wipe for cleaning purposes. -
Page 11: Filter Information And Evaluation
EVALUATING FILTERS FOR REPLACEMENT The filters in your MB unit contain alumina pellets impregnated with potassium permanganate, KMnO , which is a fast oxidizer. Formaldehyde passing through the filter is converted to carbon dioxide and water. The filter’s life depends entirely on the amount of formaldehyde fumes passing through the filter. The pellets are bright purple when new and become dark brown when spent. -
Page 12: Stainless Steel Care And Maintenance
3) Rinse the surface after using disinfectant. In Pathology and other medical areas the act of disinfecting is desired. There are a number of ways to do this including using Mopec’s Bench Spray & Wipe Disinfectant. Labs use any number of different products including 10% bleach or other disinfectant sprays and wipes. For the most part, each and every one of these has high salt contents and lower PH levels to aid with disinfection. - Page 13 Conclusions & Suggestions We are confident and can assure you that if you institute the suggestions detailed above that your Mopec Grossing station will look as it did the day it arrived. Do not assume it's the cleaner. If you do have some spotting or staining, and you've followed all of the suggestions, it may not be the cleaner.
-
Page 14: Parts
USER PARTS Replacement parts are available from Mopec The can be ordered by contacting Mopec at 800-362-8491. BF005 Potassium Permanganate Filter BF003 Particle Filter BF101 Formalin Neutralization Pad (3 Pack) P a g e | 14... -
Page 15: Preventive Maintenance
PREVENTITIVE MAINTENANCE CHECKS Procedure: 1. Visually check the exterior of equipment for any signs of damage. 2. Visually check the condition of the power cord and plug(s) for cracks, cuts, bare or broken wires and signs of excessive heat (discoloration). 3. -
Page 16: Warranty
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. To the extent that Mopec is acting as a supplier of Products manufactured by a third party, the Products will be warranted only to the extent that they are warranted by their manufacturers and Buyer (or its customer) agrees to look solely to the Product manufacturer for all warranty claims. -
Page 17: Safety Labels
SAFETY LABELS BEFORE SERVICING THE UNIT LOOK FOR AND HEED THE FOLLOWING LABEL P a g e | 17... -
Page 18: Trouble Shooting Guide
TROUBLE SHOOTING Problem Possible Solution My Unit does not turn on Assure your facility circuit breaker has not been tripped. I detect the odor of Formalin Have the filters been checked/changed recently Check Filter for saturation Replace Filter Check the Spill Pad for formalin/Replace pad P a g e | 18... - Page 19 2015 Mopec all rights reserved P a g e | 19...
