Sennheiser MZH 3015 Quick Manual

MZH 3015
MZH 3040
FEATURES
Sturdy and elegant metal gooseneck for
unobtrusive miking
RF shielding against intermodulation
from wireless equipment/devices
ARCHITECT'S

SPECIFICATIONS

The unit shall be streamlined in
appearance, with a boom diameter of 8
mm (.31") and an overall length of 15 cm
(5.9") and 40 cm (15.75"). It must also
be finished with a durable anti-reflective
matte black coating and have a pre-amp
housed with its XLR-3 connector housing.
The unit must be mountable using a table
stand, direct to surface receptacle or via
a silent shock mount system. The unit
shall accept the ME34, ME35 and ME36
microphone capsules. The unit shall be a
Sennheiser MZH 3015. The unit shall be a
MZH 3040.
Installed sound goosenecks
The MZH 3015 and MZH 3040
metal goosenecks for use with the ME 34, ME 35 and ME 36
microphone capsules. The rugged, matte black goosenecks
are fitted with a balanced, floating XLR-3 output, enabling the
microphone to be powered from 12 – 48 V phantom power.

TECHNICAL DATA

Connection ............................................................ XLR 3
Phantom Powering .............................................. P 12 - P48 V
Coating ................................................................... matte black
Diameter ................................................................ 6 mm (0.24")
Length .................................................................... 150 mm (5.91")
Number of flexible elements ............................. 1
Weight (goosenecks) .......................................... 73 g (23 oz.)
Delivery includes ................................................. MZH 3015
are sturdy and elegant
400 mm (15.75")
120 g (38 oz.)
MZH 3040
