Broadcast
HME 26(4)
Instruction manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HME 26-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sennheiser HME 26-4

Summary of Contents for Sennheiser HME 26-4

  • Page 1 Broadcast HME 26(4) Instruction manual...

  • Page 2: Safety Instructions

    Contact your Sennheiser agent or the Sennheiser Service Department. • Only replace those parts of the product whose replacement is described in this manual. All other parts must be replaced by your Sennheiser agent. • Protect the product from wetness. Use only a slightly damp cloth for cleaning.

  • Page 3: Delivery Includes

    • using the product within the operating conditions as described in this instruction manual. Improper use means using the headset other than as described in this instruction manual, or under operating conditions which differ from those described herein. Delivery includes...
  • Page 4 105 dB • “Flip-away” headphone allows single-sided listening • Detailed, linear sound reproduction for demanding applications • Flexible microphone boom, can be worn on either left or right-hand side • Noise-compensating pre-polarized condenser microphone ensures excellent speech transmission • Single-sided cable •...
  • Page 5 Operation Turning the microphone boom The microphone boom can be rotated by 180°. This allows the headset to be worn with the microphone boom positioned on either the left or right-hand side of the head. Switching the microphone transmission off If, during turning, the microphone boom is in the middle position (90°), the microphone transmission will be switched off in order...
  • Page 6 Positioning the microphone Bend the flexible microphone boom so that the microphone is placed at the corner of the mouth. Maintain a distance of approx. 2 cm between microphone and mouth. Always use the supplied wind and pop screen.
  • Page 7 Do not position the microphone directly in front of your mouth as it will pick up your breathing and plosive noises from your mouth. In addition, moisture can adversely affect the sound and performance of your microphone. When attaching sound...
  • Page 8 Switching ActiveGard™ on and off ActiveGard™ safeguards your ears from volume peaks above 105 dB, which can be transmitted via the audio system or radio equipment. ActiveGard™ is factory-preset to “on”. You can switch ActiveGard™ off by gently sliding the switch to the upper...

  • Page 9: Care And Maintenance

    Cleaning the headset Use a soft, slightly damp cloth to clean the headset from time to time. If the headset is very dirty, use a cloth dampened with mild, soapy water. Do not use any solvents or cleansing agents.
  • Page 10 Cleaning the sound inlet basket Carefully pull the sound inlet basket from the capsule. Moisten a small brush (bristle brush or toothbrush) with isopropyl alcohol. Carefully brush off the sound inlet basket. Allow the sound inlet basket to air dry for approx. 1 hour...
  • Page 11 529766 leatherette, 1 pair 529767 leatherette, 100 pairs 532724 velour, 1 pair HZH 26 hygiene pads 502595 white, 200 items 504062 black, 200 items By changing the cable, you can simply retrofit your headset (see “Product variants” on page 12).
  • Page 12 Carry bags 077408 Carry bag Wind and pop screens for BKE 4-4 535803 small (indoor use) 1 item 530895 small (indoor use) any quantity 535804 large (outdoor use) 1 item 534729 large (outdoor use) any quantity Cable clips 044740 MZQ 2002...

  • Page 13: Screen

    Product variants Variant (Cat. No.) (Part Number) Description 100 Ω per system, HME 26-100(4) (504203) condenser microphone, (026-BC) cardioid 600 Ω per system, HME 26-600(4) (504204) condenser microphone, (026-GC) cardioid Cable and connector assignment System connector Audio Hi left Audio Hi right...

  • Page 14: Solder Side

    Cable -7 (steel wire cable) yellow Audio Hi left Audio Hi right gray Audio Lo left blue Audio Lo right Microphone Hi blue Microphone Lo Screen Screen Cable -H-6 white Audio Hi left orange Audio Hi right brown Audio Lo left...

  • Page 15: Table Of Contents

    1 2 3 Solder side Solder side Ground/screen Audio Hi left Microphone Hi/48 VDC Audio Hi right Microphone Lo/48 VDC Audio Lo Together with the cable -X3K1-P48, the HME 26 is designed for P48 phantom powering as per DIN 45596.
  • Page 16 300 Ω mono/600 Ω stereo HME 26-600(4) 50 Ω mono/100 Ω stereo HME 26-100(4) Characteristic SPL 105 dB SPL at 1 kHz, 1 mW HME 26-600(4) 107 dB SPL at 1 kHz, 1 V HME 26-100(4) 115 dB SPL at 1 kHz, 1 V (ActiveGard switched off) Max.
  • Page 17 4 mV/Pa ± 2.5 dB Output voltage Terminating impedance min. 4.7 kΩ Supply voltage 5 to 15 V DC General data Ambient temperature operation: –15 °C to 55 °C storage: –55 °C to 70 °C Weight without cable approx. 200 g...

  • Page 18: Manufacturer Declarations

    Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner. In compliance with • RoHS Directive (2002/95/EC) CE Declaration of Conformity •...
  • Page 19 Sennheiser electronic GmbH & Co. KG Printed in Germany Am Labor 1, 30900 Wedemark, Germany Publ. 07/09...
