Allgemeines Gebrauchsanweisung lesen und aufbewahren Diese Gebrauchsanweisung gehört zum Ehrenkind Doppelbett/Familienbett. Sie enthält wichtige Informationen zur Inbetriebnahme und Handhabung. Lies die Gebrauchs- anweisung, insbesondere die Sicherheitshinweise, sorgfältig durch, bevor du den Ehrenkind Doppelbett/Familienbett einsetzt. Die Nichtbeachtung dieser Gebrauchs- anweisung kann zu schweren Verletzungen oder zu Schäden am Produkt führen. Die Gebrauchsanweisung basiert auf den in der Europäischen Union und im Vereinigten...
Page 5
Dieses Symbol gibt dir nützliche Zusatzinformationen zum Zusammenbau oder zum Betrieb. Konformitätserklärung (siehe Kapitel „Konformitätserklärung“): Mit diesem Symbol gekennzeichnete Produkte erfüllen alle anzuwendenden Gemein- schaftsvorschriften des Europäischen Wirtschaftsraums.
Sicherheit Bestimmungsgemäßer Gebrauch Das Doppelbett/Familienbett ist ausschließlich zur Nutzung als Bett und im Innen- bereich bestimmt. Es ist ausschließlich für den Hausgebrauch bestimmt und nicht für den gewerblichen Bereich geeignet. Verwende das Doppelbett/Familienbett nur wie in dieser Gebrauchsanweisung beschrieben. Jede andere Verwendung gilt als nicht bestimmungsgemäß...
Sicherheitshinweise WARNUNG! Verletzungsgefahr! Unsachgemäßer Umgang mit dem Produkt kann zu ernsten Verletzungen führen. • Achte darauf, dass das Doppelbett/Familienbett nur bestimmungsgemäß eingesetzt und nicht zweckentfremdet wird. • Das Doppelbett/Familienbett darf nicht nass werden. Reinige es nach den unten- stehenden Reinigungshinweisen. •...
Montagehinweise WARNUNG! Verletzungsgefahr! • Beachte, dass das Doppelbett/Familienbett erst nach der vollständiger Montage genutzt werden kann. • Beachte, dass das Montagezubehör-Set teilweise aus Kleinteilen besteht, die von Kindern verschluckt werden können. Dies kann zum Ersticken führen. Kinder dürfen niemals mit den Einzelteilen spielen. •...
Reinigung Reinige vor der erstmaligen Benutzung alle Teile des Ehrenkind Doppelbett/Familien- betts. HINWEIS Beschädigungsgefahr! Unsachgemäßer Umgang mit dem Produkt kann zu Beschädigungen führen. • Verwende keine aggressiven Reinigungsmittel, Bürsten mit Metall- oder Nylon- borsten sowie scharfe oder metallische Reinigungsgegenstände wie Messer, harte Spachtel und dergleichen.
+5° C und +20° C (Zimmertemperatur). Technische Daten Doppelbett | Kiefer Transparent Doppelbett | Kiefer Transparent Modell 200 × 180 cm | Standard 200 × 180 cm | Bodentief Version FBW1.0 FBW1.0 Farbe transparent transparent Gewicht ca. 45 kg ca. 44 kg Abmessungen 208 ×...
Page 11
Doppelbett | Kiefer Weiß Doppelbett | Kiefer Weiß Modell 200 × 180 cm | Standard 200 × 180 cm | Bodentief Version FBW1.0 FBW1.0 Farbe weiß weiß Gewicht ca. 45 kg ca. 44 kg Abmessungen 208 × 188 × 74 cm 208 ×...
Page 12
Familienbett | Kiefer Transpa- Familienbett | Kiefer Transpa- Modell rent | 90 - 90 - 90 cm rent | 90 - 90 - 90 cm Standard Bodentief Version FBW1.0 FBW1.0 Farbe transparent transparent Gewicht ca. 61,5 kg ca. 59 kg Abmessungen 208 ×...
Page 13
8720929011278 8720929011285 Familienbett | Kiefer Weiß Familienbett | Kiefer Weiß Modell 90 - 180 - 90 cm | Standard 90 - 180 - 90 cm | Bodentief Version FBW1.0 FBW1.0 Farbe weiß weiß Gewicht ca. 75,5 kg ca. 72,5 kg Abmessungen 208 ×...
Page 14
Familienbett | Kiefer Weiß Familienbett | Kiefer Weiß Modell 180 - 180 cm | Standard 180 - 180 cm | Bodentief Version FBW1.0 FBW1.0 Farbe weiß weiß Gewicht ca. 74,5 kg ca. 72 kg Abmessungen 208 × 369 × 74 cm 208 ×369×...
Page 15
180 × 12,5× 71 cm 180 ×12,5× 71 cm montiert 8720929011339 8720929011537 Familienbett Rausfallschutz Familienbett Rausfallschutz Modell Kiefer Transparent Kiefer Weiß Version FBW1.0 FBW1.0 Farbe transparent weiß Gewicht ca. 5,4 kg ca. 5,4 kg Abmessungen 150 × 45× 8 cm 150 ×45× 8 cm...
Page 16
Doppelbett | Kiefer Natur Doppelbett | Kiefer Natur Modell 200 × 180 cm | Standard 200 × 180 cm | Bodentief Version FBW1.0 FBW1.0 Farbe Natur Natur Gewicht ca. 49,25 kg ca. 48,05 kg Abmessungen 208 × 188 × 74 cm 208 ×...
Page 17
8720929011278 8720929011285 Familienbett | Kiefer Natur Familienbett | Kiefer Natur Modell 90 - 180 - 90 cm | Standard 90 - 180 - 90 cm | Bodentief Version FBW1.0 FBW1.0 Farbe Natur Natur Gewicht ca. 83,09 kg ca. 76,21 kg Abmessungen 208 ×...
Page 18
4,76 kg ca. 6,36 kg Abmessungen 90 × 12,5× 71 cm 180 ×12,5× 71 cm montiert 8720929013302 8720929013319 Familienbett Rausfallschutz Modell Kiefer Natur Version FBW1.0 Farbe Natur Gewicht ca. 6,42 kg Abmessungen 150 × 45× 8 cm montiert 8720929013296...
Eine Konformitätserklärung kann bei der unten ange- führten Adresse angefordert werden. Entsorgung Verpackung entsorgen Entsorge die Verpackung sortenrein. Gib Pappe und Karton zum Altpapier, Folien in die Wertstoff-Sammlung. Ehrenkind Doppelbett/Familienbett entsorgen Entsorge das Doppelbett/Familienbett gemäß den in deinem Land geltenden Vorschrif- ten zur Entsorgung.
Page 20
Reading and retaining the instruction manual Explanation of symbols Safety Intended use General information on the use of a family bed Safety instructions Assembly instructions Cleaning Maintenance Storage Technical specifications Declaration of conformity Disposal Disposing of the packaging Disposing of the Ehrenkind Double bed/Family bed...
General information Reading and retaining the instruction manual This instruction manual is part of the Ehrenkind Double bed/Family bed. It contains important information on initial set-up and handling. Read the instructions carefully, especially the safety instructions, before using the Ehrenkind Double bed/Family bed.
Declaration of conformity (see chapter “Declaration of conformity”): Products marked with this symbol comply with all applicable Community rules of the European Economic Area. Safety Intended use The double bed/family bed is exclusively intended for use as a bed and indoors. It is intended solely for household use and is not suitable for commercial purposes.
We strongly recommend staying informed about current guidelines from health organi- zations and ensuring that all safety standards are followed. These guidelines serve only as a reference and do not replace professional advice. Safety instructions WARNING! Risk of injury! Improper handling of the product may lead to serious injuries. •...
• Do not use the double bed/family bed if its wooden components are cracked, split or deformed. Replace damaged components only with suitable original spare parts. Assembly instructions WARNING! Risk of injury! • Note that the double bed/family bed can only be used after complete assembly. •...
Cleaning Clean all parts of the Ehrenkind Double bed/Family bed before the first use. NOTICE Risk of damage! Improper handling of the product may damage it. • Do not use aggressive cleaning agents, brushes with metal or nylon bristles, or sharp or metallic cleaning tools, such as knives, hard scrapers or similar.
+5 °C and +20 °C (room temperature). Technical specifications Double bed | Pine Transparent Double bed | Pine Transparent Model 200 × 180 cm | Standard 200 × 180 cm | Floor-level Version FBW1.0 FBW1.0 Color transparent transparent Weight approx. 45 kg approx. 44 kg Dimensions when 208 ×...
Page 27
Double bed | Pine White Double bed | Pine White Model 200 × 180 cm | Standard 200 × 180 cm | Floor-level Version FBW1.0 FBW1.0 Color white white Weight approx. 45 kg approx. 44 kg Dimensions when 208 × 188 × 74 cm 208 ×...
Page 28
Family bed | Pine Transparent Family bed | Pine Transparent Model 90 - 90 - 90 cm | Standard 90 - 90 - 90 cm | Floor-level Version FBW1.0 FBW1.0 Color transparent transparent Weight approx. 61,5 kg approx. 59 kg Dimensions when 208 ×...
Page 29
Family bed | Pine White Family bed | Pine White Model 90 - 180 - 90 cm | Standard 90 - 180 - 90 cm | Floor-level Version FBW1.0 FBW1.0 Color white white Weight approx. 75,5 kg approx. 72,5 kg Dimensions when 208 ×...
Page 30
Family bed Deconstruction set Family bed Deconstruction set Model Pine Transparent | Standard Pine Transparent | Floor-level Version FBW-V1.0 FBW-V1.0 Color transparent transparent Weight approx. 20,5 kg approx. 19,5 kg Dimensions when 208 × 8× 74 cm 208 ×8× 53 cm assembled 8720929011292 8720929011308...
Page 31
180 ×12,5× 71 cm assembled 8720929011339 8720929011537 Family bed Fall guard Pine Family bed Fall guard Pine White Model Transparent Version FBW1.0 FBW1.0 Color transparent white Weight approx. 5,4 kg approx. 5,4 kg Dimensions when 150 × 45× 8 cm 150 ×45×...
Page 32
Double bed | Pine Natural Double bed | Pine Natural Model 200 × 180 cm | Standard 200 × 180 cm | Floor-level Version FBW1.0 FBW1.0 Color natural natural Weight approx. 49,25 kg approx. 48,05 kg Dimensions when 208 × 188 × 74 cm 208 ×...
Page 33
Family bed | Pine Natural Family bed | Pine Natural Model 90 - 180 - 90 cm | Standard 90 - 180 - 90 cm | Floor-level Version FBW1.0 FBW1.0 Color natural natural Weight approx. 83,09 kg approx. 76,21 kg Dimensions when 208 ×...
Page 34
6,36 kg Dimensions when 90 × 12,5× 71 cm 180 ×12,5× 71 cm assembled 8720929013302 8720929013319 Family bed Fall guard Natural Model Transparent Version FBW1.0 Color natural Weight approx. 6,42 kg Dimensions when 150 × 45× 8 cm assembled 8720929013296...
Dispose of the packaging properly. Discard cardboard and boxes in the waste paper bin, and plastic films in the recycling bin. Disposing of the Ehrenkind Double bed/Family bed Dispose of the Ehrenkind Double bed/Family bed in accordance with the waste disposal regulations applicable in your country.
Page 36
Lire et conserver le mode d’emploi Explication des symboles Sécurité Utilisation conforme Informations générales sur l‘utilisation d‘un lit familial Consignes de sécurité Instructions de montage Nettoyage Entretien Stockage Données techniques Déclaration de conformité Élimination Éliminer l’emballage Mise au rebut de Lit double/ Lit familial Ehrenkind...
Généralités Lire et conserver le mode d’emploi Ce mode d’emploi concerne Lit double/ Lit familial Ehrenkind. Il contient des informa- tions importantes sur sa mise en service et sa manipulation. Avant toute utilisation de Lit double/ Lit familial Ehrenkind, lisez attentivement le mode d’emploi, en particulier les consignes de sécurité.
Page 38
tériels. Ce symbole fournit des informations complémentaires utiles sur le montage ou le fonc- tionnement. Déclaration de conformité (voir chapitre « Déclaration de conformité ») : Les produits portant ce symbole sont conformes à toutes les réglementations communautaires applicables dans l’Espace économique européen.
Sécurité Utilisation conforme Le lit double/lit familial est exclusivement destiné à être utilisé comme lit et en intérie- ur. Il est exclusivement destiné à un usage domestique et n‘est pas adapté à un usage commercial. Utilisez le lit double/lit familial uniquement comme décrit dans ce mode d‘emploi.
Consignes de sécurité ATTENTION ! Risque de blessures ! Un maniement inapproprié du produit peut entraîner de graves blessures. • Veillez à ce que le lit double/lit familial soit utilisé uniquement à des fins prévues et non détourné de son usage. •...
Instructions de montage ATTENTION ! Risque de blessure ! • Notez que le lit double/lit familial ne peut être utilisé qu‘après un montage complet. • Veuillez noter que l‘ensemble d‘accessoires de montage contient des petites pièces qui peuvent être avalées par les enfants, entraînant un risque d‘étouffement. Les enfants ne doivent jamais jouer avec les pièces individuelles.
Nettoyage Nettoyez avant la première utilisation toutes les pièces du Lit double/Lit familial Ehrenkind. NOTER Risque de détériorations ! Un traitement inapproprié du produit peut l’endommager. • N’utilisez pas de produits de nettoyage agressifs, de brosses à poils métalliques ou en nylon, ou d’outils de nettoyage tranchants ou métalliques tels que des couteaux,...
Données techniques Lit double | Pin Transparent Lit double | Pin Transparent Modèle 200 × 180 cm | Standard 200 × 180 cm | Niveau du sol Version FBW1.0 FBW1.0 Coleur transparent transparent Poids environ 45 kg environ 44 kg Dimensions àpres...
Page 44
Lit double | Pin Blanc Lit double | Pin Blanc Modèle 200 × 180 cm | Standard 200 × 180 cm | Niveau du sol Version FBW1.0 FBW1.0 Coleur blanc blanc Poids environ 45 kg environ 44 kg Dimensions àpres 208 ×...
Page 45
8720929011483 Lit familial | Pin Transparent Lit familial | Pin Transparent Modèle 90 - 90 - 90 cm | Standard 90 - 90 - 90 cm | Niveau du sol Version FBW1.0 FBW1.0 Coleur transparent transparent Poids environ 61,5 kg ca.
Page 46
8720929011285 Lit familial | Pin Blanc Lit familial | Pin Blanc Modèle 90 - 180 - 90 cm | Standard 90 - 180 - 90 cm | Niveau du sol Version FBW1.0 FBW1.0 Coleur blanc blanc Poids environ 75,5 kg environ 72,5 kg Dimensions àpres...
Page 47
Coleur blanc blanc Poids environ 74,5 kg environ 72 kg Dimensions àpres 208 × 369 × 74 cm 208 ×369× 53 cm montage 8720929011452 8720929011469 Lit familial Kit de démontage Lit familial Kit de démontage Modèle Pin Transparent | Standard Pin Transparent | Niveau du sol Version FBW-V1.0...
Page 48
180 ×12,5× 71 cm montage 8720929011339 8720929011537 Lit familial Protection antichute Lit familial Protection antichute Modèle Pin Transparent Pin Blanc Version FBW1.0 FBW1.0 Coleur transparent blanc Poids environ 5,4 kg environ 5,4 kg Dimensions àpres 150 × 45× 8 cm 150 ×45×...
Page 49
Lit double | Pin Nature Lit double | Pin Nature Modèle 200 × 180 cm | Standard 200 × 180 cm | Niveau du sol Version FBW1.0 FBW1.0 Coleur nature nature Poids environ 49,25 kg environ 48,05 kg Dimensions àpres 208 ×...
Page 50
Lit familial | Pin Nature Lit familial | Pin Nature Modèle 90 - 180 - 90 cm | Standard 90 - 180 - 90 cm | Niveau du sol Version FBW1.0 FBW1.0 Coleur nature nature Poids environ 83,09 kg ca. 76,21 kg Dimensions àpres...
Page 51
6,36 kg Dimensions àpres 90 × 12,5× 71 cm 180 ×12,5× 71 cm montage 8720929013302 8720929013319 Lit familial Protection antichute Modèle Pin Nature Version FBW1.0 Coleur transparent Poids environ 6,42 kg Dimensions àpres 150 × 45× 8 cm montage 8720929013296...
Mise au rebut de Lit double/Lit familial Ehrenkind Mettez au rebut Lit double/Lit familial Ehrenkind conformément à la réglementation en vigueur dans votre pays.
Page 53
Indice Informazioni generali Leggere e conservare le istruzioni per l’uso Spiegazione dei simboli Sicurezza Uso previsto Informazioni generali sull‘uso di un letto familiare Avvertenze di sicurezza Istruzioni di montaggio Pulizia Manutenzione Conservazione Dati tecnici Dichiarazione di conformità Smaltimento Smaltire l‘imballaggio Smaltimento della Letto matrimoniale/Letto familiare...
Leggere e conservare le istruzioni per l’uso Le presenti istruzioni per l’uso sono parte integrante della Letto matrimoniale/Letto familiare Ehrenkind. Contengono informazioni importanti sulla messa in funzione e sull’utilizzo. Prima di utilizzare la Letto matrimoniale/Letto familiare Ehrenkind, leggere attentamente le istruzioni per l‘uso, in particolare le avvertenze di sicurezza. La mancata osservanza di queste istruzioni per l’uso può...
Page 55
Questo simbolo fornisce ulteriori informazioni utili sul montaggio o sul funzionamento. Dichiarazione di conformità (vedi capitolo “Dichiarazione di conformità”): i prodotti contrassegnati da questo simbolo soddisfano tutte le normative comunitarie applicabili dello Spazio economico europeo.
Sicurezza Uso previsto Il letto matrimoniale/letto familiare è destinato esclusivamente all‘uso come letto e all‘inter- no degli spazi abitativi. È destinato esclusivamente per uso domestico e non è adatto per utilizzi commerciali. Usa il letto matrimoniale/letto familiare solo come descritto in questo manuale di istruzioni.
Avvertenze di sicurezza AVVERTIMENTO! Rischio di lesioni! L’uso improprio del prodotto può causare lesioni gravi. • Assicurati che il letto matrimoniale/letto familiare venga utilizzato solo come previsto e non in modo improprio. • Il letto matrimoniale/letto familiare non deve essere bagnato. Puliscilo seguendo le istruzioni di pulizia riportate di seguito.
Istruzioni di montaggio AVVERTIMENTO! Rischio di lesioni! • Considera che il letto matrimoniale/letto familiare può essere utilizzato solo dopo il completo montaggio. • Tieni presente che il set di accessori per il montaggio contiene in parte piccole parti che potrebbero essere ingerite dai bambini, causando il rischio di soffocamento. I bambini non devono mai giocare con i singoli componenti.
Pulizia Pulisci prima dell‘uso tutte le parti del Letto matrimoniale/Letto familiare Ehrenkind. NOTA Rischio di danni! L‘uso improprio del prodotto può provocare danni al prodotto stesso. • Non usare detergenti aggressivi, spazzole con setole di metallo o nylon, o oggetti di pulizia affilati o metallici come coltelli, spatole dure e simili.
Dati tecnici Letto matrimoniale Letto matrimoniale Modello Pino Trasparente | 200 × 180 cm Pino Trasparente | 200 × 180 cm Standard Profondità pavimento Versione FBW1.0 FBW1.0 Colore trasparente trasparente Peso circa 45 kg circa 44 kg Dimensioni da 208 × 188 × 74 cm 208 ×...
Page 61
Letto matrimoniale Letto matrimoniale Modello Pino Bianco | 200 × 180 cm Pino Bianco | 200 × 180 cm Standard Profondità pavimento Versione FBW1.0 FBW1.0 Colore bianco bianco Peso circa 45 kg circa 44 kg Dimensioni da 208 × 188 × 74 cm 208 ×...
Page 62
Letto familiare | Pino Trasparen- Letto familiare | Pino Trasparen- Modello te | 90 - 90 - 90 cm te | 90 - 90 - 90 cm | Profondità Standard pavimento Versione FBW1.0 FBW1.0 Colore bianco bianco Peso circa 61,5 kg circa 59 kg Dimensioni da 208 ×...
Page 63
Letto familiare | Pino Trasparen- Letto familiare | Pino Trasparen- Modello te | 90 - 180 - 90 cm te | 90 - 180 - 90 cm Standard Profondità pavimento Versione FBW1.0 FBW1.0 Colore trasparente trasparente Peso circa 75,5 kg circa 72,5 kg Dimensioni da 208 ×...
Page 64
8720929011261 Letto familiare | Pino Bianco Letto familiare | Pino Bianco Modello 180 - 180 cm | Standard 180 - 180 cm | Profondità pavi- mento Versione FBW1.0 FBW1.0 Colore bianco bianco Peso circa 74,5 kg circa 72 kg Dimensioni da 208 ×...
Page 65
Letto familiare Set di smontag- Letto familiare Set di smontag- Modello gio | Pino Bianco | Standard gio | Pino Bianco | Profondità pavimento Versione FBW-V1.0 FBW-V1.0 Colore bianco bianco Peso circa 20,5 kg circa 19,5 kg Dimensioni da 208 × 8× 74 cm 208 ×8×...
Page 66
8720929011339 8720929011537 Letto familiare Protezione anti- Letto familiare Protezione anti- Modello caduta | Pino Trasparente caduta | Pino Bianco Versione FBW1.0 FBW1.0 Colore trasparente bianco Peso circa 5,4 kg circa 5,4 kg Dimensioni da 150 × 45× 8 cm 150 ×45× 8 cm...
Page 67
Letto familiare | Pino Natura Letto familiare | Pino Natura Modello 180 - 90 cm | Standard 180 - 90 cm | Profondità pavi- mento Versione FBW1.0 FBW1.0 Colore natura natura Peso circa 66,17 kg circa 64,69 kg Dimensioni da 208 ×...
Page 68
Letto familiare | Pino Natura Letto familiare | Pino Natura Modello 90 - 180 - 90 cm 90 - 180 - 90 cm Standard Profondità pavimento Versione FBW1.0 FBW1.0 Colore natura natura Peso circa 83,09 kg circa 76,21 kg Dimensioni da 208 ×...
Page 69
Dimensioni da 90 × 12,5× 71 cm 180 ×12,5× 71 cm montato 8720929013302 8720929013319 Letto familiare Protezione anti- Modello caduta | Pino Natura Versione FBW1.0 Colore natura Peso circa 5,4 kg Dimensioni da 150 × 45× 8 cm montato 8720929011315...
Dichiarazione di conformità La dichiarazione di conformità può essere richiesta al seguente indirizzo. Smaltimento Smaltire l‘imballaggio Smaltire l’imballaggio differenziandolo. Smaltire il cartone nella raccolta della carta straccia e le pellicole nella raccolta dei materiali riciclabili. Smaltimento della Letto matrimoniale/Letto familiare Smaltire il letto matrimoniale/letto familiare in conformità...
Page 71
