  • Page 1 Q170A-IM-A...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Chapter 1 Product overview Package contents ................. 1-1 Features ..................1-1 1.3 Specifications ................1-2 Chapter 2 Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Central Processing Unit (CPU) ........... 2-4 2.3.1 Installing the CPU ............2-5 2.3.2 CPU heatsink and fan assembly installation ....
  • Page 4 Watchdog Timer ............3-11 3.3.15 Network Stack Configuration ........3-11 3.3.16 Miscellaneous ............... 3-11 Hardware Monitor menu ............3-12 Security menu ................3-12 Boot menu .................. 3-14 Exit menu ..................3-16 Appendix Notices .......................A-1 Warranty ....................A-5 ASUS contact information ...............A-7...

  • Page 5: Chapter 1 Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x ASUS Q170A-IM-A Industrial Motherboard 1 x SATA 6.0 Gb/s cable 1 x M.2 screw package 1 x ASUS I/O shield NOTE: If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 6: Specifications

    1 x Clear CMOS header Internal I/O connectors 6 x COM Port headers (RS232) 2 x COM1/2 Ring/+5V/+12V selection jumpers 1 x CPU Fan header (PWM mode) 1 x Front Panel Audio header (AAFP) (continued on the next page) Q170A-IM-A...
  • Page 7 RedHat Enterprise Fedora Workstation Open SUSE Certification CE, FCC Form Factor ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm) NOTE: Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications. Chapter 1: General information...
  • Page 8 Q170A-IM-A...

  • Page 9: Chapter 2 Motherboard Information

    Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.

  • Page 10: Motherboard Layout

    I219V PCI_1 PCI_2 Intel ® 1085 Q170 SATA6G_1 SATA6G_2 PCIEX16_2 SATA6G_3 Super PCIEX16_3 M.2(SOCKET3) PCIE SATA IRST AT_ATX_SEL PCIEX4 WDT_EN 2280 2260 2242 PCI_3 USB56 AAFP COM3 COM4 LPC_DEBUG USB78 GPIO_CON SPEAKER CLRTC F_PANEL CHASSIS 15 14 13 12 Q170A-IM-A...
  • Page 11 Connectors/Jumpers/Slots Page COM1/2 Ring/+5V/+12V selection jumpers (6-pin COM1_SEL, COM2_SEL) 2-12 ATX Power connectors (24-pin EATXPWR, 4-pin ATX12V) 2-16 CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN) 2-16 Intel LGA1151 CPU socket ® DDR4 U-DIMM slots COM Port headers (10-1 pin COM3 - COM8) 2-17 2-17 USB 2.0 headers/connectors (10-1 pin USB56, USB78 / USB9, USB10)

  • Page 12: Central Processing Unit (Cpu)

    Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1151 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap. Q170A-IM-A...

  • Page 13: Installing The Cpu

    2.3.1 Installing the CPU CAUTION! LGA1156 CPU is not compatible with the LGA1151 socket. DO NOT install an LGA1156 CPU on the LGA1151 socket. Chapter 2: Motherboard information...
  • Page 14 Q170A-IM-A...

  • Page 15: Cpu Heatsink And Fan Assembly Installation

    2.3.2 CPU heatsink and fan assembly installation CAUTION! Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 2: Motherboard information...
  • Page 16 To uninstall the CPU heatsink and fan assembly Q170A-IM-A...

  • Page 17: System Memory

    System memory This motherboard comes with two Double Data Rate 4 (DDR4) Dual Inline Memory Module (DIMM) sockets. The figure below illustrates the location of the DDR4 DIMM sockets: Channel Sockets Channel A U-DIMM_A1* Channel B U-DIMM_B1* Recommended memory configuration DIMM_A1* DIMM_B1* DIMM_B1* Installing a DIMM Chapter 2: Motherboard information...
  • Page 18 To remove a DIMM Q170A-IM-A 2-10...

  • Page 19: Jumpers

    Jumpers Clear RTC RAM (2-pin CLRTC) This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. CLRTC Connector type HEADER 1x2p, 2.54mm pitch, S/T To erase the RTC RAM: Turn OFF the computer and unplug the power cord.
  • Page 20 The chassis intrusion sensor or switch sends a low-level signal to this connector when a chassis component is installed. The signal is then generated as a chassis intrusion event. CHASSIS PIN 1 Connector type HEADER 4p, K2, 2.54mm pitch Q170A-IM-A 2-12...
  • Page 21 AT/ATX mode selection jumper (3-pin AT_ATX_SEL) AT_ATX_SEL High Active Low Active (Default) Pins 1-2 (Default) ATX mode AT mode Connector type HEADER 1x3p, 2.54mm pitch, S/T WDT Enable jumper (2-pin WDT_EN) A watchdog timer is an electronic timer that is used to detect and recover from computer malfunctions.

  • Page 22: Connectors

    Speaker Out. PS/2 keyboard port (purple). This port is for a PS/2 keyboard. HDMI port. This port is for a High-Definition Multimedia Interface (HDMI connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content. Q170A-IM-A 2-14...
  • Page 23 USB 3.2 Gen 1 (up to 5Gbps) ports. These 9-pin Universal Serial Bus (USB) ports are for USB 3.2 Gen 1 devices. 10. Microphone port (pink). This port connects to a microphone. Refer to the audio configuration table for the function of the audio ports in 2, 4, 5.1, or 7.1-channel configuration.

  • Page 24: Internal Connectors

    WAFER HD 4p, 2.54mm pitch, S/T CAUTION! Do not forget to connect the fan cables to the fan headers. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan headers! Q170A-IM-A 2-16...
  • Page 25 COM Port headers (10-1 pin COM3 - COM8) These headers are for serial (COM) ports. Connect the serial port cables to these headers, then install the module to a slot opening at the back of the system chassis. COM6 COM5 COM8 COM7 RI1#...
  • Page 26 Serial Peripheral Interface (SPI), allowing you to securely store keys, digital certificates, passwords and data. A TPM system also enhances network security, protects digital identities, and ensures platform integrity. PIN 1 Connector type Header 2x7p, K14, 2.0mm pitch Q170A-IM-A 2-18...
  • Page 27 M.2 slot (SOCKET 3) This slot allows you to install an M.2 SSD module. M.2(SOCKET3) NOTES: • The M.2 SSD module is purchased separately. • This slot supports M Key and 2242/2260/2280 storage devices. • We recommend using a PH1 screwdriver with a torque of 2.0+/-0.2 kgf·cm when tightening the screw.
  • Page 28 ATX power button/soft-off button (2-pin PWR_BTN) This 2-pin header is for the system power button. • Reset button (2-pin RESET) This 2-pin header is for the chassis-mounted reset button for system reboot without turning off the system power. Q170A-IM-A 2-20...
  • Page 29 Speaker header (4-pin SPEAKER) The 4-pin header is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. SPEAKER PIN 1 Connector type HEADER 1x4p, 2.54mm pitch, S/T 10. I C header (6-1 pin 1 The I C (Inter-Integrated Circuit) header allows you to connect an I compatible IoT security module.
  • Page 30 HEADER 2x5p, K10, 2.0mm pitch IMPORTANT! • Scan the QR code to view the meaning of each debugging code. • Debugging codes are only available for ASUS LPC Debug cards. • Contact your region sales representative for LPC Debug cards ordering. Q170A-IM-A 2-22...
  • Page 31 13. LPT header (26-1 pin LPT) The LPT (Line Printing Terminal) header supports devices such as a printer. LPT is standardized as IEEE 1284, which is the parallel port interface on IBM PC-compatible computers. PIN 1 14. Front Panel Audio header (10-1 pin AAFP) This header is for a chassis-mounted front panel audio I/O module that supports HD Audio standard.
  • Page 32 Q170A-IM-A 2-24...

  • Page 33: Chapter 3 Bios Setup

    Always shut down the system properly from the operating system. IMPORTANT! • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. • The default BIOS settings for this motherboard apply to most working conditions and ensures optimal performance.

  • Page 34: Bios Menu Screen

    3.3.1 PCH-FW Configuration TPM Device Selection Allows you to select the TPM device. Configuration options: [dTPM] [PTT] 3.3.2 Trusted Computing Security Device Support Allows you to enable or disable BIOS support for security devices. Configuration options: [Disabled] [Enabled] Q170A-IM-A...

  • Page 35: Cpu Configuration

    3.3.3 CPU Configuration The items in this menu show CPU-related information the BIOS automatically detects. The items shown in the submenu may be different depending on the type of CPU installed. Intel (VMX) Virtualization Technology When set to [Enabled], a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.

  • Page 36: Graphics Configuration

    Configuration options: [Auto] [Force X1] [Force X2] [Force X4] [Force X8] ASPM Allows you to control the ASPM (Active State Power Management) for PEG 0. It does not work if PEG is not the current active device. Configuration options: [Disabled] [Auto] [ASPM L0s] [ASPM L1] [ASPM L0sL1] Q170A-IM-A...
  • Page 37 Detect Non-Compliance Device Allows you to enable or disable the detection function of non-compliance PCI Express device. Configuration options: [Disabled] [Enabled] PCIEX16_2 Slot PCIEX16_2 Slot Allows you to enable or disable the PCIEX16_2 slot. Configuration options: [Disabled] [Enabled] ASPM Allows you to control the Active State Power Management on both NB (NorthBridge) side and SB (SouthBridge) side of the DMI Link.
  • Page 38 Allows you to set the time (in milliseconds) of waiting for link to exit Detect state for enabled ports before assuming there is no device and potentially disabling the port. Use the <+> and <-> keys to adjust the value or input the desired value directly. Q170A-IM-A...

  • Page 39: Csm Configuration

    Hot Plug Allow you to enable and disable the PCIEX4 slot Hot Plug support. Configuration options: [Disabled] [Enabled] Detect Non-Compliance Device Allows you to enable or disable the detection function of non-compliance PCI Express device. Configuration options: [Disabled] [Enabled] 3.3.6 CSM Configuration CSM Support Allow you to enable/disable the CSM support.
  • Page 40 [IO=3BCh; IRQ=5, 6, 7, 9, 10, 11, 12;] Mode [RS232] Allows you to select the Parallel Port mode. Configuration options: [STD Printer Mode] [SPP Mode] [EPP-1.9 and SPP Mode] [EPP-1.7 and SPP Mode] [ECP Mode] [ECP and EPP 1.9 Mode] [ECP and EPP 1.7 Mode] Q170A-IM-A...

  • Page 41: Serial Console Configuration

    NCT5104DSEC Super IO Configuration Serial Port 5/6/7/8 Configuration Serial Port Allows you to enable or disable the serial port (COM). Configuration options: [Disabled] [Enabled] 3.3.8 Serial Console Configuration COM1~COM8 Console Redirection Allows you enable or disable the console redirection feature. Configuration options: [Enabled] [Disabled] 3.3.9 SATA Configuration SATA6G_1/2/3 Allow you to enable/disable the SATA6G_1/2/3 port.

  • Page 42: Apm Configuration

    This item allows you to enable or disable the Wake-on-LAN function of the onboard LAN controller or other installed PCI LAN cards. Configuration options: [Disabled] [Enabled] Power On By Ring [Enabled] Enables the Ring devices to generate a wake event. [Disabled] Disables the Ring devices to generate a wake event. Q170A-IM-A 3-10...

  • Page 43: Ezflash

    Power On By RTC When set to [Enabled], the items RTC Alarm Date(Days) and [Enabled] Hour/Minute/Second are use-conffigurable with set values. [Disabled] Disables RTC to generate a wake event. 3.3.13 EzFlash Enter Ez-Flash mode This item allows you to run EzFlash utility. When you press <Enter>, a confirmation message appears.

  • Page 44: Hardware Monitor Menu

    If you have set an administrator password, we recommend that you enter the administrator password for accessing the system. To set an administrator password: Select the Administrator Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. Q170A-IM-A 3-12...
  • Page 45 To change an administrator password: Select the Administrator Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>. From the Create New Password box, key in a new password, then press <Enter>. Confirm the password when prompted.

  • Page 46: Boot Menu

    NVMe device will be enabled in fast boot mode. VGA Support [Auto] Only installing Legacy OpROM with Legacy OS and logo will not display during POST . [EFI Driver] Only EFI driver will be installed with EFI OS. Q170A-IM-A 3-14...
  • Page 47 USB Support [Disabled] All USB devices will not be available until OS boot up for a fastest POST time. [Full Initial] All USB devices will be available during POST. This process will extend the POST time. [Partial Initial] For a faster POST time, only the USB ports with keyboard and mouse connections will be detected.

  • Page 48: Exit Menu

    Restore/load default values for all the setup options. Save as User Defaults This option allows you to save the changes you have made so far as user defaults. Restore User Defaults Restore the user defaults with all the setup options. Q170A-IM-A 3-16...

  • Page 49: Appendix

    Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 50 CAN ICES-003(B)/NMB-003(B) VCCI: Japan Compliance Statement Class B ITE KC: Korea Warning Statement HDMI Compliance Statement The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Q170A-IM-A...
  • Page 51 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
  • Page 52 доступний на: www.asus.com/support Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Türkçe AsusTek Computer Inc., bu aygıtın temel gereksinimlerle ve ilişkili Čeština Společnost ASUSTeK Computer Inc. tímto prohlašuje, že toto Yönergelerin diğer ilgili koşullarıyla uyumlu olduğunu beyan eder.

  • Page 53: Warranty

    • ASUS offers a voluntary manufacturer’s Commercial Guarantee. • ASUS dragovoljno nudi komercijalno proizvođačko jamstvo. • ASUS reserves the right to interpret the provisions of the ASUS • ASUS zadržava prava na tumačenje odredbi ASUS komercijalnog Commercial Guarantee. jamstva. •...
  • Page 54 Si tiene alguna queja o necesidad de un centro de reparación local Všetky ďalšie informácie o záruke nájdete na o el periodo de garantía del producto ASUS, por favor visite el sitio https://www.asus.com/sk/support. de Soporte de ASUS en https://www.asus.com/mx/support/ para mayores detalles.

  • Page 55: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site https://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support https://qr.asus.com/techserv ASUS COMPUTER GmbH (Germany and Austria) Address Harkortstrasse 21-23, 40880 Ratingen, Germany Web site https://www.asus.com/de Online contact https://www.asus.com/support/Product/ContactUs/ Services/questionform/?lang=de-de Technical Support Telephone (DE) +49-2102-5789557 Telephone (AT)
  • Page 56 Q170A-IM-A...
