System memory
This motherboard comes with two Double Data Rate 4 (DDR4) Dual Inline Memory
Module (DIMM) sockets. The figure below illustrates the location of the DDR4
DIMM sockets:
Recommended memory configuration
DIMM_B1*
Installing a DIMM
1
Chapter 2: Motherboard information
Channel
Channel A
Channel B
DIMM_A1*
DIMM_B1*
Sockets
U-DIMM_A1*
U-DIMM_B1*
2-9
