- Page 1 TRANSIT Air & Surface Disinfection Owner’s Manual CAUTION: Read manual carefully for proper procedures and operation.
-
Page 2: Table Of Contents
Congratulations on your purchase of a CASPR Technologies enhanced air and surface disinfection system. This unit is designed to be mounted into any vehicle. Please read and follow all safety warnings and service procedures outlined in this manual. Use only genuine CASPR Technologies replacement parts available from your CASPR Technologies Distributor. -
Page 3: Warnings
• Do not touch NCC bulb with bare hands. WARNING WARNING! - UV light in operation. Disconnect unit from power supply before servicing. Failure to follow warnings may result in severe eye damage. Specifications TRANSIT 120V TRANSIT 24V TRANSIT 12V Weight 4.0 lbs 4.0 lbs 4.0 lbs... -
Page 4: Unit Diagrams
Unit Diagrams Unit Front Air Outlet Filter Flush Mounting Bracket Unit Back Security Mounting Holes Unit Internals NCC Cell... -
Page 5: Installation
STATE, AND LOCAL CODES. WHEN APPLICABLE, THE SYSTEM MUST BE WIRED THROUGH THE SAFETY NOISE SUPPRESSION RELAY SYSTEM. • Wire the system through a relay system to prevent the CASPR unit/s from draining the battery when not in operation. • A fuse must be installed at the source of the power supply when installing a CASPR Transit unit onto a vehicle. - Page 6 2 Units Wired in Parallel Using the available power source please be sure to CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CASPR Group Inc. ANY REPRODUCTION IN PART OR AS A include an in-line fuse. WHOLE WITHOUT THE WRITTEN PERMISION OF CASPR PLEASE ADVISE FAILURE OF USING A FUSE AT Group Inc.
-
Page 7: Filter Cleaning And Replacement
Filter Cleaning and Replacement We recommend cleaning the filter every 90 days, or when noticeably contaminated, by vacuuming the filter through the front filter cover. The filter should be replaced every 6 months. Service should only be performed by a qualified technician. -
Page 8: Cleaning The Unit
5. Reconnect unit to power source. NCC Cell Replacement Your CASPR Transit unit requires replacement of the NCC cells and bulbs every 18- 24 months, even if the bulb appears to be operating normally. Service should only be performed by a qualified HVAC technician. Make sure there is no power going to the unit prior to handling. - Page 9 3. Unscrew the mounting bracket 4. Unscrewing the two screws located assembly holding the NCC Cell in on the sides of the cell housing. place and lift it up out of the case. 5. Separate the Cell housing from the 6.
-
Page 10: Fuse Replacement
10. Connect the new 11. Attach the new 12. Install the Assembly Bulb to socket Cell Housing to the onto the TRANSIT unit in the mounting mounting bracket and secure with the Bracket Assembly. with the previously two thumb screws. removed screws (2). -
Page 11: Cell Disposal
Troubleshooting If your NCC Cell or CASPR TRANSIT fan does not turn on, check to ensure a secure connection. If secure, but the fan is not on, it may need to be replaced. If the connection is secure but the cell does not light up, the NCC cell or ballast may need to be replaced. -
Page 12: Warranty Information
This warranty gives you specific legal rights, and you Servicing of your CASPR Transit by parties other than our may also have other rights which vary from state authorized representatives and/or using parts other than to state. - Page 13 www.CASPRTech.com 4505 Excel Pkwy Suite 600, Addison, TX 75001 (844) 717-8819 V. IN-M-TR-01-11062021-AE...
