AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL
AQUALUMIN Nicheless Pool Light
Replacement
Pool Light
Installation and Operations Manual
4830 Timber Creek Dr, Houston, TX 77017
North America: +1 (713)-946-4343
www. pallighting.com
PAL Lighting LLC
Advertisement
Table of Contents
Related Manuals for PAL AQUALUMIN 64-PAL-RAL
Summary of Contents for PAL AQUALUMIN 64-PAL-RAL
- Page 1 64-PAL-RAL-80-T AquaLumin Sonar Retro Pool Light with Remote, PCR-2T-65 and 80ft Cable 64-PAL-RAL-150 AquaLumin Sonar Retro Pool Light with Remote, PCR-2T-65 and 150ft Cable PAL Lighting LLC 4830 Timber Creek Dr, Houston, TX 77017 North America: +1 (713)-946-4343 www. pallighting.com...
-
Page 2: Table Of Contents
ENGLISH AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL TABLE OF CONTENTS Section 1. Safety Instructions Section 2. Preparation Package Contents Preparation Work Section 3 Replacing the Light Section 4. Remote Programming Section 7. Replacement Parts For your safety, it is imperative that this product be installed and maintained by a licensed and qualified contractor specializing in pool equipment, adhering to local regulations. -
Page 3: Safety Instructions
1 x 24V Transformer 2.2 Preparation Work 1. The PAL AquaLumin Nicheless Replacement Pool Light is a 24V DC replacement light for the Pentair AquaLumin light. A 24V transformer will need to be installed to be able to operate our light. -
Page 4: Replacing The Light
2. Ensure that the pool's electrical system complies with the standards outlined in the current National Electrical Code (NEC). IMPORTANT NOTICE This PAL AquaLumin Nicheless Replacement Pool Light is intended to replace the existing AquaLumin Nicheless light. This product includes a new bracket, and a new light, completely replacing the original parts. - Page 5 ENGLISH AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL 4. Align the screws with the niche. See Figure 2 and 3. Figure 3 Figure 2 NOTE: The three machined screws will attach to the light mount and go through the gray plate into the niche to secure the light mount. The fourth pan head screw will secure only the gray gasket plate.
- Page 6 AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL IMPORTANT NOTICE We recommend pulling a new cable and using the PAL wires to operate the PAL AquaLumin Nicheless Replacement Pool Light. However, you can use the PAL gel kit and the existing wires to wire into the AquaLumin Nicheless Replacement Pool Light.
-
Page 7: Remote Programming
ENGLISH AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL Section 4. REMOTE PROGRAMMING Pairing Lights to Zones: Within 3 seconds of turning light on, press desired zone number ‘I button’ 3 times. Once linked, light(s) will flash 3 times. Cloning Modes: Within 3 seconds of turning light on, press and hold ‘I button’... -
Page 8: Replacement Parts
ENGLISH AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL Section 5. REPLACEMENT PARTS Light Replacement Parts Replacement Parts Item Part Number Description 64-PAL-RAL-BRK Wall Mounting Bracket 64-PAL-RAL-GASKET Wall Spacer 64-PAL-RAL-GEL Gel Pack 64-PAL-RAL-SCREW Screw Bag... - Page 9 ENGLISH AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL NOTES...
- Page 10 ENGLISH AQUALUMIN REPLACEMENT LIGHT | INSTALLATION & OPERATION MANUAL...
