Hisense ADT-09UX4RBL8 Technical & Service Manual page 169

10. WIRING DIAGRAM
Turbo Inverter
AUW-14U4RJ8
AUW-18U4RJ8
AUW-21U4RK8
AUW-24U4RK8
26
25
24
23
22
NO.
1 MCU
2 Program Port
3
EEPROM and EEPROM Circuit
4 Electronic Expansion Valve
5
EEPROM Flashing
6
Ambient Temperature Sensor
7
Coil Temperature Sensor
8
Discharge Temperature Sensor
9
Compressor Overheat Protector
10
Checker
11
DC Fan Motor IPM Module Circuit
12 Base Heater Interface
13 Heating Belt Interface
Super Inverter
AUW-14U4RS7
AUW-18U4RS7
AUW-21U4RJ7
AUW-24U4RJ7
AUW-36U4RK7
1
21
20 19
Description
2 3 4 5 6 7 8 9
18
NO.
4-Way Valve Circuit and Interface
14
15 Communication Circuit and SI Wire
16
L/N Power input
EARTH
17
Watcher
18
Main Relay
19
Filter Electrolytic Capacitor
20
Electric Reactor Wire
21
Bridge Rectifier
22
IGBT
23
Diode
24
IPM
25
26 Compressor U/V/W
