RDS-EON/FM-MPX/MW/LW
Radio CD combination with
CD/MD changer control
wocet DRX65/75RZ
(PE-2191E-B)
14.4V DC(10.8 to 15.6V allowable),
negative ground
B® FEATURES
Power consumption: Less than 15A
Speaker impedance: 40 (4 to 8Q allowable)
Auto antenna rated current:
500mA or less
Weight:
Main unit 1.7kg
Remote control unit
30g (including battery)
1.Rotary Encoder Control with Hluminated Search Key
2.Fully Detachable Flip Down Control Panel
3.RDS-Pro Receiver with' EON, PS, AF, TAT P, PTY,
REG and CT
4.CD-Deck with 1-Bit D/A Converter and 8-"Times
Oversampling
5.High Power 4x 40W Max./4 Gold Platet RCA Line
Dimensions(mm): — Main unit Level Output
ZBI) SO(HcTotQ)
6.Controller for MD and
CD Changer
Remote control unit
44(W) x 110(H) X27(D)
4.
