Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
Smeg FC40PXNE3
o
cerca il tuo prodotto tra le
migliori offerte di Frigoriferi e Congelatori
ELECTRONIC
NO-FROST COMBI REFRIGERATOR
Instruction booklet
ELEKTRONISCHE NO-FROST
KÜHL-GEFRIERKOMBI
Bedienungsanleitung
RÉFRIGÉRATEUR
COMBI NO-FROST ÉLECTRONIQUE
Notice d'installation et d'utilisation
KOEL/VRIESCOMBINATIE
ZONDER IJSAANSLAG
Handleiding
FRIGORIFERO
COMBINATO NO FROST
Guida all'installazione e uso
FC40PXNE3
Advertisement
Table of Contents
Related Manuals for Smeg FC40PXNE3
Summary of Contents for Smeg FC40PXNE3
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg FC40PXNE3 cerca il tuo prodotto tra le migliori offerte di Frigoriferi e Congelatori ELECTRONIC NO-FROST COMBI REFRIGERATOR Instruction booklet ELEKTRONISCHE NO-FROST KÜHL-GEFRIERKOMBI Bedienungsanleitung RÉFRIGÉRATEUR COMBI NO-FROST ÉLECTRONIQUE...
-
Page 3: Table Of Contents
Index BEFORE USING YOUR REFRIGERATOR ............2 Information on No-Frost technology ................2 Safety Information ......................3 Security warnings ......................4 Installation and Operation of your Refrigerator .............. 5 Before Starting to Operate Your Refrigerator ..............5 USAGE INFORMATION ..................6 Operating your fridge ...................... -
Page 4: Before Using Your Refrigerator
SHIPMENT AND REPOSITIONING ..............23 Repositioning the Door ....................23 BEFORE CALLING THE SERVICE ..............23 Tips For Saving Energy ....................26 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ....... 27 PART- 1. BEFORE USING YOUR REFRIGERATOR Information on No-Frost technology No-frost refrigerators differ from other static refrigerators in their operating principle. -
Page 5: Safety Information
Safety Information • While carrying and positioning the fridge, do not give damage to the cooler gas circuit. • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. •... -
Page 6: Security Warnings
Security warnings Warning: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. -
Page 7: Installation And Operation Of Your Refrigerator
Installation and Operation of your Refrigerator • The operation voltage of your refrigerator is 220-240 V and 50 Hz. • A specially grounded plug has been connected to the power cable of your refrigerator. This plug should be used with a specially grounded socket of 16 amperes. If there is no such socket in your house, please have it installed by an authorized electrician. -
Page 8: Usage Information
PART- 2. USAGE INFORMATION Display and control panel Use of control panel 1. Indicator and bar of Super Freeze mode 2. Indicator and bar of Super Cool mode 3. Adjustment indicators and bars of freezer. The active setting value will be illuminated. All bars from minimum up to the relative setting value will be illuminated. -
Page 9: Operating Your Fridge
Operating your fridge After the appliance is plugged, all symbols will appear for 2 seconds, and then the startup values will appear as -18°C on freezer setting indicator and +4°C on cooler setting indicator. All buttons on the control panel are touch-operated. (Only press to activate the button you want to operate.) Super Freeze Mode When would it be used? -
Page 10: Super Cool Mode
• Economical and Holiday modes can be selected. Super Freeze Mode will be cancelled and the selected mode is enabled. • When "Super Freeze" is active, SF can be re-selected and cancelled by pressing on button F. Note: “Super Freeze” mode will be automatically cancelled after 24 hours or freezer sensor temperature is lower than -32 Super Cool Mode When would it be used? -
Page 11: Economy Mode
Economy Mode Freezer and Cooler operate in the economical conditions that are determined in the control unit. When would it be used? • When you want your fridge to operate economically. How would it be used? • Touch button ECO. •... -
Page 12: Drink Cool Mode
• To cancel, you will just need to press on button VACATION. • Your fridge will continue to operate in the previous setting values. Drink Cool Mode When would it be used? • This mode is used to cool the drinks within adjustable time. -
Page 13: Light Cancelling Mode
Light Cancelling Mode When would it be used? • If you want to cancel lights of cooler, you can select this mode. • Press on Freezer (F) and Cooler (R) buttons simultaneously, and open and close the cooler door 3 times. The mode will be selected in this way. From now on, the lights will not come on when freezer and cooler doors are opened. -
Page 14: Cooler Temperature Settings
Cooler Temperature Settings • Initial temperature value for the Cooler Indicator is +4°C. • Press cooler (R) button once. • When you first push this button, +2°C appears on the setting indicator of the cooler. • W henever you press on this button, one bar comes on cooler bar graphic indicator and lower temperature will be set. -
Page 15: Warnings About Temperature Adjustments
Warnings about Temperature Adjustments • Your temperature adjustments will not be deleted when an energy breakdown occurs. • It is not recommended that you operate your fridge in environments colder than 10°C in terms of its efficiency. • Temperature adjustments should be made according to the frequency of door openings and the quantity of food kept inside the fridge. -
Page 16: Freezer Box
Freezer box The freezer box allows foods are maintained more regularly. Removing The freezer box; • Pull the box out as far as possible • Pull the front of box up and out. ! Make the inverse of the same operation for the resetting the sliding compartment. -
Page 17: Fresh Dial
3- To use for Chiller Department: If you want to use this compartment as chiller, you must take the sliding part (cover, which is indicated in picture) from closed position to open position and at the same time adjust refrigerator setting as 4°C or 5°C. Thus, temperature of this department has been adjusted as 1-2°C colder than refrigerator compartment's. -
Page 18: Food Placement
FOOD PLACEMENT PART- 3. Cooling Compartment • To prevent humidification and odor formation, the food should be placed in the refrigerator in enclosed cups or with their top being covered. • The hot food and drinks should also be cooled in the room temperature before being placed in the refrigerator. - Page 19 • Please do not refreeze the frozen food once they are thawed. It may pose a danger for your health since it might cause problems such as food poisoning. • Do not place the hot meals in your deep freeze before they become cold. You would cause the other food frozen beforehand in the deep freeze to become putrefied.
- Page 20 In room temperature Storing time Meat and fish Preparing Defrost time (months) -hour- Steak Wrapping in a foil 6-10 Lamb meat Wrapping in a foil Veal roast Wrapping in a foil 6-10 Veal cubes In small pieces 6-10 Lamb cubes In pieces Minced meat In packages without using spices...
- Page 21 In room temperature Vegetables and Storing time Preparing Defrost time Fruits (months) -hour- Take the leaves apart, cut the heart into pieces, and Cauliflower 10 - 12 It can be used as frozen leave it in water with a little lemon juice for a while String beans and Wash and cut to small...
- Page 22 Dairy Products Storing time Storing Conditions Preparing Pastry (months) Packet (Homogenize) Pure Milk – In its own packet In its own packet 2 - 3 Milk It can be left in its original Cheese-excluding package for storing for a short In slices 6 - 8 white cheese...
-
Page 23: Cleaning And Maintenance
PART- 4. CLEANING AND MAINTENANCE • Make sure you have disconnected the plug from the socket before starting the cleaning. • Please do not clean the refrigerator by pouring water in it. • You may wipe the inner and outer parts of your device by using warm and soapy water with a soft cloth or sponge. -
Page 24: Replacing The Light Bulb
Replacing The Light Bulb Replacing the Refrigerator Light Bulb (If the illumination is occured via lamp ) 1. Unplug the unit from the power supply, 2. Remove the screws on each side of the refrigerator lamp cover(A). 3. Change the light bulb (B) with a new one (not more than 15 Watt) 4. - Page 25 PART- 5. SHIPMENT AND REPOSITIONING • Original package and foam may be kept for re-transportation (optionally). • You should fasten your fridge with thick package, bands or strong cords and follow the instructions for transportation on the package for re-transportation. •...
- Page 26 If your refrigerator does not operate; • Is there a power failure? • Is the plug connected to the socket correctly? • Is the fuse of the socket to which the plug is connected or the main fuse blown? • Is there any failure at the socket? To check this, plug your refrigerator to a socket this is surely operating.
- Page 27 • Are the doors of the refrigerator opened very frequently? When the door is opened, the humidity found in the air in the room enters the refrigerator. Especially if the humidity rate in the room is too high, the more frequently the door is opened the faster will be the humidification.
- Page 28 Tips For Saving Energy 1– Install the appliance in a coll, well vantilated room , but not in direct sunlight and not near heat source (radiator, cooker.. etc). Otherwise use an insulating plate. 2– Allow ward food and drinks to cool down outside the appliance. 3–...
- Page 29 THE PARTS OF THE APPLIANCE AND THE PART- 7. COMPARTMENTS This figure has been drawn for information purposes about parts and accessories of the appliance. Parts may vary according to the model of the appliance. 1) Light Sensor 8) Lamb Switch 2) Cooler Glass Shelf 9) Freezer Upper Basket 15) Upper Shelf...
