NO-FROST COMBI REFRIGERATOR
ELEKTRONISCHE NO-FROST
COMBI NO-FROST ÉLECTRONIQUE
ELEKTRONISKT NO FROST COMBI KYLSKÅP
ELEKTRONISK FROSTFRI KOMBIKJØLESKAP
ELECTRONIC
Instruction booklet
FRIGORIFERO
COMBINATO NO FROST
Guida all'installazione e uso
KÜHL-GEFRIERKOMBI
Bedienungsanleitung
RÉFRIGÉRATEUR
Notice d'installation et d'utilisation
FRYS - KYLSKÅP
Bruksanvisning
FRYSER - KJØLESKAP
Bruksanvisning
FC40PXNE4
FC40MNE4
Advertisement
Table of Contents
Related Manuals for Smeg FC40PXNE4
Summary of Contents for Smeg FC40PXNE4
- Page 1 Instruction booklet FRIGORIFERO COMBINATO NO FROST Guida all'installazione e uso ELEKTRONISCHE NO-FROST KÜHL-GEFRIERKOMBI Bedienungsanleitung RÉFRIGÉRATEUR COMBI NO-FROST ÉLECTRONIQUE Notice d'installation et d'utilisation ELEKTRONISKT NO FROST COMBI KYLSKÅP FRYS - KYLSKÅP Bruksanvisning ELEKTRONISK FROSTFRI KOMBIKJØLESKAP FRYSER - KJØLESKAP Bruksanvisning FC40PXNE4 FC40MNE4...
-
Page 3: Table Of Contents
Contents BEFORE USING THE APPLIANCE ..............2 General warnings ......................2 Old and out-of-order fridges or freezers ...............4 Safety warnings ......................4 Installing and operating your fridge ................5 Before using your fridge freezer ...................6 Information on No-Frost technology ................6 USAGE INFORMATION ..................7 Display and control panel .....................7 Operating your fridge ....................8 Super freeze mode ........................8... -
Page 4: Before Using The Appliance
PART - 1. BEFORE USING THE APPLIANCE General warnings WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recom- mended by the manufacturer. - Page 5 - farm houses and by clients in hotels, motels and other res- idential type environments. - bed and breakfast type environments; - catering and similar non-retail applications. • If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service agent or similarly qualified persons in order to avoid a hazard.
-
Page 6: Old And Out-Of-Order Fridges Or Freezers
Old and out-of-order fridges or freezers • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC. Therefore, take care not to harm environment when you are discarding your old fridges.. -
Page 7: Installing And Operating Your Fridge
• Do not place glass bottles or beverage cans in the ice-making compartment as they can burst as the contents freeze. • Do not place explosive or flammable material in your fridge. Place drinks with high alcohol content vertically in the fridge compartment and make sure that their tops are tightly closed. -
Page 8: Before Using Your Fridge Freezer
Before using your fridge freezer • When using your fridge for the first time, or after transportation, keep it in an upright position for at least 3 hours before plugging into the mains. This allows efficient operation and prevents damage to the compressor. •... -
Page 9: Usage Information
PART - 1. USAGE INFORMATION Display and control panel Use of control panel 1. It is cooler set value screen. 2. It is super cooling indicator. 3. It is freezer set value screen. 4. It is super freeze indicator. 5. It is alarm symbol. 6. -
Page 10: Operating Your Fridge
Operating your fridge Super freeze mode How would it be used? • Press freezer set button until Super freeze symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set. During this mode: • Temperature of cooler and super cool mode may be adjusted. In this case super freeze mode continues. -
Page 11: Holliday Mode
Holliday mode How would it be used? • Push "mode button" until holiday symbol appears • If no button is pressed for 1 second. Mode will be set. Holiday symbol will blink 3 times. When mode is set, buzzer will sound beep beep. •... -
Page 12: Screen Saver Mode
Screen saver mode How to use? • This mode will be activated when you press on mode button for 5 seconds. • If no button is pressed within 5 seconds when he mode is active, lights of the control panel will go off. •... -
Page 13: Cooler Temperature Settings
Cooler temperature settings • Initial temperature value for Cooler Setting Indicator is +4 °C. • Press cooler button once. • When you first push this button, the last value appears on the setting indicator of the cooler. • Whenever you press on this button, lower temperature will be set. (+8°C, +6°C, +5°C, +4°C, +2°C, supercool) •... -
Page 14: Accessories
• This appliance is designed for use at an Climate Ambient Temperature ambient temperature within the 16°C - 43°C Class range. Between 16 and 43 (°C) Note: If the temperature of the environment is Between 16 and 38 (°C) higher than 38°C, the freezer partition temperature cannot be adjusted to -22°C and -24°C. -
Page 15: Fresh Dial
open position. 2. To use for Crisper Department: If you want to use this compartment as a crisper, you must take the sliding cover (which is indicated in the picture) from the open position to the closed position. • While this department is used as 0 °C department, keeping food in the chiller compartment instead of the freezer or refrigerator compartment allows food to retain freshness and flavour for longer, while preserving its fresh appearance. -
Page 16: Arranging Food In The Appliance
PART - 3. ARRANGING FOOD IN THE APPLIANCE Refrigerator compartment • Food should be placed to the fridge in closed containers or covered with appropriate material. • Hot food and beverages should be cooled to room temperature before being placed in the fridge. -
Page 17: Cleaning And Maintenance
packaging and do not exceed the storage period. • If the freezer door is left open for a long period of time, frost may form in the freezer obstructing air circulation. To avoid this, unplug the appliance and wait for the ice to melt before cleaning the freezer. -
Page 18: Transportation And Changing Of Installation Position
Replacing The Light Led Please call the service man. TRANSPORTATION AND CHANGING OF PART - 5. INSTALLATION POSITION Transportation and changing of installation position • The original packages and foamed polystyrene (PS) can be retained if required. • During transportation, the appliance should be secured with a wide string or a strong rope. -
Page 19: Before Calling Your After Sales Service
PART - 6. BEFORE CALLING YOUR AFTER SALES SERVICE Check warnings; Your fridge warns you if the temperatures for cooler and freezer are in improper levels or when a problem occurs in the appliance. Warning codes are displayed in the Freezer and Cooler Indicators. - Page 20 If your fridge is not operating: • Is there an electrical fault? • Is your appliance plugged in? • Is the fuse of the socket or the main fuse blown? • Is there a fault with the socket? Examine this by plugging your fridge into a socket which you are sure is working.
-
Page 21: Tips For Saving Energy
• If a problem persists after you have followed all the instructions above, please consult to the nearest Authorised Technical Service Centre. • The appliance you have purchased is designed for domestic use and can only be used at home and for the stated purposes. It is not suitable for commercial or common use. If the consumer uses the appliance in a way that does not comply with this, we emphasise that the manufacturer and the dealer will not be responsible for any repair or failure within the guarantee period. -
Page 22: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE PART - 7. COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. A) Fridge compartment B) Freezer compartment 1) Light sensor 7) Light key 2) Fridge glass shelf 13) Cooling accumulator...
