EKI 1029
IR Audio Transmission Technology |

General Description

The EKI 1029 is a slim multi-channel receiver for narrow-band applications. It is
powered by an environmentally friendly accupack and can be used with head-
phones, stethoset headphones, earphones or induction couplers. The EKI 1029 is
fitted with a squelch and has an energy-saving function.

Features

Multi-channel bodypack receiver
Narrow-band
Powered by BA 1029 accupack, can be recharged in the receiver
Squelch
Energy-saving circuitry
Headphone socket (3.5 mm mono jack) with on/off function
Delivery includes: 1 x EKI 1029 multi-channel receiver
1 x BA 1029 accupack

Recommended Accessories

HD 410 D open headphones
HD 1029 open headphones
TC 2-26 stethoset headphones
TC 2-36 earphone with earbow
L 1029-20 charging case for 20 receivers
L 1029-75 Charging Case for 75 receivers
Plug-in mains unit for charging cases
NT 29 European version
NT 29-120 USA version
NT 29-UK UK version
BA 1029 accupack

Product Variants

EKI 1029 PLL 32: Multi-channel receiver,
32 switchable channels (ch. 0 – ch. 31)
EKI 1029 PLL 16: Multi-channel receiver,
16 switchable channels (ch. 0 – ch. 15)
EKI 1029 PLL 16 H: Multi-channel receiver,
16 switchable channels (ch. 16 – ch. 31)
EKI 1029-12: Multi-channel receiver,
12 switchable channels (ch. 0 – ch. 11)
EKI 1029-7: Multi-channel receiver,
7 switchable channels (ch. 0 – ch. 6)
Receivers

Technical Data (for -PLL 32)

Modulation .................................................narrow-band FM
Carrier frequencies ...................................... 55 – 1,335 kHz
Channels.......................................ch. 0 – ch. 31, switchable
AF frequency response ................................. 50 – 8,000 Hz
THD ...............................................................................typ. 2 %
Min. terminating impedance ........................................25 Ω
Headphone output ...................3.5 mm mono jack socket
Power supply............. BA 1029 accupack, 2.5 V, 170 mAh
Operating time .............................................. approx. 30 hrs
AF signal-to-noise ratio .................................... > 52 dB(A)
Weight .............................................................. approx. 100 g
Cat. No. 002146
Cat. No. 003985

Dimensions of the EKI 1029

Cat. No. 005115
Cat. No. 005116
Cat. No. 003776
Cat. No. 003371
Cat. No. 004002
Cat. No. 004003
Cat. No. 004004
Cat. No. 003708
Cat. No. 004623
Cat. No. 003627
Cat. No. 004622
Cat. No. 003252
Cat. No. 003475
with on/off function
125 mm
60 mm
EKI 1029
