- Page 1 DUBAI SOFA ASSEMBLY GUIDE SCAN ME www.furniturebox.co.uk Scan QR code for more tips, advice and assembly video or visit furniturebox.co.uk/club/dubaisofa...
- Page 2 Important - Please read these instructions fully before starting assembly SAFETY AND NO POWER TOOLS CARE ADVICE SAFETY AND CARE ADVICE • Check you have all the components and • Only clean using a damp tools listed. cloth and mild detergent, do no use bleach or •...
- Page 3 PLEASE CHECK CAREFULLY AND MAKE SURE YOU HAVE ALL FITTINGS AND TOOLS LISTED BELOW BEFORE YOU START. 12PC 12PC NOTE: The quantities above are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. www.furniturebox.co.uk...
- Page 4 STEP Use a clean, flat, soft surface to avoid any bumps or scratches. Start by assembling the corner seat unit. Attach the 2x back rest pieces [B] to the seat [A]. Align the pre-drilled holes. You may find it easier to flip the seat and back rests over as shown in the illustration. Connect using 2 x washers [D] followed by 2x screws [C] on each side of the back rest pieces - 8 in total.
- Page 5 Connect using 6x washers [D] followed by 6x screws [C]. Once all screws are in place, fully tighten with Allen key [F]. Screw in 4x feet [E]. Flip your bench unit over so it sits on its feet. Check stability. www.furniturebox.co.uk...
- Page 6 STEP Add 4x feet [E] to the bottom of the coffee table legs. Flip your coffee table onto its feet and check stability. Your sofa set is now ready to use! Follow us on Instagram @furniturebox_uk...
- Page 7 www.furniturebox.co.uk...
- Page 8 ACTIVATE YOUR GUARANTEE ONLINE scan this QR code with your phone to read the full guarantee on line and register your product. It only takes a moment to fill out. Or visit: furniturebox.co.uk/our-guarantee...
