- Page 1 SAMBA ASSEMBLY GUIDE SCAN ME www.furniturebox.co.uk Scan QR code for more tips, advice and assembly video or visit furniturebox.co.uk/club/samba-tv...
- Page 2 Important - Please read these instructions fully before starting assembly SAFETY AND NO POWER TOOLS CARE ADVICE SAFETY AND CARE ADVICE • Check you have all the components and • Only clean using a damp tools listed. cloth and mild detergent, do no use bleach or •...
- Page 3 PLEASE CHECK CAREFULLY AND MAKE SURE YOU HAVE ALL FITTINGS AND TOOLS LISTED BELOW BEFORE YOU START. NOTE: The quantities above are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. www.furniturebox.co.uk...
- Page 4 STEP Use a clear, flat, soft surface to avoid bumps or scratches. Take top panel [1]. Screw in 6 x dowel rods [A] and 6x rods [B] into holes as shown. Next, make up all 6 of your drawer runners. there are 3 drawers, each with a left and right side boards.
- Page 5 Lock bottom board [8] into place by twisting the cam locks [I1]. Then slot little back board [16] into the grooves on the side and bottom boards. Lower this last drawer onto the rods, as per diagram. www.furniturebox.co.uk...
- Page 6 STEP Lock everything together in place by placing 1 x washer [D] followed by 1 x nut [c] over the ends of the rods, in each of the holes as indicated on diagram. Tighten using spanner [E] provided. STEP Construct your drawers. Connect 1 x left drawer side board [10] and 1 x right drawer side board [11] to 1 x drawer back board [12] using 4x screws [H] as per diagram.
- Page 7 Attach the 4 x glass shelf supports [J] using screw [K]. 2 supports per shelf, front and back, as per diagram. STEP ATTENTION: Carefully slot your drawers into the supports. Your TV stand is now ready to use. www.furniturebox.co.uk...
