Page 1: Table Of Contents
FDC37H Dental Chair Installation Guide Firstar Dental Company 18915 84 Ave. S. Kent, WA 98032 www.firstardental.com E-Mail: technical@firstardental.com Table of Contents Start Here Removing Packaging Dental Chair Installation Chair Upholstery Headrest Cushion Backrest Cushion... - Page 2 Seat Cushion Armrest Cushion Installation Completion Checklist...
- Page 3 FDC-601 Installation Guide Start Here GENERAL INFORMATION Make sure that you follow local building codes and regulations for this installation. They differ from state to state and internationally. Dispose the packaging materials in accordance with current packaging regulations. Also, make sure that the following steps are completed prior to installation. 1.
- Page 4 ● Please make sure to follow instructions on this installation manual. FDC-ED 1604 REV.2...
-
Page 5: Removing Packaging
FDC-601 Installation Guide Removing Packaging Dental Chair Installation 1. Unpack Box A and verify all the components inside match with the inventory list. Make sure all the parts are in good condition with no signs of damage. 2. Use a Philips screw driver to remove 4 shipping screws ④ on the bottom of the wooden shipping pallet ③. - Page 6 ⑧ Connector Pin x 2 ⑨ Set Screw x 2 FDC-601 Installation Guide Dental Chair Dental Chair Movement Control Test FDC-37HC dental chair movement can be controlled by a pre-programmed footswitch. Before moving on to the next step, it is important to check the chair movement functionality. Connect the power cable to the wall outlet and then test the chair movements in the following steps: 1.
-
Page 7: Chair Upholstery
① Dental Chair ② Chair Footswitch Figure 2: Dental Chair Movement Control Testing FDC-601 Installation Guide Chair Upholstery If chair is part of the dental package, wait until the entire installation is complete before installing upholstery. Failure to do so may result in damaging the upholstery. Headrest Cushion 1. -
Page 8: Backrest Cushion
Backrest Cushion 1. Remove the headrest support before doing the backrest cushion installation. 2. Raise the dental chair and the backrest support ② upward with the footswitch. 3. Put the backrest cushion ① on the backrest support and align 4 button studs ④... - Page 9 Seat Cushion 1. Put the seat frame ① on the side of the yoke casting ③. 2. Align two screw holes as indicated on Figure 5. Detail A. 3. Place a washer ④ between the seat frame and the yoke casting. 4.
- Page 10 FDC-601 Installation Guide Installation Completion Checklist Installation Completion Checklist Refer to the user manual for operation of the touchpad and foot control functions. Dental Chair • The rotational brake functions properly. • The touchpad functions correctly. • The headrest stays in position after being adjusted. •...
- Page 11 FDC-ED 1604 REV.2...
