FDC37H Dental Chair User Manual Firstar Dental Company 18915 84 Ave. S. Kent, WA 98032 www.firstardental.com E-Mail: technical@firstardental.com Table of Contents Introduction Unit Dimensions and Technical Data Operation Instruction Dental Chair Cleaning and Maintenance Electromagnetic Compatibility Appendix Wiring Diagram... -
Page 2: Introduction
Dental Chair Required Operating Area Warranty Statement Introduction IEC Symbols Thank you for choosing Firstar Dental products. The following symbols conform to IEC labeling This booklet contains detailed information standards and may be located throughout the about the operation instruction and... - Page 3 ● Protect against impact, vibration and falling is required during transportation and storage. ● Transport and store the boxes upright. ● Storage location shall be well ventilated. Storage environment shall not contain any corrosive gases. Recommended Environment Conditions Classifications Transportation and Storage Environment Medical –...
- Page 4 Maximum Patient Weight 300lbs (136kg) Delivery system capacity 125lbs (57kg) Empty weight 300lbs (136kg) Package weight 396.9 lbs (160kg) Package dimensions 57”L x 32”H x 34”W (145cm x 81cm x 86cm)
-
Page 5: Unit Dimensions And Technical Data
Unit Dimensions and Technical Data Dental Chair A. Dimensions B. Technical Data Hydraulic Liquid Pressure: 5.6MPa (55 kgf/cm Input Supply Power: 115 VAC, 60Hz / 230 VAC, 50Hz/60Hz, as applicable Fuse Size: F1/F2-10A, F3-100mA / F1/F2-6.3A, F3-63mA Maximum Load (including unit): 2450N (250kgf) Control Voltage: 5VDC... -
Page 6: Operation Instruction
Operation Instruction Dental Chair Components ① Adjustable Headrest Cushion ② Back Support ③ Seat ④ Armrest ⑤ Armrest Lock ⑥ “Program” Button ⑦ Chair Rotation Foot Lock ⑧ Foot Switch Headrest Position Adjustment Double Articulating Headrest Height Adjustment Push down or pull up the blade from the chair back to change the headrest to the desired height. - Page 7 Armrest Adjustment The chair’s armrest can be lowered allowing patient to enter and exit from either side of the chair. To lower and raise the armrest: Pull up the armrest lock trigger, push the end of the armrest to lower it. Lift up the arm till you hear a click sound, which secures the arm in its original up position.
- Page 8 Dental Chair Foot Switch Settings Manual positioning of the chair can be done by operating the footswitch or touchpad control located at the delivery system tray. Chair & Back Up or Down Operation ● To move the chair up or down, push and hold the puck on the foot control (Up and down buttons) ●...
- Page 9 Dental Chair Collision Protection System To prevent damage to the chair or other equipment, all FDC dental chairs are equipped with a Collision Protection System. The safety switch located at the bottom of the chair senses the chair contacts an object when the chair is moving down;...
-
Page 10: Dental Chair Cleaning And Maintenance
Remember that barriers should always be changed between patients. Under normal use, your FDC37H dental chair should require no maintenance. In the event of equipment failure or damage you should contact your authorized Firstar Dental representative. Refer to the Firstar Products Cleaning Guide for information on proper cleaning and disinfection guidelines of our products. -
Page 11: Electromagnetic Compatibility
Electromagnetic Compatibility All electrical medical devices are subject to special EMC safety measurements and as a result the equipment must be installed and operate according to the installation instruction manual and the user manual. Portable and mobile RF communications equipment can affect medical electrical equipment. ELECTROMAGNETIC COMPATIBILITY testing has been done for this product. - Page 12 Immunity Test This product is intended for use in the following electromagnetic environment. Users should assure that the product is used in such an environment. IMMUNITY TEST IEC60601 ELECTROMAGNETIC COMPLIANCE LEVEL TEST DATA ENVIRONMENT GUIDANCE Electrostatic ±2, ±4, ±6 kV direct ±2, ±4, ±6 kV direct Floors should be wood, Discharge (ESD)
- Page 13 IMMUNITY TEST IEC 60601 TEST LEVEL COMPLIANCE ELECTROMAGNETIC LEVEL ENVIRONMENT GUIDANCE Conducted RF 3 Vrms 3 Vrms �� = 1. 2 �� IEC 61000-4-6 150 kHz to 80 MHz Radiated RF 3 V/m 3 V/m �� = 1. 2 �� 80MHz 800MHz IEC 61000-4-3 80 kHz to 2.5 MHz...
-
Page 14: Appendix
Appendix Wiring Diagram... - Page 15 Hydraulic Fluid Power Schematics Pump: single phase AC hydraulic motor pump six in one solenoid valve P, A, B, C, R: solenoid valve fittings base movement cylinder back movement cylinder SV1: base up solenoid (fluid supply) SV2: base down solenoid (fluid return) SV3: back down solenoid (fluid supply) SV4:...
- Page 16 Dental Chair Required Operating Area Note: 1. *contoured utility center size and tubing diagrams are shown on the next appendix. 2. *dental chair front clearance space is required to have at least 70cfm away from the wall. 3. Each dental chair required operating area is 9 m...
- Page 17 Warranty Statement All FDC products sold to and installed by dealers are guaranteed to be free from defects in workmanship and materials for one year from date of purchase. Hydraulic motor pump itself has factory warranty of five years. During that period, FDC will replace any defective part at no charge. FDC WILL NOT be responsible for dealer or service company labor charges or shipping charges.
