Summary of Contents for HEIDENHAIN LIP 6031 Dplus
- Page 1 LIP 6031 Dplus Mounting Instructions a i n . d e n h . h e i d w w w x x x x x x x x- x x x x x ID x x x x D p lu 6 0 01 L IP [ ] [ ]...
-
Page 2: Table Of Contents
Contents Contents Basic information........................Safety............................. Items supplied and accessories..................... Mounting..........................Adjustment and diagnosis..................... Removal..........................HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 3 4.2.1 Notes on mounting the linear scale...................... 4.2.2 Materials and tools........................... 4.2.3 Gluing the linear scale..........................4.2.4 Mounting the fixed-point elements......................Mounting the scanning head...................... 4.3.1 Notes on mounting the scanning head....................HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
- Page 4 Connecting an encoder using its ID.................... Connecting the encoder manually....................Using the mounting wizard......................Checking the mounting......................Activating/Deactivating the function display................Removal..........................Safety precautions regarding removal..................Removing the scanning head..................... Removing the scale........................HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
-
Page 5: Basic Information
7 Serial number of scanning head Target groups of the Mounting Instructions The Mounting Instructions must be read and observed by every person who performs any of the following tasks: Design Mounting Removal HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 6: Notes On Reading The Documentation
Have you found any errors or would you like to suggest changes? We are continuously striving to improve our documentation for you. Please help us by sending your suggestions to the following e-mail address: userdoc@heidenhain.de HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 7: Symbols And Fonts Used For Marking Text
Solid contaminants: class 3 Max. pressure dew point: class 4 Bold Identifies elements in figures and illustrations, such as positions, dimensions and worksteps Example: S marks the beginning of the measuring length (ML). HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 8: Notes In This Documentation
The information symbol indicates a tip. A tip provides important additional or supplementary information. The book symbol indicates a cross reference. A cross reference leads to external documentation, for example: further documentation from HEIDENHAIN or another supplier. Units and tolerances Unless otherwise specified, the dimensions stated in these Mounting Instructions are given in millimeters. -
Page 9: Safety
Do not expose the encoder to mechanical stress NOTICE Property damage due to electrical stress Do not engage or disengage any connecting elements while the product is under power Do not touch the contacts of the plug connections HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 10 This device contains electrostatic-sensitive components that can be destroyed by electrostatic discharge (ESD). It is essential to observe the safety precautions for handling ESD-sensitive components Never touch connector pins without ensuring proper grounding Wear a grounded ESD wristband when handling device connections HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
-
Page 11: Items Supplied And Accessories
[ ] [ ] [ ] [ ] DU R OP TO ain .de eid enh ww w.h Operating Instructions Quality Inspection Document XX xxx Qualitätsprüfbescheinigung Quality Inspection Document ID xxxxxxx-xx SN xxxxxxxx x HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 12: Items Supplied With The Scanning Head
3.1.2 Items supplied with the scanning head Component Figure Scanning head a in .d e n h .h e id w w w Spacer shim Operating Instructions Manufacturer's Inspection Document XXX xxx xxxxxxx-xx xxxxxxxxx xxxxxxxxx xxxxxxxxx HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 13: Mounting Accessories
Items supplied and accessories | Mounting accessories Mounting accessories The following accessories can be obtained separately from HEIDENHAIN. For more information on the listed products, please refer to the applicable Mounting Instructions and the Exposed Linear Encoders brochure. www.heidenhain.com/documentation Enter the document ID 208960 3.2.1 For mounting the linear scale... -
Page 14: Mounting
OPTODUR In order to avoid signal interferences, observe the minimum clearance from sources of interference. For more information on sources of interference, refer to the Interfaces of HEIDENHAIN Encoders brochure. www.heidenhain.com/documentation Enter the document ID 1078628 HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 15: Mounting The Linear Scale
Recommended diameter of the stop pins: 3 mm. For a measuring length of ML ≤ 2040, use three stop pins to stabilize the scale ML sufficiently. (ML+10) 0.72 x (ML+10) HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 16: Materials And Tools
For this task, the following materials and tools are needed: Included in delivery To be provided separately Roller Stop pins Fixed-point elements Adhesive 4 screws (DIN 7984 – M3×6) Torque wrench (hexagon socket for 2.5 mm) HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 17: Gluing The Linear Scale
Do not perform further work on the scale until the maximum adhesive force has been reached The maximum adhesive force of the mounting film is reached at room temperature after approx. 70 hours. HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 18: Mounting The Fixed-Point Elements
To ensure high fixed-point rigidity, pay attention to the specifications for curing temperature and curing time. Operating temperature Curing temperature Curing time –10 °C to +30 °C 22 °C 24 hours –10 °C to +70 °C 80 °C 3 hours HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 19: Mounting The Scanning Head
[ ] [ ] [ ] [ ] DU R OP TO in .d en ha he id ww w. ISO 4762 – M2.5 x (a+6) – 8.8 ISO 7092 – 2.7 HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 20 [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] DU R OP TO in .d en ha he id ww w. HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
-
Page 21: Final Steps
[ ] [ ] [ ] [ ] O DU O PT n. de nh ai .h ei de w w w Resistance measurement If necessary, connect the shield with the machine earth (field ground) HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 22: Connecting The Encoder
For more information on the pin layouts, refer to the Cables and Connectors brochure. www.heidenhain.com/documentation Enter the document ID 1206103 For more information on sources of interference, refer to the Interfaces of HEIDENHAIN Encoders brochure. www.heidenhain.com/documentation Enter the document ID 1078628... -
Page 23: Adjustment And Diagnosis
PWM 21 ATS software, version 3.6, with integrated local encoder database for automatic encoder identification. The ATS software is available for download free of charge from the www.heidenhain.com/service/downloads/ software/ area on the HEIDENHAIN website. For more information, see the Exposed Linear Encoders brochure. -
Page 24: Connecting The Encoder Manually
If you cannot connect the encoder using its ID, proceed as described in the "Connecting the encoder manually" chapter. Connecting the encoder manually Double-click Connect the encoder in the function menu The Adjusting and Testing Software displays the Encoder selection dialog. Function menu HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 25 The Adjusting and Testing Software displays the Encoder selection dialog. Encoder selection dialog For more information on the supply voltage and interfaces, refer to the Exposed Linear Encoders brochure. www.heidenhain.com/documentation Enter the document ID 208960 HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
-
Page 26: Using The Mounting Wizard
The Encoder selection dialog with the encoder data Using the mounting wizard The function display is inactive as long as the LIP mounting verification tab is open. Click the Wizards tab Position display tab HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 27 Adjustment and diagnosis | Using the mounting wizard The Wizards selection is displayed. Wizards tab Click the LIP mounting wizard tab on the bottom The message Step 1: Note is displayed. Wizards selection HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
- Page 28 Wizards tab with Step 1: Note message Click Next The message The encoder will be reset to its factory settings is displayed. Wizards tab with Step 2: Mounting the encoder message HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
- Page 29 [ ] [ ] [ ] [ ] [ ] [ ] O D U O P T a in .d e n h .h e id w w w Moiré alignment HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
- Page 30 1) message Traverse reference mark 1 in both directions until "Progress: 100%" has been reached Reference mark 1 and incremental track 1 have now been adjusted. Wizards tab with Step 4: Adjusting message HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
- Page 31 Wizards tab with Step 4: Adjusting the incremental signals and the reference pulse (scanning position 2) message Select Scanning position The signals of the selected scanning position are displayed. Wizards tab with Step 5: Verify the adjustment message HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
-
Page 32: Checking The Mounting
The adjustment was successfully concluded. Wizards tab with Step 5: Verify the adjustment message Checking the mounting Click the LIP mounting verification Verifying the mounting using EnDat 3 is displayed. Wizards tab HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... -
Page 33: Activating/Deactivating The Function Display
Verifying the mounting using EnDat 3 Activating/Deactivating the function display The function display is inactive as long as the LIP mounting verification tab is open. Click the Wizards tab Position display tab HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 34 Click the LIP mounting verification Verifying the mounting using EnDat 3 is displayed. Wizards tab Click the Function display button The Mounting the encoder note is displayed Wizards tab with Function display HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
- Page 35 Adjustment and diagnosis | Activating/Deactivating the function display Click OK The function display is inactive. Repeat the process to activate the function display. Mounting the encoder note HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023...
-
Page 36: Removal
Remove the scanning head in the reversed sequence of mounting. Further information: "Mounting the scanning head", Page 19 Removing the scale Further information can be found in the Disassembly Instructions. www.heidenhain.com/documentation Enter the document ID 1185755 HEIDENHAIN | Mounting Instructions | LIP 6031 Dplus | 05/2023... - Page 37 DR. JOHANNES HEIDENHAIN GmbH Dr.-Johannes-Heidenhain-Straße 5 83301 Traunreut, Germany +49 8669 31-0 +49 8669 32-5061 info@heidenhain.de Technical support +49 8669 32-1000 Measuring systems +49 8669 31-3104 service.ms-support@heidenhain.de NC support +49 8669 31-3101 service.nc-support@heidenhain.de NC programming ...
