Page 1 Safety Light Curtain Type 4 SF4D Series Instruction Manual Contact Ramco Innovations for technical and application support of SF4D series Our email is nsales@ramcoi.com 2016.11 WUME-SF4D-2 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 2 (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 3 Thank you very much for purchasing Panasonic Industrial Devices SUNX's Safety Light Curtain, SF4D series. Please read this Instruction Manual carefully and thoroughly for the correct and optimum use of this product. Kindly keep this manual in a convenient place for quick reference.
Page 4: Table Of Contents
······························66 SF4D-TM1 ············································································68 2-5-9-1 Wiring for Parallel Connection ····································68 2-5-9-2 Wiring for Mixed Series and Parallel Connection ············72 2-6 Adjustment················································································ 76 2-6-1 Beam Adjustment ···································································76 ·······································································80 ·································································81 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 5 6-3-6 Side Mounting with MS-SFD-1-8 and MS-SFB-2 ························· 157 6-3-7 Mounting with MS-SFD-3-6 ···················································· 158 6-3-8 Rear Mounting with MS-SFD-4BG and MS-SFB-2 ······················ 159 6-3-9 Side Mounting with MS-SFD-4BG and MS-SFB-2 ······················· 160 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 6 6-3-10-5 No Dead-Space Beam Adjustment Mounting Bracket MS-SFD-3-6 ······················································· 165 6-3-10-6 SF4B-G Compatible Mounting Bracket MS-SFD-4BG · 166 ···························································· 167 7-1 Glossary················································································· 168 7-2 CE Marking Declaration of Conformity ·········································· 170 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 7: Chapter 1 Introduction
Chapter 1 Introduction 1-1 Safety Cautions ··········································································8 1-2 Applicable Standards / Regulations ················································ 11 ···················································· 12 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 8: Safety Cautions
Before using this device, check whether the device performs properly with the functions and In case of disposal, dispose this device as an industrial waste. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 9 When installing multiple sets of this device, connect the sets and, if necessary, install some barriers such that mutual interference does not occur. For details, refer to “2-3-4 Preventing Mutual Interference”. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 10 Clean this device with a clean cloth. Do not use any volatile chemicals. Others ing in death or serious injury. Do not use this device to detect transparent objects, translucent objects or objects smaller © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 11: Applicable Standards / Regulations
WARNING Since this device has not received “Type Examination” in Article 44-2 of the Industrial Safety and dards / regulations applied in the relevant nation and region. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 12 SF4B-TR25 (ø25 × 220mm) Quick Instruction Manual (Japanese, English, Chinese, Korean) 1 pc. for each language General Information for Safety, Compliance, and Instructions (23 languages) 1 pc. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 13: Chapter 2 Before Using The Device
2-5-9 SF4D-TM1 ·68 2-5-9-1 Wiring for Parallel Connection ····································68 2-5-9-2 Wiring for Mixed Series and Parallel Connection ············72 2-6 Adjustment················································································ 76 2-6-1 Beam Adjustment ···································································76 ·······································································80 ·································································81 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 14: Features
For details on options, refer to “6-2 Options”. 2-2 Parts of the Device Receiver Indicator Emitter Beam axis Indicator Indicator Gray cable (with black line) Indicator Indicator Gray cable © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 15 The status of the receiver is indicated by the indicators. SF4D-TM1 (option) and Con- Please purchase the SF4D-TM1 ware can be downloaded free-of-charge from our website (panasonic.net/id/pidsx/global). <Beam channels> Light emitting elements are arranged in the emitter and light receiving elements are arranged in...
Page 16 2) For details on the blanking function and parallel connection, refer to “3-11 Functions That Can be Set Using the Optional Communication Module SF4D-TM1”. 3) Names in brackets [ ] are names that are indicated on the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 17 Checking basic information Monitoring operations Checking histories such as errors software Collating settings Reading and writing settings Copy function Communication module SF4D-TM1 (option) Saved data initialization function © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 18: Protection Area
<Example of correct sensing area setup> Sensing Protective Dangerous Dangerous area structure part part Sensing area <Example of incorrect sensing area setup> Sensing Sensing Dangerous Dangerous area area part part © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 19: Safety Distance
The safety distance is calculated using the equations given on the following pages when a per- son moves perpendicularly (normal intrusion) into the sensing area of the device. Safety distance S Sensing area Dangerous part Intrusion direction © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 20 Minimum required distance between the sensing area plane and the nearest dan- gerous part of the machine Normally 1,600 (mm/sec.) is used. T = T SF4D SF4D C = 850 (mm) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 21 S = 1,600 × T + 97.6 = 1,600 × 0.4 + 97.6 = 737.6 This meets condition 5) above, and thus the safety distance is 737.6 (mm). © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 22 = 23.8mm = 61.2mm = 129.2mm <Reference> According to ANSI B11.19, D = 900mm (3ft) when d > 63.5mm (2.5 inches). Calculated using 1 (inch) = 25.4 (mm). © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 23 Possible > 20 to 30mm 130mm > 30 to 40mm 240mm Not possible > 40mm 850mm or a safety controller is used, calculate with C = 0. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 24 Distance (sensing range L) between emitter and receiver Permissible installation distance A When 0.2 to 3m 0.131m When 3 to 15m Installation allowed area Installation prohibited area Distance L (m) between emitter and receiver © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 25: Preventing Mutual Interference
For the wiring method, refer to “2-5-9 Wiring for Function Changes Using Optional Com- munication Module SF4D-TM1”. For the setting method, refer to the “SF4D-TM1 User's Manual”. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 26: Preventing Mutual Interference By Device Placement
Receiver Receiver Emitter Emitter Receiver Receiver Emitter 3) Front and back placement 4) With a light-blocking barrier Receiver Receiver Emitter Receiver Emitter Emitter Emitter Receiver Blocking object © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 27 The emitter and receiver cables must be oriented in the same direction. Risk of malfunctioning if the cables are not in the same oriented in the same direction. Cable Cable Cable Cable © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 28: Mounting
Unless otherwise indicated, the mounting procedures that follow are for both the emitter and re- ceiver. Prior to mounting, prepare mounting holes in the mounting surface as described in “6-3 Dimensions”. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 29 [M4 (length 8mm), opposing faces 3mm]. Tighten to a torque of 1.5N·m or less. [M4 (length 8mm), opposing faces 3mm] (Included with Mounting bracket Base bracket © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 30: Ms-Sfd-3-6
Step 3 Install the beam adjustment mounting bracket on the mounting surface with a hexagon- socket head (purchase separately). <MS-SFD-1-5> <MS-SFD-1-6> <MS-SFD-1-8> [M5 (purchase separately)] [M6 (purchase separately)] [M8 (purchase separately)] [M8 (purchase separately)] © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 31 [M4 (length 12mm), opposing faces 3mm]. Tighten to a torque of 1.2N·m or less. For the mounting position of the intermediate supporting bracket, refer to “6-3 Dimen- sions”. This device <Side mounting> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 32 [M5 (purchase separately)]. <Rear mounting> <Side mounting> [M5 (purchase separately)] [M5 (purchase separately)] CAUTION The intermediate supporting bracket MS-SFB-2 is not intended to secure the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 33 Step 2 Partially loosen the hexagon-socket head bolt (M5, black) for light curtain fastening. for light curtain fastening (M5, black) CAUTION Do not remove the hexagon-socket head bolt (M5, black) that fastens the light curtain from this product. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 34 (M5, black) This device CAUTION Firmly fasten the product to the no dead-space beam adjustment mounting bracket. Risk of prod- uct falling and causing injury or product damage. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 35 Step 2 While pushing the product against the hexagon-socket head bolt side, remove the no dead-space beam adjustment mounting bracket. This device No dead-space beam adjustment mounting bracket © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 36: Ms-Sfd-4Bg
[M4 (length 8mm), opposing faces 3mm]. Tighten to a torque of 1.5N·m or less. [M4 (length 8mm), opposing faces 3mm] (Included with MS-SFD-4BG) Mounting bracket Base bracket © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 37 Mounting Step 3 Install the beam adjustment mounting bracket on the mounting surface with a hexagon- socket head bolts (purchase separately). [M5 (purchase separately)] [M8 (purchase separately)] © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 38 SFD-CB05-S 0.5m SFD-CCB3 SFD-CCB7 Discrete wire type SFD-CCB10 8-core SFD-CCB15 SFD-CB05 0.5m Connector type SFD-CB5 SFD-CB10 SFD-CCB3-MU Discrete wire type SFD-CCB7-MU 12-core SFD-CCB10-MU Connector type SFD-CB05-MU 0.5m © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 39 Cable This device Connector Groove Step 2 Tighten the two M2.6 screws. Tighten to a torque of 0.3N·m or less. M2.6 screw (Included with bottom cap cable) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 40: Adding And Removing Sensors (Series Connection)
Fastened with M2.6 screw Not fastened with M2.6 screw 2. Make sure the connector is completely inserted before fastening with the M2.6 screws. Without gap With gap © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 41 Step 3 Tighten the two M2.6 screws. Tighten to a torque of 0.3N·m or less. M2.6 screw M2.6 screw (Included with cable for series (Included with cable for connection) series connection) Sub sensor Main sensor (Bottom) (Top) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 42 Mounting <Removing the series connection cable> Step 1 To disconnect the series connection cable, reverse the procedure for <Connecting the series connection cable>. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 43: Mounting And Removing The Front Protective Cover
Front protective cover (wide type) (option) This device Expand both sides of the front protective cover to the right and left and then remove the cover from the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 44 CAUTION Do not apply excessive force when removing the front protective cover from the device. Doing so may break the cover. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 45: Wiring
5) If surges occur, take countermeasures such as connecting a surge absorber to the source of the surges. 6) The power unit must be a CLASS 2 compliant unit. (When mark compliance is required.) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 46 24V DC (Blue) 0V Internal circuit Users’ circuit Receiver (Brown) +V 24V DC Lockout release input (Blue) 0V Internal circuit Users’ circuit Switch S1 Test input <Reference> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 47 (Pink) Test input (Blue) 0V Internal circuit Users’ circuit Receiver (Brown) +V Lockout release input 24V DC (Blue) 0V Internal circuit Users’ circuit Switch S1 Test input <Reference> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 48 (Pale purple) External device monitor input K1 K2 Lockout release input (Blue) 0V Internal circuit Users’ circuit Switch S1 Test / Reset input Interlock setting input, External device monitor input <Reference> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 49 (Pale purple) External device monitor input K1 K2 (Blue) 0V Internal circuit Users’ circuit Switch S1 Test / Reset input Interlock setting input, External device monitor input <Reference> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 50 (Yellow) Muting input B (Pale purple) External device monitor input K1 K2 (Red) Auxiliary output 2 Lockout release input Load (Gray) NC (Blue) 0V Internal circuit Users’ circuit © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 51 Wiring Switch S1 Test / Reset input <Reference> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 52 Load (Red) Auxiliary output 2 (Pale purple) External device monitor input K1 K2 (Pink) Muting input A (Yellow) Muting input B (Blue) 0V Internal circuit Users’ circuit © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 53 Wiring Switch S1 Test / Reset input <Reference> For wiring, refer to 2-5-4 and following sections. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 54 <Timing chart> Light received Light reception state 50ms or less Light blocked (Note 1) Control output 1 50μs 80μs Control output 2 80μs (Note 2) 50μs 80μs 100μs © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 55: Cable Wiring / Connections / Extension And Connector Pinouts
24V DC Pink Test input Emitter Gray / Gray Blue Pale blue Brown 24V DC White Gray (with Black line) / Receiver Blue Black Black Pale blue © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 56 Connectors for the emitter are gray, and connectors for the receiver are black. For details on cables with a connector on one end and cables with a connector on both ends, refer to “6-2 Options”. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 57: Basic Wiring
*Symbols <Using NPN output> Gray cable (Pink) Test input (Brown) +V 24V DC (Blue) 0V (Brown) +V 24V DC (Blue) 0V Gray cable (with black line) *Symbols © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 58 (Pale purple) External device monitor input (Brown) +V Gray cable (with black line) (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output Cannot be used *Symbols © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 59 (Pale purple) External device monitor input (Brown) +V Gray cable (with black line) (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output Cannot be used *Symbols © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 60: Wiring For Manual Reset (Interlock Is Valid)
(with black line) (Blue) 0V Interlock function Valid (manual reset) External device monitor function Invalid Auxiliary output Not possible *Symbols Switch S1 2) For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 61 (Pale purple) External device monitor input (Brown) +V Gray cable (with black line) (Blue) 0V Interlock function Valid (manual reset) External device monitor function Invalid Auxiliary output Not possible *Symbols Switch S1 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 62: Wiring For Series Connection
(with black line) (Blue) 0V Interlock function Valid (manual reset) External device monitor function Invalid Auxiliary output Not possible *Symbols Switch S1 2) For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 63 (Pale purple) External device monitor input (Brown) +V Gray cable (with black line) (Blue) 0V Interlock function Valid (manual reset) External device monitor function Invalid Auxiliary output Not possible *Symbols Switch S1 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 64 K1 K2 (Brown) +V Gray cable (with black line) (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Valid Auxiliary output Can be used *Symbols © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 65 (with black line) (Pale purple) External device monitor input K1 K2 (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Valid Auxiliary output Can be used *Symbols © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 66 (Red) Auxiliary output 2 (Gray) NC Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output 1 Not possible *Symbols Switch S1 Test / Reset input Switch S2 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 67 (Red) Auxiliary output 2 (Gray) NC Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output 1 Not possible *Symbols Switch S1 Test / Reset input Switch S2 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 68: Sf4D-Tm1
<Using PNP output> Interlock function Valid (manual reset) External device monitor function Valid Auxiliary output 1 Can be used *Symbols Switch S1 2) For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 69 (Pale purple) External device monitor input (Brown) +V (Blue) 0V Gray cable (with black line) (Pink) Muting input A (Yellow) Muting input B (Red) Parallel interference prevention output (Gray) Not used © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 70 Wiring <Using NPN output> Interlock function Valid (manual reset) External device monitor function Valid Auxiliary output 1 Can be used *Symbols Switch S1 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 71 (Pale purple) External device monitor input (Blue) 0V Gray cable (with black line) (Pink) Muting input A (Yellow) Muting input B (Red) Parallel interference prevention output (Gray) Not used © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 72: Wiring For Mixed Series And Parallel Connection
<Using PNP output> Interlock function Valid (manual reset) External device monitor function Valid Auxiliary output 1 Can be used *Symbols Switch S1 2) For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 73 (Pale purple) External device monitor input (Brown) +V (Blue) 0V Gray cable (with black line) (Pink) Muting input A (Yellow) Muting input B (Red) Parallel interference prevention output (Gray) Not used © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 74 Wiring <Using NPN output> Interlock function Valid (manual reset) External device monitor function Valid Auxiliary output 1 Can be used *Symbols Switch S1 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 75 (Pale purple) External device monitor input (Blue) 0V Gray cable (with black line) (Pink) Muting input A (Yellow) Muting input B (Red) Parallel interference prevention output (Gray) Not used © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 76: Adjustment
Step 4 Check the upper application indicator and lower application indicator on the emitter, the operation indicator, the upper application indicator and lower application indicator on the Receiver Upper application indicator Emitter Lower application indicator Normal position Normal position <Vertical misalignment> © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 77 Normal position <Angle deviates to left> <Angle deviates to right> <Reference> For series connection, when all the devices connected in series receive light, the upper and lower © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 78: Beam Adjustment
Do not remove the hexagon-socket head bolt (M5, silver) for beam adjustment from this product. silver) for beam adjustment is loosened, loosen the hexagon-socket head bolt [M5] or hex bolt [M6] securing the no dead-space beam adjustment mounting bracket on the mounting surface. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 79 Stable light reception state: Light intensity / Level 1 Light intensity / Level 2 Stable light reception indicator Digital indicator Stable light reception state: Light intensity / Level 3 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 80 “Chapter 5 Trouble- shooting” and inform your technician. <Reference> If an indicator indicates the light-received state when the test rod blocks light, make sure there are © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 81 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 82 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 83 Lights red indicator the side of the device. 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 84 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 85 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 86 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 87 Light emission intensity control indicator (Note) Test indicator Lights Lights Lights Lights Lights Lights Lights Lights indicator green green green green green green green green DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 88 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 89 Lights Lights Lights Lights Lights Lights Lights Lights indicator green green green green green green green green DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 90 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 91 Lights red indicator the side of the device. 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 92 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 93 Lights orange Lights orange Lights orange indicator Light emission intensity control indicator (Note) Test indicator Lights green Lights green Lights green Lights green Lights green Lights green indicator DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 94 2) The function setting indicator (yellow / orange) lights yellow when the blanking function or parallel con- nection is used, and blinks orange when the communication module SF4D-TM1 (option) is connected. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 95 3) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. 4) For details on yellow blinking or lit numbers in the digital indicator, refer to “Chapter 5 Troubleshoot- ing”. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 96 4) For details on yellow blinking or lit numbers in the digital indicator, refer to “Chapter 5 Troubleshoot- ing”. will not recover automatically). Refer to “Chapter 5 Troubleshooting” to remove the cause of the problem. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 97 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. 3) For details on yellow blinking or lit numbers in the digital indicator, refer to “Chapter 5 Troubleshoot- ing”. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 98 4) For details on yellow blinking or lit numbers in the digital indicator, refer to “Chapter 5 Troubleshoot- ing”. will not recover automatically). Refer to “Chapter 5 Troubleshooting” to remove the cause of the problem. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 99: Chapter 3 Functions
3-11-4 External Device Monitor Function ··········································· 120 ·································································· 121 3-11-6 Application Indicator Function ················································ 122 3-11-7 Muting Function ·································································· 123 ······························································· 125 3-11-9 Protection Function ····························································· 125 3-11-10 Cable Switching Function ···················································· 125 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 100: Self-Diagnosis Function
When using the device with auto-reset, use a safety relay unit or other device to prevent auto- matic restart of the system after safety output shutoff. (EN 60204-1) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 101 14ms 14ms 16ms 16ms 14ms 14ms 193 to 256 16ms 16ms 18ms 18ms <Reference> The conditions for interlock activation can be changed using the communication module SF4D-TM1 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 102: Lockout Release Function
2 sec. or less Normal Lockout <Using PNP output> <Using NPN output> (Brown) (Brown) (Pale blue) (Pale blue) (Blue) (Blue) *Switch S1 *Switch S2 Short circuit Short circuit (Note) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 103: Test Input Function
WARNING Do not use the test input function for the purpose of stopping the machine for which the device is installed. Risk of death or serious injury. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 104 The output operation setting of the auxiliary output can be changed using the communication module SF4D-TM1 Example auxiliary output application check the decrease of received light. blocked), you can check if the interlock can be released by reset. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 105: External Device Monitor Function
<Timing chart (Error 1)> (Note 1) Light received Light received state Light blocked Control output 300ms or less (Note 2) External device monitor input Lockout state © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 106 193 to 256 16ms 16ms 18ms 18ms 2) Using the communication module SF4D-TM1 (option), you can change the allowed response time with- in the range 100 to 600ms. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 107: Muting Function
You can change the time range to 0 to 3 sec. Use the communication module SF4D-TM1 (option) to muting input A and an NC (Normally Closed) type muting sensor to muting input B. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 108 C to muting sensor D must be under 3 sec. Distance between muting sensors C and D (m) < S (m/sec.) x 3 (sec.) Safe zone Danger zone © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 109 Muting input A Muting input B <NPN output type> Muting sensor A Muting sensor C Muting sensor B Muting sensor D Muting input A Muting input B © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 110 A and B for enabling of the muting function. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 111 The override input is shorted to 0V or +V, and the test / reset input is open. (Continuously for 3 seconds) elapses. <Reference> You can set an interval from 60 to 600 sec. in increments of 10 sec. using the communication module SF4D-TM1 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 112 When the muting indicator diagnosis function is invalid, the muting 2) The range depends on the number of beam channels and number of series connections. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 113: Dip Switch Settings
• (Emitter / Receiver) Power save mode Normal mode Power save duce power consumption. (Upper application indicator and lower mode application indicator, Digital indicator / • CAUTION © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 114 Indicators on emitter side Indicators on receiver side Upper application indicator Upper application indicator Lower application indicator Lower application indicator Light emission inten- sity control indicator Frequency indicator Frequency indicator © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 115: Application Indicator Function
(Pale blue) (Pale blue) (Blue) (Blue) *Switch S1 *Switch S2 Application indicator input 1 / 2 Application indicator input 1 / 2 Short circuit (Note) Short circuit © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 116 Application indicator input 1 Synchronization + Gray / Black Application indicator input 2 Brown Auxiliary output 1 Black Pale blue White Blue Pale blue Synchronization + Blue Synchronization - © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 117 (Blue) (Blue) Application indicator / Lights orange <Using PNP output> <Using NPN output> <Application indicator> (Brown) (Brown) (Gray) (Gray) (Gray / Black) (Gray / Black) (Blue) (Blue) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 118: Sf4D-Tm1
When optical synchronization is selected, you cannot specify both the beam axis of the bottom WARNING chine's danger zone from the sensing area of the beam axis. Protection structure Dangerous area © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 119: Floating Blanking Function
0 beam channels 1 beam channel 2 beam channels 3 beam channels 4 beam channels 5 beam channels SF4D-F ø14mm ø24mm ø34mm ø44mm ø54mm ø64mm SF4D-H ø25mm ø45mm ø65mm ø85mm ø105mm ø125mm SF4D-A ø45mm ø85mm ø125mm ø165mm ø205mm ø245mm © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 120: Interlock Function
External device moni- tact "b" of the external device 300ms tor time exceeds the monitor time, the 100 to 600ms (increments of 10ms) device enters the lockout state. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 121 3) The light received / blocked state of the sensing area is output regardless of the functions and states below. • tion, lockout state © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 122: Application Indicator Function
Select one of blue, green, cyan, the override input wire (yel- red, magenta, yellow, invalid Select lights or blinking low) and the device enters the override state © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 123: Muting Function
Any number of beam axes Invalid Exit-only muting Eliminates the need to install a Invalid Valid (Note 2) muting sensor on the exit side. (Exit-only muting) 2) For details, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 124 <Release conditions for muting> The following release conditions change when exit-only muting is used. prox. 20ms or more. When the device changes to the light receiving state. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 125: Protection Function
This depends on the selected patterns with a determined input cable. Cable switching function Invalid signal and non-safety output For details, refer to the “SF4D-TM1 signal. User's Manual”. <Reference> changed. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 126 Functions (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 127: Chapter 4 Maintenance
Chapter 4 Maintenance 4-1 Daily Inspection ······································································· 128 4-2 Periodic Inspection (Every Six Months) ········································· 129 4-3 Inspection after Maintenance ······················································ 129 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 128: Daily Inspection
Dangerous parts remain stopped as long as the test rod is present in the sensing area. Be sure to test operation before using the muting function. Check the condition of the muting indi- cator (dirt, brightness, etc.). © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 129: Periodic Inspection (Every Six Months)
6) When a safety relay unit or external device (forcible guide relay or magnetic conductor) part has been replaced. 7) When safety controller or safety PLC settings are changed. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 130 Maintenance (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 131: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting 5-1 Emitter Troubleshooting ····························································· 132 5-2 Receiver Troubleshooting ·························································· 135 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 132: Emitter Troubleshooting
Frequency indicator <All indicators are turns OFF> Cause Remedy Power is not supplied. Connect the power supply correctly. Set the supply voltage correctly. Connector not connected securely. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 133 Use the muting auxiliary output at a current from 250mA or less. Excessive rush current in the [“ ” blinks] Muting auxiliary output error muting auxiliary output. Replace the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 134 / reset input wire (pink) connected to 0V or +V. Take action as indicated in the troubleshooting for the emitter and receiver. If the problem per- © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 135: Receiver Troubleshooting
Interlock indicator Digital indicator Frequency indicator <All indicators are turns OFF> Cause Remedy Power is not supplied. Connect the power supply correctly. Set the supply voltage correctly. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 136 PLC. error. shorted to each other, or to another input / output wire. Excessive current is flowing 1) wire (black) or control out- © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 137 The voltage of the power sup- Make sure the power supply voltage conforms to [“ ” blinks] plied to the device exceeds the Power supply voltage error © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 138 - wire (orange / black). (orange / black) has shorted or is broken. Take action as indicated in the troubleshooting for the emitter and receiver. If the problem per- © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 139 6-3-10-3 Beam Adjustment Mounting Bracket MS-SFD-1-8 ······· 163 6-3-10-4 Intermediate Support Bracket MS-SFB-2 ·················· 164 6-3-10-5 No Dead-Space Beam Adjustment Mounting Bracket MS-SFD-3-6 · 165 6-3-10-6 SF4B-G Compatible Mounting Bracket MS-SFD-4BG · 166 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 140 (emitter / receiver total) In Japan, do not use this device as safety equipment for a press machine. Please use the model for press machines or shears (paper shears) in Japan. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 141 (emitter / receiver total) In Japan, do not use this device as safety equipment for a press machine. Please use the model for press machines or shears (paper shears) in Japan. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 142 (emitter / receiver total) In Japan, do not use this device as safety equipment for a press machine. Please use the model for press machines or shears (paper shears) in Japan. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 143 Degree of pollution 2,000m or less (Note 4) Withstand voltage AC 1,000V for one minute (between all supply terminals connected together and enclosure) Insulation resistance together and enclosure) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 144 40.5m or less 350mA 50m or less 10.5m or less 100mA 25.5m or less 200mA 25.5m or less 20.5m or less 350mA 25.5m or less 10.5m or less © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 145 12ms 12ms 14ms 14ms 14ms 14ms 14ms 14ms 14ms 14ms 14ms 145 to 192 14ms 14ms 16ms 16ms 14ms 14ms 193 to 256 16ms 16ms 18ms 18ms © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 146 Use to extend a 5-core cable. SFD-CC3-S 5-core SFD-CC10-S Use to extend a 8-core cable. SFD-CC3 8-core SFD-CC10 SFD-CC3-MU Use to extend a 12-core cable. 12-core SFD-CC7-MU SFD-CC10-MU © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 147 Use to connect the device in series. SFD-CSL05 0.5m mend that an at least 0.1m long series connection cable be used. SFD-CSL1 Common for emitter / receiver SFD-CSL5 SFD-CSL10 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 148 Mounting brackets for replacement of a previous ries model with this model. No need to change the mounting hole pitch. Use when installing the device in a location subject to vibration. MS-SFD-4BG © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 149 0.2 to 7.5m 0.8 to 12m FC-SFDH-64-S SF4D-F127 SF4D-H64 SF4D-A32 SF4D-A Both 0.2 to 7m 0.8 to 11m FC-SFDH-72-S SF4D-H72 SF4D-A36 FC-SFDH-80-S SF4D-H80 SF4D-A40 FC-SFDH-88-S SF4D-H88 SF4D-A44 FC-SFDH-96-S SF4D-H96 SF4D-A48 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 150 SF-C21 Various types of safety circuit can be configured by selecting a logic and connecting a safety device. Model No. Remarks SF-LAT-2N Convenient for beam adjustment. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 151 Conversion module that lets you connect a PC to the device to change function settings and monitor the device status. SF4D-TM1 SF4D-TM1 Light Curtain software can be downloaded free-of-charge from our website (panasonic.net/ id/pidsx/global). © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com...
Page 152: Dimensions
SF4D-A40 1,580 1,560 1,590 1,630 1,639 1,646 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,790 1,799 1,806 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,950 1,959 1,966 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 153: Side Mounting With Ms-Sfd-1-5 And Ms-Sfb-2
SF4D-A40 1,580 1,560 1,590 1,630 1,639 1,646 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,790 1,799 1,806 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,950 1,959 1,966 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 154: Rear Mounting With Ms-Sfd-1-6 And Ms-Sfb-2
1,474 1,488 SF4D-H80 SF4D-A40 1,580 1,560 1,590 1,634 1,648 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,794 1,808 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,954 1,968 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 155: Side Mounting With Ms-Sfd-1-6 And Ms-Sfb-2
1,474 1,488 SF4D-H80 SF4D-A40 1,580 1,560 1,590 1,634 1,648 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,794 1,808 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,954 1,968 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 156: Rear Mounting With Ms-Sfd-1-8 And Ms-Sfb-2
1,479 1,495 SF4D-H80 SF4D-A40 1,580 1,560 1,590 1,639 1,655 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,799 1,815 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,959 1,975 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 157: Side Mounting With Ms-Sfd-1-8 And Ms-Sfb-2
1,479 1,495 SF4D-H80 SF4D-A40 1,580 1,560 1,590 1,639 1,655 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,799 1,815 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,959 1,975 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 158: Mounting With Ms-Sfd-3-6
1,260 1,240 1,270 SF4D-H72 SF4D-A36 1,420 1,400 1,430 SF4D-H80 SF4D-A40 1,580 1,560 1,590 SF4D-H88 SF4D-A44 1,740 1,720 1,750 SF4D-H96 SF4D-A48 1,900 1,880 1,910 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 159: Rear Mounting With Ms-Sfd-4Bg And Ms-Sfb-2
SF4D-A40 1,580 1,560 1,590 1,639 1,673 1,694 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,799 1,833 1,854 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,959 1,993 2,014 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 160: Side Mounting With Ms-Sfd-4Bg And Ms-Sfb-2
SF4D-A40 1,580 1,560 1,590 1,639 1,673 1,694 SF4D-H88 SF4D-A44 1,740 1,720 1,750 1,799 1,833 1,854 SF4D-H96 SF4D-A48 1,900 1,880 1,910 1,959 1,993 2,014 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 161: Mounting Brackets
View of arrow A Ultra low-head hex socket bolt [M5 (length 5mm), opposing faces 3mm] View of arrow A [M4 (length 8mm), opposing faces 3mm] 45° 45° © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 162: Beam Adjustment Mounting Bracket Ms-Sfd-1-6
View of arrow A Ultra low-head hex socket bolt [M5 (length 5mm), opposing faces 3mm] View of arrow A [M4 (length 8mm), opposing faces 3mm] 45° 45° © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 163: Beam Adjustment Mounting Bracket Ms-Sfd-1-8
View of arrow A Ultra low-head hex socket bolt [M5 (length 5mm), opposing faces 3mm] View of arrow A [M4 (length 8mm), opposing faces 3mm] 45° 45° © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 164: Intermediate Support Bracket Ms-Sfb-2
Dimensions 22.2 M4 [(length 12), 4-R2.8 opposing faces 3mm] R21.4 30° 4-R2.8 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 165: Ms-Sfd-3-6
Dimensions bolt [M5 (length 18mm), opposing faces 4mm] bolt [M5 (length 28mm), opposing faces 4mm] View of arrow A View of arrow A View of arrow A © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 166: Sf4B-G Compatible Mounting Bracket Ms-Sfd-4Bg
View of arrow A Ultra low-head hex socket bolt [M5 (length 5mm), opposing faces 3mm] View of arrow A [M4 (length 8mm), opposing faces 3mm] 45° 45° © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 167 Chapter 7 Other Information 7-1 Glossary················································································· 168 7-2 CE Marking Declaration of Conformity ·········································· 170 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 168: Glossary
Rod for checking the detection capability of the device. Test rod The size of the rod is equivalent to the minimum sensing object. SDs not operating normally, etc.) has occurred. When the emitter is Lockout © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 169 Abbreviation for Presence Sensing Device Initiation. This is a safety device that restarts the device automatically with- PSDI out operator intervention after the device has detected danger and temporarily halted. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 170: Ce Marking Declaration Of Conformity
CE Marking Declaration of Conformity Itemized Essentials of EC Declaration of Conformity Manufacturer’s Name: Panasonic Industrial Devices SUNX Co., Ltd Manufacturer’s Address: 2431-1, Ushiyama-cho, Kasugai, Aichi 486-0901, Japan EC Representative’s Name: EC Representative’s Address: Product: Model Name: SF4D Series Trade Name: Panasonic...
Page 171 Revision history First edition January 29, 2016 Second edition November 30, 2016 © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 172 (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2016 Ramco Innovations www.PanasonicSensors.com (800) 280-6933...
Page 173 3. DISCLAIMERS (1) Panasonic Industrial Devices SUNX’s sole obligation and liability under this warranty is limited to the repair or re- placement, or refund of the purchase price, of a defective Product, at Panasonic Industrial Devices SUNX’s option.
Page 174 Overseas Sales Division (Head Office): 2431-1 Ushiyama-cho, Kasugai-shi, Aichi, 486-0901, Japan Telephone: +81-568-33-7861 Facsimile: +81-568-33-8591 panasonic.net/id/pidsx/global For sales network, please visit our website. © Panasonic Industrial Devices SUNX Co., Ltd. 2016 November, 2016 PRINTED IN JAPAN WUME-SF4D-2 Ramco Innovations www.PanasonicSensors.com...

This manual is also suitable for:

Sf4d-f series Sf4d-h series Sf4d-a series Sf4d-tm1

Panasonic SF4D Series Instruction Manual

Chapter 1 Introduction

Chapter 2 Before Using the Device

Chapter 3 Functions

Sf4D-Tm1

Chapter 4 Maintenance

Chapter 5 Troubleshooting

Rear Mounting with MS-SFD-1-5 and MS-SFB-2

Side Mounting with MS-SFD-1-5 and MS-SFB-2

Rear Mounting with MS-SFD-1-6 and MS-SFB-2

Side Mounting with MS-SFD-1-6 and MS-SFB-2

Rear Mounting with MS-SFD-1-8 and MS-SFB-2

Side Mounting with MS-SFD-1-8 and MS-SFB-2

Mounting with MS-SFD-3-6

Rear Mounting with MS-SFD-4BG and MS-SFB-2

Side Mounting with MS-SFD-4BG and MS-SFB-2

No Dead-Space Beam Adjustment Mounting Bracket MS-SFD-3-6

SF4B-G Compatible Mounting Bracket MS-SFD-4BG

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic SF4D Series

Summary of Contents for Panasonic SF4D Series

This manual is also suitable for:

Table of Contents
