Page 1 Safety Light Curtain Type 4 Instruction Manual Contact Ramco Innovations for technical and application support of SF4D-xx-01 Our email is nsales@ramcoi.com Ministry of Health, Labour and Welfare approved device 2017.6 Press machines: Model examination No. TA601 (SF4D-F,-H), TA600 (SF4D-A) Shearing machines: Model examination No. TA603 (SF4D-F,-H), TA602 (SF4D-A) WUME-SF4D01-3 Ramco National www.PanasonicSensors.com...
Page 2 (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 3 Thank you very much for purchasing Panasonic Industrial Devices SUNX's Safety Light Curtain, Please read this Instruction Manual carefully and thoroughly for the correct and optimum use of this product. Kindly keep this manual in a convenient place for quick reference.
Page 4 2-5-4 Basic Wiring ··········································································64 2-5-5 Wiring for Manual Reset (Interlock is Valid) ··································67 2-5-6 Wiring for Series Connection ····················································69 ·······71 ······························73 2-6 Adjustment················································································ 75 2-6-1 Beam Adjustment ···································································75 ·······································································79 ·································································81 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 5 6-3-10-5 No Dead-Space Beam Adjustment Mounting Bracket MS-SFD-3-6 ······················································· 159 6-3-10-6 SF4B-G Compatible Mounting Bracket MS-SFD-4BG · 160 ···························································· 161 7-1 Glossary················································································· 162 7-2 CE Marking Declaration of Conformity ·········································· 164 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 6 (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 7 1-1 Safety Cautions ···········································································8 1-2 Applicable Standards / Regulations ················································ 12 ···················································· 14 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 8 In case of disposal, dispose this device as an industrial waste. When using as a safety device for a press machine or paper shearing machine in Japan, always at- tach the protective tube (option) to the cable. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 9 When installing multiple sets of this device, connect the sets and, if necessary, install some barriers such that mutual interference does not occur. For details, refer to “2-3-4 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 10 Clean this device with a clean cloth. Do not use any volatile chemicals. Others ing in death or serious injury. Do not use this device to detect transparent objects, translucent objects or objects smaller © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 11 Machine type Shearing machine with an emergency stop mechanism and restart prevention mechanism Shearing thickness 200mm or less Shearing width 5,000mm or less Blade length 5,500mm or less © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 12 JIS B 9704-1/2 (Type 4), JIS B 9705-1 (Category 4), JIS C 0508-1 to 7 (SIL3) ANSI/UL 61496-1/2 (Type 4) CAN/CSA C22.2 No.14, CAN/CSA E61496-1/2 For the standards in US / Canada, quired. GB 4584 mark © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 13 When only this device is used, or when this device is used in combination with the specified control unit, a different the model examination No. applies. When used in combination with the ing machine. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 14 (ø14 × 220mm), (ø25 × 220mm) Quick Instruction Manual (Japanese, English, Chinese) 1 pc. for each language General Information for Safety, Compliance, and Instructions (23 languages) 1 pc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 15: Table Of Contents
2-5-4 Basic Wiring ··········································································64 2-5-5 Wiring for Manual Reset (Interlock is Valid) ··································67 2-5-6 Wiring for Series Connection ····················································69 ·······71 ······························73 2-6 Adjustment················································································ 75 2-6-1 Beam Adjustment ···································································75 ·······································································79 ·································································81 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 16: Features
Upper application indicator and lower application indicator make beam alignment easy. For details on options, refer to Receiver Indicator Emitter Beam axis Indicator Indicator Gray cable (with black line) Indicator Indicator Gray cable © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 17 Lower application indicator Lower application indicator Emitter: Light emission intensity control indicator Stable light Receiver: reception indicator Function setting indicator Digital indicator Emitter: Test indicator Frequency indicator Receiver: Interlock indicator © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 18 ” Interlock indicator (Yellow) Interlock activated: Lights yellow “ ” ” Notes: 1) In the case of optical synchronization, the upper application indicator and lower application indicator on © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 19 Checking basic information Monitoring operations software Checking histories such as errors Communication module Collating settings (option) Reading and writing settings Copy function Communication module (option) Saved data initialization function © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 20: Protection Area
Bottom Sensing range (effective) Sensing Protective Dangerous Dangerous area structure part part Sensing area Sensing Sensing Dangerous Dangerous area area part part © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 21 The safety distance is calculated using the equations given on the following pages when a per- son moves perpendicularly (normal intrusion) into the sensing area of the device. Safety distance S Sensing area Dangerous part Intrusion direction © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 22 : Maximum response time of machine (sec.) : Response time of device (sec.) SF4D C: Additional distance calculated from the minimum sensing object of the device (mm) C = 850 (mm) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 23 S = 1,600 × T + 97.6 = 1,600 × 0.4 + 97.6 = 737.6 This meets condition 5) above, and thus the safety distance is 737.6 (mm). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 24: Safety Distance
: Additional distance calculated from the minimum sensing object of the device (mm) = 23.8mm = 61.2mm = 129.2mm According to ANSI B11.19, D = 900mm (3ft) when d > 63.5mm (2.5 inches). Calculated using 1 (inch) = 25.4 (mm). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 25 2. Install the auxiliary beam channels (sub sensors) so that they are horizontal with respect to the front line of the bolster, and in a position that is about the height of the worker's waist. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 26 Risk of death or serious injury if auxiliary beam channels (sub sensors) are not in- stalled. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 27 Risk of death or serious injury if auxiliary beam channels (sub sensors) are not in- stalled. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 28 80mm Possible > 20 to 30mm 130mm > 30 to 40mm 240mm Not possible > 40mm 850mm or a safety controller is used, calculate with C = 0. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 29 Distance (sensing range L) between emitter and receiver Permissible installation distance A When 0.2 to 3m 0.131m When 3 to 15m Installation allowed area Installation prohibited area Distance L (m) between emitter and receiver © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 30 When connecting devices in series, connect emitters to emitters and receivers to receivers. If an emitter is connected to a receiver, the device will change to the lockout state. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 31 Emitter Receiver Receiver Emitter Emitter Receiver Receiver Emitter 3) Front and back placement 4) With a light-blocking barrier Receiver Receiver Emitter Receiver Emitter Emitter Emitter Receiver Blocking object © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 32 The emitter and receiver cables must be oriented in the same direction. Risk of malfunctioning if the cables are not in the same oriented in the same direction. Cable Cable Cable Cable © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 33 Unless otherwise indicated, the mounting procedures that follow are for both the emitter and re- ceiver. Prior to mounting, prepare mounting holes in the mounting surface as described in “6-3 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 34 Change the orientation of the mounting bracket, and tighten the two hexagon-socket of 1.5N·m or less. Hexagon-socket head bolt with washer (Included with Mounting bracket Base bracket © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 35 Step 3 Install the beam adjustment mounting bracket on the mounting surface with a hexagon- socket head (purchase separately). < > < > < > Hexagon-socket head bolt Hexagon-socket head bolt Hexagon-socket head bolt Hexagon-socket head bolt © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 36 Step 2 Fit the intermediate supporting bracket onto the side of the device, and fasten with the Tighten to a torque of 1.2N·m or less. For the mounting position of the intermediate supporting bracket, refer to This device © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 37 : 56 or more beam axes, : 28 or more beam axes, one set is required. The intermediate supporting bracket MS-SFB-2 is not intended to secure the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 38 Step 2 Partially loosen the hexagon-socket head bolt (M5, black) for light curtain fastening. Hexagon-socket head bolt for light curtain fastening (M5, black) Do not remove the hexagon-socket head bolt (M5, black) that fastens the light curtain from this product. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 39 (M5, black) This device Firmly fasten the product to the no dead-space beam adjustment mounting bracket. Risk of prod- uct falling and causing injury or product damage. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 40 Step 2 While pushing the product against the hexagon-socket head bolt side, remove the no dead-space beam adjustment mounting bracket. Hexagon-socket head bolt This device No dead-space beam adjustment mounting bracket © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 41 Ultra low-head hex socket bolt for base bracket Change the orientation of the mounting bracket, and tighten the two hexagon-socket head bolts Hexagon-socket head bolt with washer (Included with MS-SFD-4BG) Mounting bracket Base bracket © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 42 Mounting Step 3 Install the beam adjustment mounting bracket on the mounting surface with a hexagon- socket head bolts (purchase separately). Hexagon-socket head bolt Hexagon-socket head bolt © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 43 The length of the bottom cap cable varies by model No. Type Model No. Length Discrete wire type 5-core Connector type 0.5m SFD-CCB3 Discrete wire type 8-core 0.5m Connector type SFD-CCB3-MU Discrete wire type 12-core Connector type 0.5m © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 44 Connector Cable This device Connector Groove Step 2 Tighten the two M2.6 screws. Tighten to a torque of 0.3N·m or less. M2.6 screw (Included with bottom cap cable) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 45 1. Do not run the cable before you have fastened the connector with the M2.6 screws. Fastened with M2.6 screw Not fastened with M2.6 screw 2. Make sure the connector is completely inserted before fastening with the M2.6 screws. Without gap With gap © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 46: Series Connection
Step 3 Tighten the two M2.6 screws. Tighten to a torque of 0.3N·m or less. M2.6 screw M2.6 screw (Included with cable for series (Included with cable for connection) series connection) Sub sensor Main sensor (Bottom) (Top) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 47: Mounting
When using as a safety device for a press machine or paper shearing machine in Japan, always at- tach the protective tube (option) to the cable. Step 1 To disconnect the series connection cable, reverse the procedure for © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 48 About 33mm Step 2 Separate the protective tube as shown below. Step 3 Insert the cable. Step 4 Reinsert the protective tube to restore to its original state. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 49 Front protective cover (wide type) (option) This device Expand both sides of the front protective cover to the right and left and then remove the cover from the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 50 This device remove the cover from the device. Do not apply excessive force when removing the front protective cover from the device. Doing so may break the cover. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 51: Wiring
5) If surges occur, take countermeasures such as connecting a surge absorber to the source of the surges. 6) The power unit must be a CLASS 2 compliant unit. (When mark compliance is required.) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 52 (Brown) +V 24V DC Lockout release input (Blue) 0V Internal circuit Users’ circuit Switch S1 Test input Note: Vs is the supply voltage. K1, K2: Safety relay unit, etc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 53 Internal circuit Users’ circuit Receiver (Brown) +V Lockout release input 24V DC (Blue) 0V Internal circuit Users’ circuit Switch S1 Test input K1, K2: Safety relay unit, etc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 54 Switch S1 Test / Reset input Interlock setting input, External device monitor input Note: Vs is the supply voltage. K1, K2: External device (forcible guide relay or magnetic conductor) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 55 (Blue) 0V Internal circuit Users’ circuit Switch S1 Test / Reset input Interlock setting input, External device monitor input K1, K2: External device (forcible guide relay or magnetic conductor) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 56 (Yellow) Muting input B K1 K2 (Pale purple) External device monitor input (Red) Auxiliary output 2 Lockout release input Load (Gray) NC (Blue) 0V Internal circuit Users’ circuit © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 57 Wiring Switch S1 Test / Reset input Note: Vs is the supply voltage. K1, K2: External device (forcible guide relay or magnetic conductor) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 58 (Gray) NC Load (Red) Auxiliary output 2 (Pale purple) External device monitor input K1 K2 (Pink) Muting input A (Yellow) Muting input B (Blue) 0V Internal circuit Users’ circuit © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 59 Wiring Switch S1 Test / Reset input K1, K2: External device (forcible guide relay or magnetic conductor) For wiring, refer to 2-5-4 and following sections. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 60 50ms or less Light blocked (Note 1) Control output 1 50μs 80μs Control output 2 80μs (Note 2) 50μs 80μs 100μs Notes: 1) Depends on main cycle: 2.6 to 8.9ms © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 61 When using as a safety device for a press machine or paper shearing machine in Japan, always attach the protective tube (option) to the cable. To attach the protective tube, refer to “ A side B side side side © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 62 Blue Pale blue White Brown 24V DC Black Pale purple External device monitor input Gray (with black line) / Receiver Black Synchronization + Synchronization - Blue Pale blue © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 63 Connectors for the emitter are gray, and connectors for the receiver are black. For details on cables with a connector on one end and cables with a connector on both ends, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 64 Gray cable (Pink) Test input (Brown) +V 24V DC (Blue) 0V (Brown) +V 24V DC (Blue) 0V Gray cable (with black line) K1, K2: Safety relay unit, etc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 65 Gray cable (with black line) (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output Cannot be used K1, K2: Safety relay unit, etc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 66 Gray cable (with black line) (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output Cannot be used K1, K2: Safety relay unit, etc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 67 External device monitor function Invalid Auxiliary output Not possible Switch S1 K1, K2: Safety relay unit, etc. Notes: 1) Vs is the supply voltage. 2) For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 68 Interlock function Valid (manual reset) External device monitor function Invalid Auxiliary output Not possible Switch S1 K1, K2: Safety relay unit, etc. Note: For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 69 External device monitor function Invalid Auxiliary output Not possible Switch S1 K1, K2: Safety relay unit, etc. Notes: 1) Vs is the supply voltage. 2) For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 70 Interlock function Valid (manual reset) External device monitor function Invalid Auxiliary output Not possible Switch S1 K1, K2: Safety relay unit, etc. Note: For information on reset, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 71 (with black line) (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Valid Auxiliary output Can be used K1, K2: External device (forcible guide relay or magnetic conductor) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 72 K1 K2 (Blue) 0V Interlock function Invalid (auto reset) External device monitor function Valid Auxiliary output Can be used K1, K2: External device (forcible guide relay or magnetic conductor) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 73 External device monitor function Invalid Auxiliary output 1 Not possible Switch S1 Test / Reset input Switch S2 K1, K2: Safety relay unit, etc. Note: Vs is the supply voltage. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 74 Interlock function Invalid (auto reset) External device monitor function Invalid Auxiliary output 1 Not possible Switch S1 Test / Reset input Switch S2 K1, K2: Safety relay unit, etc. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 75: Adjustment
Receiver Upper application indicator Emitter Lower application indicator Normal position Normal position <Horizontal misalignment> <Vertical misalignment> © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 76 Normal position Normal position <Angle deviates to left> <Angle deviates to right> For series connection, when all the devices connected in series receive light, the upper and lower © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 77 No dead-space beam adjustment mounting bracket Hexagon-socket head bolt (M5, silver) for beam adjustment Do not remove the hexagon-socket head bolt (M5, silver) for beam adjustment from this product. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 78 Digital indicator Step 7 If the stable light reception indicator lights green the device is in the stable light recep- tion state. Stable light reception indicator Digital indicator © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 79 If an indicator indicates the light-received state when the test rod blocks light, make sure there are © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 80 For details, refer to “About the Revision of the Safety Device Management Guidelines for Press Ma- chines” (Ministry of Health, Labour and Welfare Publication 930 No. 11, September 30, 2015). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 81 Notes: 1) The states of the upper application indicator and lower application indicator can also be checked from the side of the device. 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 82 Lights red green green green green Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 83 Notes: 1) The states of the upper application indicator and lower application indicator can also be checked from the side of the device. 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 84 Lights red Lights red Lights red Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 85 Notes: 1) The states of the upper application indicator and lower application indicator can also be checked from the side of the device. 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 86 Lights Lights green green green green Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 87 Note: The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 88 Lights red green green green green Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 89 Note: The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 90 Lights red Lights red Lights red Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 91 Notes: 1) The states of the upper application indicator and lower application indicator can also be checked from the side of the device. 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 92 Lights red Lights red Lights red Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 93 Lights green Lights green Lights green Lights green indicator Note: The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 94 Lights red Lights red Lights red Note: The states of the upper application indicator and lower application indicator can also be checked from the side of the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 95 3) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. 4) For details on yellow blinking or lit numbers in the digital indicator, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 96 3) For details on yellow blinking or lit numbers in the digital indicator, refer to will not recover automatically). Refer to to remove the cause of the problem. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 97 2) The light emission intensity control indicator (orange) lights orange when long mode is selected with the DIP switches. 3) For details on yellow blinking or lit numbers in the digital indicator, refer to © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 98 3) For details on yellow blinking or lit numbers in the digital indicator, refer to will not recover automatically). Refer to to remove the cause of the problem. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 99 3-4 Test Input Function ··································································· 103 ············································ 104 3-6 External Device Monitor Function ················································ 105 3-7 Muting Function ······································································· 107 ·····································································111 3-9 DIP Switch Settings ·································································· 113 3-10 Application indicator function ····················································· 115 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 100: Self-Diagnosis Function
When using the device with auto-reset, use a safety relay unit or other device to prevent auto- matic restart of the system after safety output shutoff. (EN 60204-1) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 101 97 to 127 10ms 12ms 12ms 14ms 14ms 128 to 144 12ms 12ms 14ms 14ms 145 to 192 14ms 14ms 16ms 16ms 193 to 256 16ms 16ms 18ms 18ms © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 102 Lockout (Brown) (Brown) (Pale blue) (Pale blue) (Blue) (Blue) 0 to +2.5V (source current 5mA or less): Short circuit Short circuit (Note) Note: Vs is the supply voltage. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 103: Interlock Function
Note: The range depends on the number of beam channels and number of series connections. Do not use the test input function for the purpose of stopping the machine for which the device is installed. Risk of death or serious injury. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 104 1 / 2 negative logic) Do not use the auxiliary output for the purpose of stopping the machine for which the device is in- stalled. Risk of death or serious injury. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 105 Connect the external device monitor input wire (pale purple) to the auxiliary output wire (red). When the external device monitor function is invalid, external devices cannot be connected to the auxiliary output. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 106 97 to 127 10ms 12ms 12ms 14ms 14ms 128 to 144 12ms 12ms 14ms 14ms 145 to 192 14ms 14ms 16ms 16ms 193 to 256 16ms 16ms 18ms 18ms © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 107: Muting Function
If a muting sensor other than the above is used, the muting function may activate at a time not in- tended by the machine designer and create a risk of death or serious injury. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 108 Muting sensor B Muting sensor D Muting input A Muting input B Muting sensor A Muting sensor C Muting sensor B Muting sensor D Muting input A Muting input B © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 109 Rise operation Top dead point Start of descent Descent operation Safety function valid Safety function invalid Safety function valid Device state (normal operation) (muting function valid) (normal operation) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 110 0.08 sec. or less 0.1 sec. or less 0.14 sec. or less 0.16 sec. or less Muting auxiliary output Light received Light received state Light blocked Control output © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 111 The override input is shorted to 0V or +V, and the test / reset input is open. (Continuously for 3 seconds) elapses. Note: The override function only operates when auto reset is selected (interlock invalid). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 112 When the muting indicator diagnosis function is invalid, the muting 2) The range depends on the number of beam channels and number of series connections. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 113: Dip Switch Settings
DIP switch 4 • (Emitter / Receiver) Power save mode Normal mode Power save duce power consumption. (Upper application indicator and lower mode application indicator, Digital indicator / • © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 114 Upper application indicator Upper application indicator Lower application indicator Lower application indicator Light emission inten- sity control indicator Frequency indicator Frequency indicator © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 115: Application Indicator Function
Application indicator input 1 / 2 Application indicator input 1 / 2 0 to +2.5V (source current 5mA or less): Short circuit (Note) Short circuit Note: Vs is the supply voltage. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 116 Application indicator input 1 Synchronization + Gray / Black Application indicator input 2 Brown Auxiliary output 1 Black Pale blue White Blue Pale blue Synchronization + Blue Synchronization - © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 117 (Gray / Black) (Blue) (Blue) (Brown) (Brown) (Gray) (Gray) (Gray / Black) (Gray / Black) (Blue) (Blue) (Brown) (Brown) (Gray) (Gray) (Gray / Black) (Gray / Black) (Blue) (Blue) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 118 Functions (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 119 4-1 Daily Inspection ······································································· 120 4-2 Periodic Inspection (Every Six Months) ········································· 121 4-3 Inspection after Maintenance ······················································ 122 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 120 Dangerous parts remain stopped as long as the test rod is present in the sensing area. Be sure to test operation before using the muting function. Check the condition of the muting indi- cator (dirt, brightness, etc.). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 121 The current number of operation cycles (time) of parts with a limited service life is less than the number of service life cycles (time). No screws or connectors related to the device are loose. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 122 6) When a safety relay unit or external device (forcible guide relay or magnetic conductor) part has been replaced. 7) When safety controller or safety PLC settings are changed. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 123 5-1 Emitter Troubleshooting ····························································· 124 5-2 Receiver Troubleshooting ·························································· 127 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 124 Stable light reception indicator Test indicator Digital indicator Frequency indicator Cause Remedy Power is not supplied. Connect the power supply correctly. Set the supply voltage correctly. Connector not connected securely. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 125 / output wire. Use the muting auxiliary output at a current from 250mA or less. Excessive rush current in the Muting auxiliary output error muting auxiliary output. Replace the device. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 126 / reset input wire (pink) connected to 0V or +V. Take action as indicated in the troubleshooting for the emitter and receiver. If the problem per- © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 127 Function setting indicator Stable light reception indicator Interlock indicator Digital indicator Frequency indicator Cause Remedy Power is not supplied. Connect the power supply correctly. Set the supply voltage correctly. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 128 (forcible guide relay or magnetic conductor), safety controller, or safety PLC. error. shorted to each other, or to another input / output wire. Excessive current is flowing 1) wire (black) or control out- © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 129 The voltage of the power sup- Make sure the power supply voltage conforms to plied to the device exceeds the Power supply voltage er- © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 130 Synchronization error Cause Remedy If the interlock function is not needed (When auto interlock. reset is used), open the interlock setting input wire (pale purple), and isolate. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 131 - wire (orange / black). (orange / black) has shorted or is broken. Take action as indicated in the troubleshooting for the emitter and receiver. If the problem per- © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 132 Troubleshooting (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 133 6-3-10-3 Beam Adjustment Mounting Bracket ······· 157 6-3-10-4 Intermediate Support Bracket MS-SFB-2 ·················· 158 6-3-10-5 No Dead-Space Beam Adjustment Mounting Bracket MS-SFD-3-6 · 159 6-3-10-6 SF4B-G Compatible Mounting Bracket MS-SFD-4BG · 160 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 134 Weight Approx. 1,900g Approx. 2,300g Approx. 2,800g Approx. 3,200g (emitter / receiver total) : Probability of dangerous failure per hour, MTTFd: Mean time to dangerous failure (in years). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 135 Weight Approx. 3,600g Approx. 4,000g Approx. 4,400g Approx. 4,800g (emitter / receiver total) : Probability of dangerous failure per hour, MTTFd: Mean time to dangerous failure (in years). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 136 Weight Approx. 3,600g Approx. 4,000g Approx. 4,400g Approx. 4,800g (emitter / receiver total) : Probability of dangerous failure per hour, MTTFd: Mean time to dangerous failure (in years). © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 137 10 to 55Hz, 0.75mm double amplitude for two hours each in X, Y, and Z directions Vibration resistance Malfunction resistance 10 to 55Hz, 0.75mm double amplitude 20 times each in X, Y, and Z directions © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 138 25.5m or less 200mA 25.5m or less 20.5m or less 350mA 25.5m or less 10.5m or less Power cable: A bottom cap cable (option) combined with an extension cable (option) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 139 97 to 127 10ms 12ms 12ms 14ms 14ms 128 to 144 12ms 12ms 14ms 14ms 145 to 192 14ms 14ms 16ms 16ms 193 to 256 16ms 16ms 18ms 18ms © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 140 Use to extend a 8-core cable. SFD-CC3 8-core For emitter: Gray connector For receiver: Black connector SFD-CC3-MU Use to extend a 12-core cable. 12-core For emitter: Gray connector For receiver: Black connector © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 141 When using as a safety device for a press machine or paper shearing machine in Japan, always attach the protective tube (option) to the cable. (13mm) (Inner diameter ø9mm) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 142 No need to change the mounting hole pitch. Use when installing the device in a location subject to vibration. MS-SFD-4BG M5 hexagon-socket head bolt: 2 used M8 hexagon-socket head bolt: 1 used Material: SPCC © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 143 0.2 to 7.5m 0.8 to 12m FC-SFDH-64 SF4D-A Both 0.2 to 7m 0.8 to 11m Material: Polycarbonate Note: Avoid using this cover in a place where severe vibration occurs. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 144 Various types of safety circuit can be configured by selecting a logic and connecting a safety device. Model No. Remarks SF-LAT-2N Convenient for beam adjustment. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 145 Conversion module that lets you connect a PC to the device to change function settings and monitor the device status. Light Curtain software can be downloaded free-of-charge from our website ( © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com...
Page 146 1,420 1,400 1,430 1,470 1,479 1,486 1,580 1,560 1,590 1,630 1,639 1,646 1,740 1,720 1,750 1,790 1,799 1,806 1,900 1,880 1,910 1,950 1,959 1,966 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 147 1,420 1,400 1,430 1,470 1,479 1,486 1,580 1,560 1,590 1,630 1,639 1,646 1,740 1,720 1,750 1,790 1,799 1,806 1,900 1,880 1,910 1,950 1,959 1,966 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 148 1,240 1,270 1,314 1,328 1,420 1,400 1,430 1,474 1,488 1,580 1,560 1,590 1,634 1,648 1,740 1,720 1,750 1,794 1,808 1,900 1,880 1,910 1,954 1,968 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 149 1,240 1,270 1,314 1,328 1,420 1,400 1,430 1,474 1,488 1,580 1,560 1,590 1,634 1,648 1,740 1,720 1,750 1,794 1,808 1,900 1,880 1,910 1,954 1,968 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 150 1,240 1,270 1,319 1,335 1,420 1,400 1,430 1,479 1,495 1,580 1,560 1,590 1,639 1,655 1,740 1,720 1,750 1,799 1,815 1,900 1,880 1,910 1,959 1,975 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 151 1,240 1,270 1,319 1,335 1,420 1,400 1,430 1,479 1,495 1,580 1,560 1,590 1,639 1,655 1,740 1,720 1,750 1,799 1,815 1,900 1,880 1,910 1,959 1,975 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 152 Model No. Count SF4D-F SF4D-A SF4D-H 1,100 1,080 1,110 1,260 1,240 1,270 1,420 1,400 1,430 1,580 1,560 1,590 1,740 1,720 1,750 1,900 1,880 1,910 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 153 1,420 1,400 1,430 1,479 1,513 1,534 1,580 1,560 1,590 1,639 1,673 1,694 1,740 1,720 1,750 1,799 1,833 1,854 1,900 1,880 1,910 1,959 1,993 2,014 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 154 1,420 1,400 1,430 1,479 1,513 1,534 1,580 1,560 1,590 1,639 1,673 1,694 1,740 1,720 1,750 1,799 1,833 1,854 1,900 1,880 1,910 1,959 1,993 2,014 Type SF4D-F SF4D-H SF4D-A © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 155 Dimensions (Units: mm) (3.6) t 3.2 View of arrow A Ultra low-head hex socket View of arrow A Hexagon-socket head bolt with washer 45° 45° Material: SPCC © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 156 Dimensions (Units: mm) (3.6) t 3.2 View of arrow A Ultra low-head hex socket View of arrow A Hexagon-socket head bolt with washer 45° 45° Material: SPCC © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 157 Dimensions (Units: mm) (3.6) t 3.2 View of arrow A Ultra low-head hex socket View of arrow A Hexagon-socket head bolt with washer 45° 45° Material: SPCC © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 158 Dimensions (Units: mm) 22.2 4-R2.8 R21.4 30° 4-R2.8 Material: Die-cast zinc alloy © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 159 (Units: mm) Hex socket bolt 18mm), opposing Hex socket bolt 28mm), opposing View of arrow A View of arrow A View of arrow A Material: Die-cast zinc alloy © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 160 Dimensions (Units: mm) (3.6) t 3.2 View of arrow A Ultra low-head hex socket View of arrow A Hexagon-socket head bolt with washer 45° 45° Material: SPCC © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 161 7-1 Glossary················································································· 162 7-2 CE Marking Declaration of Conformity ·········································· 164 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 162 Rod for checking the detection capability of the device. Test rod The size of the rod is equivalent to the minimum sensing object. SDs not operating normally, etc.) has occurred. When the emitter is Lockout © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 163 Abbreviation for Presence Sensing Device Initiation. This is a safety device that restarts the device automatically with- PSDI out operator intervention after the device has detected danger and temporarily halted. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 164 - 2006/42/EC Machinery Directive - 2014/30/EU EMC Directive - 2011/65/EU RoHS Directive - EN 61496-1 - EN 55011 - EN 61000-6-2 - EN 50581 65 80339 München Germany © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 165 First edition November 30, 2016 Second edition March 31, 2017 Third edition June 30, 2017 © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 166 (MEMO) © Panasonic Industrial Devices SUNX Co., Ltd. 2017 Ramco National www.PanasonicSensors.com 1-800-280-6933...
Page 167 (1) Panasonic Industrial Devices SUNX’s sole obligation and liability under this warranty is limited to the repair or re- placement, or refund of the purchase price, of a defective Product, at Panasonic Industrial Devices SUNX’s option.
Page 168 Overseas Sales Division (Head Office): 2431-1 Ushiyama-cho, Kasugai-shi, Aichi, 486-0901, Japan Telephone: +81-568-33-7861 Facsimile: +81-568-33-8591 panasonic.net/id/pidsx/global For sales network, please visit our website. © Panasonic Industrial Devices SUNX Co., Ltd. 2017 June, 2017 PRINTED IN JAPAN WUME-SF4D01-3 Ramco National www.PanasonicSensors.com...

This manual is also suitable for:

Sf4d-f-01 series Sf4d-h-01 series Sf4d-a-01 series Sf4d-f Sf4d-h Sf4d-a

Panasonic SF4D-01 Series Instruction Manual

Section 1

Section 2

Quick Links

Chapters

Need help?

Questions and answers

Summary of Contents for Panasonic SF4D-01 Series

Page 15: Table Of Contents

Page 16: Features

Page 20: Protection Area

Page 24: Safety Distance

Page 46: Series Connection

Page 47: Mounting

Page 51: Wiring

Page 75: Adjustment

Page 100: Self-Diagnosis Function

Page 103: Interlock Function

Page 107: Muting Function

Page 113: Dip Switch Settings

Page 115: Application Indicator Function

This manual is also suitable for:

Panasonic SF4D-01 Series Instruction Manual

Section 1

Section 2

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic SF4D-01 Series

Summary of Contents for Panasonic SF4D-01 Series

This manual is also suitable for:

Table of Contents
