Anthem Owner's Manual
A P R I L 2 0 2 4 | V E R S I O N 1 . 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Anthem 2024 and is the answer not in the manual?

Questions and answers

Related Manuals for Ryvid Anthem 2024

Summary of Contents for Ryvid Anthem 2024

  • Page 1 Anthem Owner’s Manual A P R I L 2 0 2 4 | V E R S I O N 1 . 4...
  • Page 2 The manual serves as a reference, so please consult your actual Anthem for information on appearance, functionality, and performance. To ensure optimal performance and longevity, use only Ryvid approved components and accessories on your motorcycle.

  • Page 3: Table Of Contents

    Table of Contents Anthem Details Worksheet Anthem Features and Controls Storage and Accessories Pre-Ride Checks An Important Message from Ryvid Exterior Overview Additional Accessories Information Carrying Capacity and Loading California Proposition 65 Controls Display General California Perchlorate Advisory Power Button...

  • Page 4: An Important Message From Ryvid

    Anthem. You are now a part of the growing Ryvid community! To ensure the best performance of your Anthem over its lifetime and that Ryvid can contact you if necessary, please be certain that your Anthem is registered with Ryvid. If you have questions, please contact Ryvid (see page 101 for contact info.)

  • Page 5: California Proposition 65

    For more information go to: www.P65Warnings.ca.gov/passenger-vehicle. California Perchlorate Advisory WARNING: Certain components of this Ryvid Anthem such as lithium batteries may contain perchlorate material. Special handling may apply for service or end of life disposal. See www.dtsc.ca.gov.

  • Page 6: About This Manual

    About This Manual Emissions Information This manual covers the features and operation of the Ryvid Anthem motorcycle. The terms The Ryvid Anthem is a true freeway-capable, zero emissions vehicle under California Air “right” or “left” reference right or left as viewed by a rider seated on the Anthem.

  • Page 7: General Safety Precautions

    General Guidelines • The Ryvid Anthem is a powerful motorcycle that requires extreme caution when operating. • To reduce the risk of injury, wear the proper safety gear, including a helmet, eye protection, riding boots, gloves, and protective clothing. •...

  • Page 8: Important Operating Information

    WARNING: CAUTION: • Modifying the Anthem can make the motorcycle unsafe and may result in severe injury. Ryvid • When stopping on an incline, do not prevent rollback using the throttle, as this generates is not responsible for non-approved alterations or modifications.
  • Page 9 Important Battery Conditioning CAUTION: Battery conditioning and balance is of the upmost importance. Before riding, it is necessary to fully charge your battery on receipt of your Anthem, or after any period of storage longer than 15 days. A full charge is 85.3+ or more volts indicated on the display. During shipping or storage of 15 days or longer, slight imbalance can develop between the cells of the battery pack.

  • Page 10: Important Placards And Markings

    Vehicle Identification Number VIN NUMBER LOCATED HERE The following breakdown of the VIN will help you understand the significance of each digit or character in case you need to reference it when contacting Ryvid or ordering parts. VIN Digit WMI:...
  • Page 11 Model Year Code EPA Mfg COde Ind. Sector Code Battery Type Code Mfg Defined Code 2023 Ryvid Highway Motorcyle Lithium Ion Anthem Important Placecards & Markings...

  • Page 12: Ryvid Motor Label

    Ryvid Motor Label The motor serial number is located on the Ryvid motor label. The motor number may be needed for registration in some states. R A 0 0 0 0 1 Important Placecards & Markings...

  • Page 13: Anthem Features And Controls

    Exterior Overview Throttle Mirrors Front Brake Regen Button Display Page 37 Left Controls Page 37 Right Controls Page 41 Page 27 Page 27 Front Signals Storage Adjustable Seat Page 35 Page 39 Page 85 Power Button Anthem Features and Controls Taillight Page 29 Headlight...

  • Page 14: Controls

    Controls Left Control Right Control 1. Reverse (Momentary, hold to engage) 7. Hazard Flasher (Press On/Press Off) 2. High Beam (Press to engage) 8. Normal/Sport Mode Switch (Press to change) 3. Turn Signal Switch (Does not need press to cancel) 9.

  • Page 15: Power Button

    Power Button Motor Stop The Power button is used to power on and The Motor Stop button will stop the motor off the Anthem. The power button has an from receiving power to drive the motor and indicator light around the circumference of the deactivate the throttle functionality.

  • Page 16: Mode

    Mode Eco Mode Sport Mode In this mode, the motor’s current is limited Sport Mode (“S”) unlocks the maximum to 74 Amps, which will limit acceleration performance of the Anthem. This allows while still allowing the vehicle to reach its quicker acceleration and a higher top speed maximum speed.

  • Page 17: Reverse

    Reverse Seat Height Control Press and hold the “R” button while turning the The Anthem’s seat height can be commanded throttle to move the Anthem in reverse. Speed up or down with this three-position switch. See and torque are limited in this mode. A red “R” page 85 for more details on the functionality will appear on the display when in reverse.

  • Page 18: Hazard Flasher

    Hazard Flasher Headlight Adjustment Pressing the Hazard Flasher button will The angle of the Anthem headlight can be flash both front and both rear turn signals adjusted by turning the adjuster knob, located simultaneously. Pressing the Hazard Flasher under the headlight and above the front fender. button again deactivates the feature.

  • Page 19: Braking

    Regenerative Braking Braking Regenerative braking allows for the recovery of electrical energy during breaking by using the electric motor as an electric generator, which slows down the motorcycle. Mechanical Braking In the Anthem, regenerative braking (known as regen) is The right brake lever activates the mechanical automatically applied in Eco Mode (“E”) when the throttle brake on the front wheel.

  • Page 20: Storage And Accessories

    Storage and Accessories Miscellaneous Storage Accessories Mounting The Anthem is equipped with a small storage The Anthem’s frame has 4 pre-threaded, M6 compartment for miscellaneous items. The holes on each side of the frame for mounting storage compartment is lockable by key and various accessories.

  • Page 21: Additional Accessories Information

    Power Controller Controls Left Control Right Control 1. Reverse / Cruise Control (Press to engage, see following page for details) 7. Hazard Flasher (Press On/Press Off) 2. High Beam (Press to engage) 8. Normal/Sport Mode Switch (Press to change) 3. Turn Signal Switch (Does not need press to cancel) 9.
  • Page 22 Power Controller Controls Right Hand Control The bottom left button on the right hand control no longer has a designated function due to the combination of the reverse and Reverse / Cruise Control cruise control. While stopped, press and hold the “R/CC“ button while turning the throttle to move the Anthem in reverse.

  • Page 23: Display Indicators

    When doing so, ensure that the throttle is fully closed. If this fails to Unused Indicators clear the warning, or if the warning reoccurs repeatedly after clearing, contact Ryvid Service. Unused Indicators – Please note that there are unused indicators on the display.

  • Page 24: Display Operation And Settings

    Short press then hold the “mute” button to remotely power on the Anthem • Change units from Miles to Kilometers: During the startup screen (Ryvid logo on a black back ground) press and hold the lower left button ( ) for at least 3 seconds.

  • Page 25: Battery

    When charging your Anthem, always prioritize safety and follow these precautions to avoid potential risk of electrical shock: • Use Ryvid-provided charging equipment or third-party equipment approved for use by Ryvid. Please direct third-party equipment questions to hello@ryvid.com. • Do not use charging equipment if it shows any sign of damage such as frayed or exposed Battery wires.
  • Page 26 If the battery has an abnormal noise, smell, rupture, deformation, color change, signs of • Keep the battery away from fire, heat, or water. melting, heat, or water inflow, please notify Ryvid and stop usage of the battery immediately. Place the battery in an open space outside, away from people and pets. •...

  • Page 27: Charging And Maintaining Your Battery

    Proper maintenance of the Anthem’s battery is critical for its longevity. To help you maintain your Leaving the battery at a low state of charge for a prolonged period could damage it and may battery, Ryvid offers the following guidelines for proper charging and usage: not be covered under your warranty.

  • Page 28: Charging Components

    110V cord (with NEMA 515R connector), your Anthem will charge from empty to 80% in about 2.3 hours and to 100% in 3.25 hours. Using the Ryvid J-Plug accessory, or optional 220V cord (with NEMA 1450R connector) charge time from empty to 80% is reduced to approximately 1.3 hours and to 100% in approximately 1.85 hours.

  • Page 29: Charging Instructions (Battery Attached)

    Charging Instructions (Attached to Anthem) Insert Charge Cable The Anthem battery may be charged while mounted to the bike, or separately from the bike. To begin charging the battery on the bike, simply connect the charge cord to a power source. The charger will then engage, and the charger fan will operate.

  • Page 30: Charging Instructions (Battery Removed)

    Charging Instructions (Removed from Anthem) When the battery is off the bike, raise the luggage handle to view the battery SOC indicator. Pressing the power button will activate red LED indicators corresponding to the battery’s state of charge: 1 red light = 0-25% 2 red lights = 26-50% 3 red lights = 51-75% 4 red lights = 76-100%...

  • Page 31: Battery Life

    Battery life is dependent on many factors, including charge cycles, high temperatures, storage conditions, cell design, and more. Ryvid has designed the Anthem battery to balance battery life, vehicle performance, and usability. Your specific use will impact the battery’s life expectancy;...

  • Page 32: Battery Removal, Installation, And Handling

    Battery Removal, Installation, and Handling The Anthem features an easy-to-release battery which can be removed for charging or storage without the use of tools. The battery also features a secondary safety latch, a battery-presence safety switch, and a combination security lock. WARNING: •...

  • Page 33: Battery Lock

    Battery Lock Suitcase Handle Release Red Secondary Latch Top Handle The battery is equipped with a combination lock to help prevent theft. A combination lock also Battery Lock has the added benefit of not requiring a physical key, which could be lost Primary Latch Frame Top Hook Red Latch...
  • Page 34 Resetting The Battery To perform a battery reset: 1. Remove the battery from your Anthem. (refer to page 69 for the battery removal process) 2. Pull the red release tab and lift up the transport handle. 3. Locate the battery power button on the top of the battery, beneath the transport handle. 4.
  • Page 35 Removing the Battery from the Bike: Set the combination lock to the unlocked Primary Latch: Pull the red latch Use one hand to support the battery Secondary Latch: Reach your other code and rotate the lock 90 degrees release trigger forward. from the front handle (located just below hand through the battery side handle counterclockwise.
  • Page 36 Removing the Battery from the Bike: DISCONNECT DATA CABLE FROM IN-LINE PLUG: Slowly lower the front of the battery to Open the cable access door on the left Disconnect Cables: Disconnect the power, ground, and data cables. Note that the positive the ground.
  • Page 37 Removing the Battery from the Bike: Page 81 for moving the battery when off of the Ryvid Anthem. Page 113 for storage of the battery. Close the cable access door. Please do not With the front wheels of the battery lose the cable access door.
  • Page 38 Installing the Battery on the Bike: Ensure that the combination lock is Position the battery underneath the With hands securely on the forward handle unlocked and rotated 90 degrees motorcycle. The omnidirectional wheels and side handles, tilt the battery forward counterclockwise.
  • Page 39 Installing the Battery on the Bike: Open the cable access door on the left Connect the Battery Cables: Connect the Connect the Data Cable: Reconnect the black data cable with the in-line connector. side of the battery by pushing on the discharge cables first.
  • Page 40 Installing the Battery on the Bike: Lift the front of the battery up, rotating Primary Latch: Lift the primary latch Primary Latch: Close the primary latch Rotate the combination lock 90 degrees it around the lower frame pin, until the handle upwards to allow the latch to handle by pushing it downward until clockwise and scramble the code to lock...
  • Page 41 Moving the Battery When Off the Bike: Due to the weight of the battery, it is ideal to move the battery on the ground and avoid lifting it when possible. The battery attachment to the bike was designed in a way such that the full weight of the battery does not need to be lifted to remove it from or attach it to the bike.
  • Page 42 Moving the Battery When Off the Bike: To extend the battery luggage handle: To stow the battery luggage handle: To stow the battery luggage handle: Rotate the battery handle until you hear a Pull the red handle release trigger and With the battery handle in the down position, click, at which point the handle is locked rotate the battery handle forward.

  • Page 43: Adjustable Seat

    The Anthem is equipped with an electronically adjustable seat to accommodate riders of various heights. Seat height ranges from 30 in (76.2 cm) to 34 in (86.4 cm) from the ground. Although the seat height is adjustable while riding, Ryvid recommends that the seat height is adjusted while stationary.

  • Page 44: Suspension Settings

    Suspension Settings Front Suspension The front suspension dampening is adjustable at the top of each fork cap using a flat head screwdriver. There are a total of 30 clicks of dampening adjustment. Rotating clockwise will make dampening harder and rotating counterclockwise will make dampening softer. When adjusting The Anthem is equipped with suspension components that can be adjusted to suit the rider’s comfort preferences.

  • Page 45: Pre-Ride Checks

    Check the following items each time before riding your motorcycle. Do not ride your motorcycle unless all Headlights, Turn Signals, and Ensure headlights, turn signals, and brake lights are conditions below are satisfied. In the event that an item does not pass the check, contact Ryvid Service or a professional motorcycle technician. Brake Lights functioning properly.

  • Page 46: Carrying Capacity And Loading

    General WARNING: Overloading or improper loading can cause a crash in which you could be seriously hurt or killed. Observe all load limits and loading guidelines in this manual. Your Anthem has been designed to carry the rider, one additional passenger, and limited cargo. When you carry cargo, you may feel some difference during acceleration and braking, but if you keep your motorcycle well-maintained, with good tires and brakes, you can safely carry loads within the limits and guidelines outlined below.

  • Page 47: Loading Guidelines

    Loading Guidelines • Consider aerodynamics: Large, bulky items can catch the wind and make your bike more difficult to handle, especially at high speeds. • Securely attach cargo: To prevent loose items from creating a hazard, make sure that all cargo is tied down securely.

  • Page 48: Maintaining Your Anthem

    Maintaining Your Anthem Use the charts below to keep track of your Anthem’s service needs. If you have questions about any maintenance procedures, please contact Ryvid Service. Always operate within your personal technical abilities or seek assistance from a professional motorcycle technician.
  • Page 49 Every 500 miles 3,000 miles 6,000 miles 10,000 miles Item Routine Every Ride or 1 month or 12 months or 18 months or 24 months Belt Tension Verify belt tension using the tensioner tool Check level using sight glass on handlebars, Brake Fluid add more fluid if below minimum level Brake Fluid...
  • Page 50 Every 500 miles 3,000 miles 6,000 miles 10,000 miles Item Routine Every Ride or 1 month or 12 months or 18 months or 24 months Measure and ensure at least 3mm (0.1in) of Brake Pads friction material is remaining Brake Lever Ensure minimal free play Turn Signals Ensure function in both directions...
  • Page 51 Every 500 miles 3,000 miles 6,000 miles 10,000 miles Item Routine Every Ride or 1 month or 12 months or 18 months or 24 months Wheels Check for damage Check tread depth, if below 2mm; replace tire. Tires Ensure filled to correct PSI Ensure smooth operation along full range of Steering Mechanism motion.

  • Page 52: Wheels And Tires

    Wheels and Tires Tire Inflation Inspect both wheels for the following: • Bends or cracks. CHECK MANUFACTURING LABEL • Impact marks. Inspect both tires for the following: 0000000000000000 • Cuts, cracks, splits, or missing tread lugs in the tread or sidewall area. •...

  • Page 53: Tire Replacement

    Tire Replacement The tires that are equipped with the Anthem were specified to provide the best overall riding experience. Tire specifications approved by Ryvid can be located on the FMVSS label for your Anthem (refer to FMVSS label below). WARNING: Tires other than those originally equipped on the Anthem may cause adverse handling and performance characteristics.

  • Page 54: Brakes

    Brakes Brake Fluid Replacement The fluid level in the reservoirs may drop slightly during normal Brake fluid must be replaced every 12 months regardless of the distance the motorcycle has been use as a result of brake pad wear but should not be allowed to ridden.

  • Page 55: Cleaning Your Anthem

    Cleaning Your Anthem After washing the motorcycle, allow all electrical components to dry before operation. If the motorcycle is ridden after being washed, use caution, and allow extra distance when braking initially, as moisture could remain on the brake pads. To prolong the life of your motorcycle, wash it periodically, as doing so helps ensure that safety- CAUTION: Improper cleaning can damage electrical components, cowlings, panels, and other...

  • Page 56: Tie Down Instructions

    Tie Down Instructions Tie Down Process Position the ramp and secure it with a tie down strap to prevent it from sliding out of position Items Needed during the loading process. With the help of a friend/spotter, push your Anthem into position on the trailer or truck bed •...

  • Page 57: Parking And Long-Term Storage

    To prolong the life of your battery, store your motorcycle in a cool area, as storing it in a hot area will shorten the battery life. The recommended storage temperature is +32°F (0°C) to 85°F (29°C). • CAUTION: Only charge the battery using provided Ryvid charger and cables. Maintaining Your Anthem...

  • Page 58: Customer Information

    Customer Assistance Please have the following available when contacting Ryvid, as this information is essential to answer your questions effectively and efficiently or resolve your concerns. • Owner’s name and address • Owner’s telephone number • Vehicle identification number (VIN) •...

  • Page 59: Reporting Safety Defects

    However, NHTSA cannot become involved in individual problems between you and Ryvid Inc. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at: 1-888-327-4236 (TTY: 1-800-424-9153);...
