4.Address code setting

If you use a universal DMX controller to control the units, you have to set DMX
address from 1 to 512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Settings, press the
ENTER button to confirm, use the UP/DOWN button to select DMX Address,
press the ENTER button to confirm, the present address will blink in the display,
use the UP/DOWN button to adjust the address from 001 to 512, press the
ENTER button to store. Press the MENU button back to the last menu or let the
unit idle 30 seconds to exit menu mode.Please refer to the following diagram to
address your DMX512 channel for the first 4 units.
Channel UNIT1 UNIT2 UNIT3 UNIT4
MODE ADDERSS ADDERSS ADDERSS ADDERSS
31CH 1 32 63 94

5.Fixture size
