IDG30(H,L)AV4-(F,N)**(C,D,J)(-R)-X032
IDG50(H,L)AV4-(F,N)**(C,D,J)(-R)-X032
IDG60(L,S)AV4-(F,N)**(C,D,J)(-R)-X032
IDG75(L,S)AV4-(F,N)**(C,D,J)(-R)-X032
IDG100(L,S)AV4-(F,N)**(C,D,J)(-R)-X032
F
PRODUCT NAME
Membrane Air Dryer
MODEL / Series / Product Number
IDG3(H)V4-(F,N)**(C,J)(-R,S)-X032
IDG5(H)V4-(F,N)**(C,J)(-R,S)-X032
IDG10(H)V4-(F,N)**(C,D,J)(-R)-X032
IDG20(H)V4-(F,N)**(C,D,J)(-R)-X032
Doc. no. DOC1074092
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SMC Networks IDG3 V4-X032 Series
Summary of Contents for SMC Networks IDG3 V4-X032 Series
- Page 1 Doc. no. DOC1074092 PRODUCT NAME Membrane Air Dryer MODEL / Series / Product Number IDG3(H)V4-(F,N)**(C,J)(-R,S)-X032 IDG5(H)V4-(F,N)**(C,J)(-R,S)-X032 IDG10(H)V4-(F,N)**(C,D,J)(-R)-X032 IDG20(H)V4-(F,N)**(C,D,J)(-R)-X032 IDG30(H,L)AV4-(F,N)**(C,D,J)(-R)-X032 IDG50(H,L)AV4-(F,N)**(C,D,J)(-R)-X032 IDG60(L,S)AV4-(F,N)**(C,D,J)(-R)-X032 IDG75(L,S)AV4-(F,N)**(C,D,J)(-R)-X032 IDG100(L,S)AV4-(F,N)**(C,D,J)(-R)-X032...
- Page 2 Contents Safety Instructions Limitations of Use Maintenance Specifications...
- Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 2. Limitations of Use Design Selection Warning Caution 1. Depending on the model and operating conditions, the 1. Consider the purge air flow rate. oxygen ratio of the outlet air may drop. Find the purge air flow rate from the charts and calculate Do not use standard dew point –40°C (symbol: L) type, the “required outlet air flow rate + purge air flow rate”.
- Page 6 Mounting Piping Warning Dew point checker 1. Check for locking of case and body. When using in a unit, be sure to set the air pressure to zero Plug before using a mist separator or micro mist separator with ∗ Please modular connections.
- Page 7 Air Supply Operating Environment Caution Caution 1. Compressed air supply capacity 1. Do not use at temperatures (fluid or ambient An air source that has a supply capacity that is larger than temperatures) higher than the prescribed operating the “required outlet air flow rate (dry air flow rate) + purge conditions.
- Page 8 3. Maintenance Caution 1. Confirm that the equipment’s pressure is at zero and Service Parts no longer in a pressurized state before removing any parts or piping. Performing any work while pressure Table. Membrane module kit and Dew point indicator kit remains in the equipment may lead to injury or Name Membrane module...
- Page 9 4. Specifications 1) Standard dew point: -20 C, -15 Specifications Model IDG3V4 IDG5V4 IDG10V4 IDG20V4 IDG30AV4 IDG50AV4 IDG3HV4 IDG5HV4 IDG10HV4 IDG20HV4 IDG30HAV4 IDG50HAV4 Mist separator AFM20-A AFM30-A AFM40-A AFM20-A AFM30-A AFM40-A Micro mist separator AFD20-A AFD30-A AFD40-A AFD20-A AFD30-A AFD40-A Note4) Note4) Note4)
- Page 10 Revision history 1st edition: March 2024 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
