Bosch Sensortec"| BST-BMP581-DS004-02
BMP581
Barometric Pressure Sensor
BST-BMP581-DS004-02
Document revision
Document release date
Document number
Sales Part Number
Notes
Modifications reserved | Data subject to change without notice
1.2
January 2022
BST-BMP581-DS004-02
0 273 017 025
Data and descriptions in this document are subject to change without notice. Product
photos and pictures are for illustration purposes only and may differ from the real
product appearance.
1 | 74
Document number: BST-BMP581-DS004-02
