This appliance shall be installed in accordance with:
• Manufacturer's Installation Instructions
• Current AS/NZS 3000
• Local Regulations and Municipal Building Codes including local OH&S requirements
This appliance must be installed, maintained and removed only by an Authorised Person.
For continued safety of this appliance it must be installed and maintained in accordance
with the manufacturer's instructions.
Installation Manual
Slim Four-Way Cassette
RINNAI SLIM FOUR-WAY CASSETTE MODELS
Indoor
CIN070R
CIN100R
CIN120R
CIN140R
Outdoor
DONSR07Z72
DONSR10Z72
DONSR12Z72
DONSR14Z72
Advertisement
Table of Contents
Related Manuals for Rinnai CIN070R
Summary of Contents for Rinnai CIN070R
- Page 1 Installation Manual Slim Four-Way Cassette RINNAI SLIM FOUR-WAY CASSETTE MODELS Indoor Outdoor CIN070R DONSR07Z72 CIN100R DONSR10Z72 CIN120R DONSR12Z72 CIN140R DONSR14Z72 This appliance shall be installed in accordance with: • Manufacturer’s Installation Instructions • Current AS/NZS 3000 • Local Regulations and Municipal Building Codes including local OH&S requirements This appliance must be installed, maintained and removed only by an Authorised Person.
-
Page 2: Table Of Contents
Table of Contents Installation Manual Accessories ............ 04 Safety Precautions ........05 Installation Overview ....... 07 Indoor Unit Installation Indoor Unit Installation ......08 ......07 a. Indoor Unit Parts .........08 b. Indoor Unit Installation Instructions ..09 Outdoor Unit Installation ...... - Page 3 Refrigerant Piping Connection ..... 1 . . A. Notes on Pipe Length and Elevation ....17 B. Refrigerant Piping Connection Instructions ...
-
Page 4: Accessories
Accessories The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditione r. Improper installation may result in water leakage, c i r fi , e r . l i Name Shape Quantity... -
Page 5: Safety Precautions
Safety Precautions Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. Failure to observe a warning may result in death. The appliance must be installed in accordance with national regulations. - Page 6 Several indoor units covered in this manual have an "M" suffix in their Model Number. These units can also be used on selected Rinnai Multi Split systems applications. For more information on compatibility, please refer to the Installation Manual accompanying the Rinnai Multi Split Outdoor Unit.
- Page 7 INSTALLATION ORDER Install the indoor unit Install the outdoor unit Install the drainpipe Evacuate the refrigerant system Connect the wires Connect the refrigerant pipes Install the front panel Perform a test run Page 7 ...
-
Page 8: Indoor Unit Parts
Indoor Unit Installation Indoor Unit Parts Drain pump (within indoor unit) Drain pipe Air outlet Air inlet Front grille Louver Display panel Refrigerant pipe Fig. 4.1 Safety Precautions CAUTION WARNING • Securely install the indoor unit on a • Install the indoor and outdoor units, cables structure that can sustain its weight. -
Page 9: Indoor Unit Installation Instructions
Indoor Unit Installation Instructions CAUTION NOTE: Panel installation should be done after DO NOT install the unit in the following piping and wiring. locations: In areas with oil drilling or fracking Step 1: Select installation location In coastal areas with high salt content in the air The indoor unit should be installed in a location that meets the following requirements: In areas with caustic gases in the air, such... - Page 10 n i l v i t Table h of H (mm/inch) > 275 > 317 > 317 > 317 . t i 1. Use the included paper template to cut a rectangular hole in the ceiling, leaving at least 1m (39”) on all sides.
- Page 11 5. Mount the indoor unit. You will need two NOTE: Ensure that the indoor unit is level. The people to lift and secure it. Insert suspension unit is equipped with a built-in drain pump and bolts into the unit’s hanging holes. Fasten them using the included washers and nuts (See Fig.
- Page 12 Outdoor Unit Installation √ The area must be free of combustible gases Outdoor Unit Installation Instructions and chemicals. √ The pipe length between the outdoor and Step 1: Select installation location. indoor unit may not exceed the maximum The outdoor unit should be installed in the allowable pipe length.
- Page 13 Outdoor Unit Dimensions (Wall or obstacle) Air inlet >300mm Air inlet Maintainence access >600mm Air outlet Fig.5.6 NOTE All pictures and diagrams in this manual are indicative for explanatory purposes only. There may be differences between these and the products supplied, depending on the model. Actual unit specifications should be reviewed.
- Page 14 NOTE: The minimum distance between the Notes On Drilling Hole In Wall outdoor unit and walls described in the l i r installation guide does not apply to airtight refrigerant piping, and the signal cable that will rooms. Be sure to keep the unit unobstructed .
-
Page 15: Drainpipe Installation
Drain pipe Installation (Indoor unit has Drain Pump) The drainpipe is used to drain water from the NOTE : DRAINPIPE INSTALLATION unit. Improper installation may cause unit and When using an extended drainpipe, tighten • property damage. the indoor connection with an additional protection tube to prevent it from pulling CAUTION loose. - Page 16 3. Using a core drill, drill a hole in the wall. Make sure that the hole is drilled at a slight downward angle, so that the outdoor end of the hole is lower than the indoor end by about 12mm (0.5”). This will ensure proper water drainage (See Fig.
-
Page 17: Refrigerant Piping Connection
Refrigerant Piping Connection Safety Precautions Notes: Pipe Length and Elevation Ensure that the length of the refrigerant pipe, the number of bends, and the drop height between WARNING the indoor and outdoor units meets the • piping must be completed by a e r i licensed technician and must comply with Table 7.1... -
Page 18: Refrigerant Piping Connection Instructions
Refrigerant Piping Connection Instructions Burrs can affect the air -tight seal of refrigerant piping connection. They must be completely CAUTION removed. The branching pipe must be installed • 1. Hold the pipe at a downward angle to horizontally. An angle of more than 10° may n i l cause malfunction. - Page 19 6. Place flaring tool onto the form. 7. Turn the handle of the flaring tool clockwise until the pipe is fully flared. Flare the pipe in accordance with the dimensions shown in table 7.5. Table 7.5: PIPING EXTENSION BEYOND FLARE Fig.
- Page 20 8. Wiring Super Slim Four-Way Cassette Wiring Safety Precautions Outdoor Unit Wiring WARNING WARNING • Be sure to disconnect the power supply before Before performing any electrical or wiring work working on the unit. the main power to the system. •...
-
Page 21: Wiring
8. Wiring Indoor Unit Wiring 1. Prepare the cable for connection CAUTION e r i • While connecting the wires, please strictly follow the wiring diagram. of the wires inside. • The refrigerant circuit can become very hot. Keep b. Strip the insulation from the ends of the wires. the interconnection cable away from the copper e r i i r c... -
Page 22: Technical Specifications
13.1 17.7 19.2 ACOP 3.36 3.46 3.49 3.36 Star Rating Indoor Unit CIN070R CIN100R CIN120R CIN140R Fascia Panel Model No. CINFAS Rated Input Air Flow (Hi / Med / Lo) 439 / 333 / 278 639 / 556 / 500... - Page 23 Air Evacuation 4. Turn on the vacuum pump to evacuate the Safety Precautions system. 5. Run the vacuum for at least 15 minutes, or until the Compound Meter reads -76cmHG CAUTION (-1x105Pa). 6. Close the Low Pressure side of the manifold •...
- Page 24 Note On Adjusting Refrigerant CAUTION • Refrigerant charging must be performed after wiring, vacuuming and the leak test. DO NOT exceed the maximum allowable quantity of refrigerant or over charge the system. • s ’ t • Charging with unsuitable substances may cause explosions or accidents. Ensure that the appropriate refrigerant is used.
-
Page 25: Panel Installation
Panel Installation Step 3: Install the panel CAUTION Align the front panel to the main body, taking into account the position of the piping and DO NOT place the panel facedown on the floor, drain sides. Hang the four latches of the against a wall, or on uneven surfaces. - Page 26 2. Remove foam stops from inside the fan. 5. Close the front grille. 3. Attach the side of the front grille to the 6. Fasten the installation covers at all four panel. corners by pushing them inwards. (See Fig.10.6) 4. Connect the display panel cable to the corresponding wire on the main body.
-
Page 27: Test Run
Test Run f. Check to see that the drainage system is Before Test Run unimpeded and draining smoothly. A test run must be performed after the entire g. Ensure there is no vibration or abnormal system has been completely installed. Confirm noise during operation. - Page 28 Braeside, Victoria 3195 AU45204 Rinnai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your Rinnai appliance. If your appliance requires service, please call our National Help Line. Rinnai recommends that this appliance be serviced at least every 2 years.
