- Page 1 User manual SCREW FEEDER BY VIBRATING BOWL BSF 300 SERIES 60203-08/22 www.dogassembly.fr...
-
Page 2: Table Of Contents
RANSPORTATION AND STORAGE ..........................45 WEEE RECYCLING AND END OF SERVICE LIFE ......................46 7.4.1 Collection and recycling scheme ..........................46 7.4.2 Collection points ................................46 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... - Page 3 This warning statement indicates important information (for example: damage to property), but no hazard Information Information to view in your customer area on the www.doga.fr web site. Caution This warning statement indicates a low risk that may lead to minor or moderate injuries if not avoided.
-
Page 4: Informations
The system is not able to detect and eliminate non-conforming screws. It is essential to select the screws before use to ensure consistency and to avoid any defective parts in the feeder bowl. DO NOT USE MAGNETIC SCREWS. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... -
Page 5: Glossary
With electric: Max 1 Lt/sec Maximum rate 50 vis/min Noise Depends on the screwdriver: With pneumatic : Max 80 DBA (operator location ) With electric: Max 60 DBA (operator location ) Screw feeder by vibrating bowl © DOGA | 60203- 08/22... -
Page 6: Sécurity
- Inappropriate or risky working speed. - Lack of protective and safety measures. - Poor or absent maintenance. - Uncertain or insecure fixing of the machine or its parts. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... -
Page 7: Declaration Of Incorporation
2.3 Déclaration of incorporation Screw feeder by vibrating bowl © DOGA | 60203- 08/22... -
Page 8: Residual Risks
During maintenance work, put up a warning sign for use. Machine parts that are not in perfect condition must be replaced immediately. Use only original spare and wearing parts ! Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... -
Page 9: Protective Actions To Be Taken By Users
It is forbidden to modify the machine (even partially) without the prior agreement of the manufacturer. If this is not observed, we cannot be held responsible for any damage. This machine may not be used in an environment where there is a risk of explosion. Screw feeder by vibrating bowl © DOGA | 60203- 08/22... -
Page 10: Setting Up
Once positioned on the work bench, check the levelling and, if necessary, make the required corrections by acting on the nuts of the feet. figure 2 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... - Page 11 1 to 1.5 mm. If necessary, use the clearance of the separator holder lights as shown below. Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 12 Connect the air supply tube of the screwdriver (only for a pneumatic screwing tool) Connect the START connector of the auto-advance lever Red hose Black hose Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 13 Do not increase this value too much! If you do, the jaws will not be able to hold the screw before the tightening cycle and the screw will be lost. This pressure regulator is not present when the PNEUMATIC RETENTION SYSTEM is not required. Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 14 The electrical wiring of the machine is designed to operate with a single-phase voltage of 230 V and a frequency of 50 Hz; variations are tolerated at +/- 10% and the frequency variation at +/- 1% of the respective nominal values. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
-
Page 15: Commissioning
Let the vibrating bowl run until the screws fill all the spirals before reaching the separator. Take the tool and place it on the clamping point, press the START lever. Screw feeder by vibrating bowl © DOGA | 60203- 08/22... - Page 16 The speed of descent of the self-advance can be regulated by the flow control. Flow regulator for the downstroke of the auto-advance The vibration intensity of the tank can be adjusted with the potentiometer Bowl vibration level Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
-
Page 17: Micro Plc Parameter
Software switch in order to escape bit and bit On : Cycle stopped, bit out of jaws. holder from the nozzle. This is particularly Off : Normal cycle. useful for maintenance operation. Screw feeder by vibrating bowl © DOGA | 60203- 08/22... - Page 18 • Press ESC button for LOGO menu entering. • With arrows button, select menu “Program”. Then press OK. • Select menu “SET parameters”. Then press OK. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 19 Change the value by pressing the arrows ˅˄. • Press OK to validate. • Press ESC successively until the following screen appears. • Press ˄ to return to the home screen. Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
-
Page 20: Using
Press and hold the start lever for the entire screwdriving cycle. Once the screwdriver has stopped : • Release the start lever A screw dispensing cycle takes place. ▪ A screw is delivered into the nose. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... -
Page 21: Settings
(be careful, bit will be released out of jaws immediately!). Remove the bit. Insert the new bit. Go into the PLC menu and change on state “OFF” the software switch. Remove grubs Screw feeder by vibrating bowl © DOGA | 60203- 08/22... -
Page 22: Bit Holder Substitution
Reassembly the sleeve and lock the nut at correct distance “X”. Go into the PLC menu and change on state “OFF” the software switch. Bit holder Sleeve Ring and pin Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... -
Page 23: Daily Maintenance
The piston goes too slow Low pressure. Seals worn out. The tool does not work Air not present. Piston not completely in backward position. Screw jam in the nozzle. Blade rotor worn out. Screw feeder by vibrating bowl © DOGA | 60203- 08/22... -
Page 24: Helpline
The repair, maintenance, calibration or adjustment service will only be able to start once this form has been received. Download the after-sales service return form 6.8..1 You can download the form by following one of the following links : http://service.doga.fr/syst/dogatech.nsf/liste/00182 https://www.doga.fr/nos-services/maintenance-industrielle Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... -
Page 25: On-Site Troubleshooting
If you need on-site service, please contact your service contact. Warranty 6.10 DOGA guarantees its products against defects in parts and workmanship for a period of 12 months. To benefit from the parts and labour warranty, the following conditions must be met : •... -
Page 26: Part List And Exploded Views
For any spare part quotation, please specify in your request : - The serial number of your machine (see CE plate) - The part number(s). Customised parts for your application are identified by a 7.1 Feeder Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22... - Page 27 30518004-01 plate BSF300 Sous ensemble électrovanne / sub assembly solenoid valve 30518003-04 Sous ensemble platine pneumatique / Sub assembly pneumatic plate 30518004-0 Sous ensemble couvercle / sub assembly cover 30518003-06 Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 28 Plan / drawing : 30121093-02_01 7.1..2 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 29 Presse-étoupe métallique 1/4"/ 1/4" Metal cable gland 410-090-000 Carte de contrôle des vibrations / Vibration control card 20010503 Logo power 24 V/2,5 A 6EP33326SB000AY0 Logo ! 24CE, 8DI(4AI)/4DO, 400 Blocks 6ED10521CC080BA0 Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 30 Plan / drawing 30518003-01 7.1..3 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 31 Plot conique M6x18 Ø20 L.24mm DVA.6-20-24-M6-18-55 / Bumper 501-010-001 M6x18 Ø20 L.24mm DVA.6-20-24-M6-18-55 Pied Ø50 M8 L.43mm / Adjustable foot Ø50 M8 L.43mm 502-010-020 Ecrou Marteau 8 M5 7,7x16 / Nut 8 M5 7,7x16 ø4 CDDCU0000027 Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 32 Plan / Drawing 30518003-02 7.1..4 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 33 Ø plate 205 - H 196mm - clockwise rotation Pièces personnalisées pour votre application / Customised parts for your application Précisez le repère, le N° de série / Specify the marker and the S/N Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 34 Plan / drawing 30518003-04 7.1..5 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 35 Silencieux G1/4 / Silencer G1/4 305-060-004 Silencieux d’échappement G1/4 / Exhaust silencer G1/4 305-060-006 Embase 4 positions G1/4 série V50 / 4 positions subbase G1/4 325-030-018 series V50 Connecteur DIN43650 / Plug DIN43650 330-010-009 Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 36 Bouton PL20-M6 / Button PL20-M6 500-010-005 Vis M5 X 10 / Screw M5 X 10 105-010-410 Vis M6 X 12 UNI5931 / Screw M6 X 12 UNI5931 100-012-001 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
- Page 37 7.1..7 Plan / Drawing 30518004-02 Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 38 Equerre filtre régulateur série Excelon / filter regulator Bracket 320-020-014 Excelon serie Vis M4 x 10 UNI5931 / Screw M4 x 10 UNI5931 100-011-220 150-010-110 Ecrou M4 UNI 5588 / Nut M4 UNI 5588 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
-
Page 39: Selector
7.2 Selector Screw feeder by vibrating bowl © DOGA | 60203- 08/22... - Page 40 140-011-270 Pièces personnalisées pour votre application / Customised parts for your application Précisez le repère, le N° de série / Specify the marker and the S/N. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
-
Page 41: Auto Advanced Unit Aa60 - Aa100
7.3 Auto-Advanced unit AA60 – AA100 Screw feeder by vibrating bowl © DOGA | 60203- 08/22... - Page 42 Joint LRC L3 - ø 22 - LRC 3093/22 / Seal LRC L3 - ø 22 - LRC 3093/22 310-030-010 Détecteur FESTO, 24Vdc PNP NO / Sensor FESTO, 24Vdc PNP NO 405-050-038 Anneau magnétique Ø29,5xØ24,5xSp.2mm / Magnetic ring 750-030-001 Ø29,5xØ24,5xSp.2mm Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
-
Page 43: Nozzle
7.4 Nozzle Screw feeder by vibrating bowl © DOGA | 60203- 08/22... - Page 44 180-310-330 Pièces personnalisées pour votre application / Customised parts for your application Précisez le repère, le N° de série / Specify the marker and the S/N. Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
-
Page 45: Standards
Clean the appliance according to the instructions in the Maintenance chapter. • Store it in a suitable container to protect it from dust and direct sunlight. • Store it in a dry place at an ambient temperature below 40°C. Screw feeder by vibrating bowl © DOGA | 60203- 08/22... -
Page 46: Weee Recycling And End Of Service Life
7.4.1 Collection and recycling scheme In compliance with the French Environmental Code covering professional Waste Electric and Electronic Equipment (WEEE) (art.R543-195 et seq.), DOGA is a member of ECOSYSTEM, an eco-organization approved by public authorities under the conditions defined by art R543-197. - Page 47 Screw feeder by vibrating bowl © DOGA | 60203- 08/22...
- Page 48 © DOGA | DOC.60203-08/22 Screw feeder by vibrating bowl – BSF 300 series © DOGA | 60203- 08/22...
