HENDI 212172 - WAFFLE MAKER Manual

Intended use

• This appliance is intended for professional use.
• This appliance is intended for making waffle only. Any other use may lead to damage of the appliance or personal injury.
• Operating the appliance for any other purpose shall be deemed a misuse of the device. The user shall be solely liable for improper use of the device.

Grounding installation

This appliance is classified as protection class I and must be connected to a protective ground. Grounding reduces the risk of electric shock by providing an escape wire for the electric current.
This appliance is fitted with a power cord that has a grounding wire and grounded plug. The plug must be plugged into an outlet that is properly installed and grounded.

Main parts of the appliance

1. Handle
2. Baking plates (Upper & lower)
3. RESET button (At the back)
4. Timer (Up to 15 mins)
5. Heating indicator (Orange)
6. Temperature control knob, 0°C ~ 220°C (MAX)
7. ON/OFF switch

Preparations before using for the first time

• Unpack the appliance carefully and remove all protective packaging and wrapping. Make sure no packaging debris remains on the appliance.
• Keep the packaging if you intend to store your appliance in the future.
• Check delivery contents for any missing parts and any possible transport damage. In the event of damage in transit or missing parts, DO NOT use the appliance and contact your supplier immediately.
• Place the appliance on a horizontal, stable and heat resistant surface. Leave at least 20 cm of space around and above the appliance.
• Let the appliance heat up for few minutes at the highest temperature setting (--> Operation) to remove all residues from the manufacturing process. It may also emit some odour for the first few cycles. This is normal and does not lead to defect or hazard.
• Let the appliance cool down completely before cleaning to use it again.

Operation

• Clean the baking plate by a moist cloth before first time of using.
• Connect the power plug with a suitable electrical outlet.
• Switch on the appliance with the ON/OFF switch, it will light up. Then turn the temperature control knob clockwise to select the required baking temperature.
• When the baking plate is heating up, the Orange heating indicator light up.
• Wait 5 to 10 minutes for preheating. Once the set temperature is reached, the Orange heating indicator will go off automatically.
• Now it is ready for baking. Lightly coat the lower baking plate with butter, margarine or suitable baking oil. Then, spread the waffle dough evenly on the lower baking plates. Do not pour too much tough.
• Close the lid by using the handle.
• Orange heating indicator lights up again for heat-ing up.
• Timer: Switch on the timer, when finished the timer will sound.
• Remove the waffles using a waffle fork (not sup-plied). Never use abrasive utensils. This may damage the non-stick coating of the baking plates. Never use bare hands to touch the food. Danger of burns!
  Note: When you pour the batter onto the hot baking plate, you might hear some slight cracking noise caused by difference in temperature. This is normal.
• Close the appliance if more waffles are to be baked, in order to maintain the temperature.
• After use: set the Temperature control knob to zero degree in upwards position until the Orange heating indicator goes out.

Attention
Disconnect the power plug from the electrical outlet and let it cool completely before cleaning and storing.

Attention
When the timer is finished the power won't be cut. To switch the appliance off turn temperature control to zero degree.

Note: Due to the manufacturing residues, the appliance may emit slight odor in the first few cycles. This is normal and does not indicate any defect or hazard. Make sure the appliance is well ventilated during operation.

RESET the Hi-limiter (thermal cut-out)

NOTE: The RESET button is at the back of the appliance.

• Unplug the appliance electrical power outlet.
• Allow the appliance to completely cool down.
• Press the RESET button of the Hi-limiter (ther-mal cut-out). You should hear a click sound.
• Plug into the socket and you can use it again.

Cleaning and maintenance

Attention
Always unplug from the electrical power supply outlet and let it cool down completely before cleaning and storage.

Cleaning

• Never immerse the appliance in water or other liquids.
• Clean the cooled exterior surface with a slightly damp cloth or sponge with some mild soap solution.
• Never use abrasive sponges or detergents, steel wool or metallic utensils to clean the interior or exterior parts of the appliance.

Storage

• Before storage, always make sure the appliance has already been disconnected from the electrical outlet and cooled down completely.
• Store the appliance in a cool, clean and dry place.
• Never put heavy objects on the appliance as it may damage the appliance.

Troubleshooting

If the appliance does not function properly, please check the below table for the solution. If you are still unable to solve the problem, please contact the supplier/service provider.

Technical specification

Remark: Technical specification is subjected to change without prior notification.

Safety regulations

Read this manual carefully, paying particular attention to the safety regulations outlined below, before installing and using this appliance for the first time.

• This appliance is intended for commercial use.
• Only use the appliance for the intended purpose it was designed for as described in this manual.
• The manufacturer is not liable for any damage caused by incorrect operation and improper use.
• Keep the appliance and electrical plug away from water and other liquids. In the event the appliance falls into water, immediately remove the power plug from the socket. Do not use the appliance until it has been checked by a certified technician. Failure to follow these instructions will cause life threatening risks.
• Never attempt to open the housing of the appliance by yourself.
• Do not insert objects into the housing of the appliance.
• Do not touch the plug with wet or damp hands.
•
  Do not attempt to repair the appliance by yourself, repairs are only to be conducted by qualified personnel.
• Never use a damaged appliance! When it's damaged, disconnect the appliance from the socket and contact the retailer.
•
  Do not immerse the electrical parts of the appliance in water or other liquids.
• Never hold the appliance under running water.
• Regularly check the power plug and cord for any damage. When damaged it must be replaced by a service agent or similarly qualified person in order to avoid danger or injury.
• Make sure the cord does not come in contact with sharp or hot objects and keep it away from open fire. Never pull the power cord to unplug it from the socket, always pull the plug instead.
• Make sure that the power cord and/or extension cord do not cause a trip hazard.
• Never leave the appliance unattended during use.
•
  As long as the plug is in the socket the appliance is connected to the power source.
• Turn off the appliance before unplugging it from the socket.
• Connect the power plug to an easily accessible electrical socket so that in case of emergency the appliance can be unplugged immediately.
• Never carry the appliance by the cord.
• Do not use any extra devices that are not supplied together with the appliance.
• Only connect the appliance to an electrical outlet with the voltage and frequency mentioned on the appliance label.
• Never use accessories other than those recommended by the manufacturer. Failure to do so could pose a safety risk to the user and could damage the appliance. Only use original parts and accessories.
• This appliance should not be operated by persons with reduced physical, sensory or mental capabilities, or persons that have a lack of experience and knowledge.
• This appliance should, under any circumstances, not be used by children.
• Keep the appliance and its power cord out of reach of children.
•
  ALWAYS switch off the appliance and unplug from power socket before cleaning, maintenance or storage.

Special Safety Regulations

• This appliance is intended for making waffle only. Any other use may lead to damage of the appliance or personal injury.
• Use the appliance only as described in this manual.
• This appliance should be operated by trained personnel in kitchen of the restaurant, canteens or bar staff, etc.
•
  CAUTION! HOT SURFACE! The temperature of the baking plates and other accessible surface are very high during use. Touch the temperature control knob & the handle only.
• When this appliance is to be positioned in close proximity to a wall, partitions, kitchen furniture, decorative finishes, etc., it is recommended that they are made of noncombustible material; if not, they shall be cladded with a suitable non-combustible heat insulating material, and that the closest attention be paid to fire prevention regulations.
• Do not place the appliance on a heating object (gasoline, electric, charcoal cooker, etc.). Keep the appliance away from any hot surfaces and open flames. Always operate the appliance on a level, stable, clean, heat-resistant and dry surface.
• Do not use the appliance near explosive or flammable materials, credit cards, magnetic discs or radios.
• This appliance is not intended to be operated by means of an external timer or separate remote-control system.
•
  Keep all ventilation openings in the appliance clear of obstruction.
• Allow at least 20 cm spacing around the appliance for ventilation purpose during use.
• Do not use water jet, flush directly with water or steam cleaner as the parts will get wet and electric shock might be resulted.
•
  Securely route the power cord if necessary in order to prevent unintentional pulling or contact with the heating surface.
• Do not wash the appliance with water. Washing can cause leakages and increase the risk of electric shock.
• Do not clean or store the appliance unless it is completely cooled down.
