Airthereal Pristine - Pro6H - WATER PURIFIER Manual

SPECIFICATIONS

Product Name Reverse Osmosis Water Purifier
Model Pro6H
Input 120V 60Hz
Rated Power 1500W
Inlet Water Temperature 41-100°F
Working Pressure 0.4Mpa-0.8Mpa
Pure Water Rate 8.8 fl oz/min
Ambient Humidity ≤ 90%
Ambient Temp 39-104°F
Pure to Drain 3:1

COMPONENTS

COMPONENTS

GETTING STARTED

Setting up

  1. Please wash the water tank before first use.
  2. Fill the water to the MAX volume line on the water tank.
  3. Place the machine on a flat and stable surface that is within reach of a power outlet.
  4. Ensure the filter is installed securely in its designated spot. (The filter is preinstalled before delivery)
  5. Plug into the power outlet and turn on the switch behind the machine. The LCD display will illuminate.
  6. Each time the power is switched on, the machine automatically enters the backflushing mode. The control panel cannot be operated during this time.
  7. After backflushing, we suggest emptying the water tank and long pressing to drain the water in the inner part of the machine until you hear the Water shortage alarm. This concludes one cycle of cleaning.
  8. Repeat steps 2-7 at least 5-6 times before using or drinking any water.
    Display Icons in 6:
    Backflushing: power on, the will illuminate, and then enter the water making mode Water dispensing making: the will illuminate until finished.

warning Note: When using the machine for the first time, in the process of backflushing and water dispensing making, the will illuminate, which is normal, Then the light will disappear after water dispensing making.

Function

Function

warning NOTE: EACH TIME THE POWER IS SWITCHED ON, YOU MUST DISPENSE A CUP OF WATER UNTIL THE SETTING BUTTON ILLUMINATES BEFORE YOU CAN ADJUST THE SETTING.

Touch control


Water Making

Press to water making or stop water making.
warning Note: The machine automatically enters child lock mode after finishing water dispensing and no operation for more than 30 seconds. The child lock button will light up.


Child Lock

Press to enter and release the child lock.


Volume

Press to choose volume of water you need. You can choose between 4 different volumes: 4/8/16/32 OZ.


Temperature

Press to choose the dispensed water temperature. You can choose between 5 different temperatures: water temp in tank/113/158/185/212°F. The setting function is consistent with the following settings, and the corresponding settings are as follows:

Normal Temperature Bottle Warming Tea Boiling Water
The temperature of the water in the tank 113°F 185°F 212°F

LED Display

LED Display

MAINTENANCE

Filter Lifespans

RO (Reverse Osmosis) Membrane Filter need to replace the filter
PCB (Pleated PP Membrane & Activated Carbon Block) Filter need to replace the filter

warning Note:

  1. The filter lifespan is based on the power-on time of the whole machine or the time the machine is actively purifying water. Whichever time threshold is reached first will cause the filter reset indicator to illuminate.
  2. The actual lifetime of the filters may differ depending on the input water quality, season, and how long the machine is powered on. The figures above are just an estimate. Your results may vary.

Filter replacement

  1. Turn off the power and remove the raw water tank.
  2. Open the buckle and pull the filter out.
  3. Reinstall the new filter, then pull the buckle down to secure it.
  4. Fill with raw water.
  5. Power on and press for 5s to reset the filter. (In the case of an indicator that alerts you to replace the filter).
  6. Press for 5s enter to reset the setting. Press Flush to select which filter needs to be reset, then press for 3s to reset. After reset, press for 3s to exit the settings. (In the case of an indicator that has not alerted you to replace the filter, but stopped working and needed to be replaced).

Automatic backflushing

The system automatically enters flushing mode under the following circumstances:

  1. For the first time using When powered on, the system will automatically switch to auto-flushing mode and start back-flushing for 20 seconds.
  2. Every time before water making The system will be forced to backflush for 20 seconds before a filtration cycle starts.
  3. For restored power When the power is restored from an outage, the system will be forced to auto backflush for 20 seconds.
  4. Manual back-flushing Press to trigger the 20 second backflushing.

How to clean your water purifier

  1. Please regularly wipe the exterior with a soft towel. Do not wipe the surface with chemical cleaners as not to damage the surface.
  2. Do not rinse the product with water as it may cause water accumulation that is prone to bacteria and odors.
  3. Please clean the water tank regularly to keep the tank clean and hygienic. Dirty water in the tank may cause damage to seals and other components.
  4. If you need to stop using this machine for a long time (more than 7 days), please drain the water tank and unplug from the power supply. When using the water purifier again, you must clean the unit according to the "Product Instructions" above before drinking normally.

TROUBLESHOOTING

Error Codes

Problem Possible Causes Solution
E1 The outlet water temperature sensor is faulty Power off, wait for 30 minute, then restart
E4 Heating film failure Power off, wait for a period of time and then restart
E5 The inlet water temperature is below 32°F Use water warmer than 41°F
E6 The tank low water level switch was short-circuited Turn off the unit and contact Airthereal Customer Service
E7 Zero-crossing faults
E8 Continue to produce water for 20 minutes, but the water in the inner tank is not full.
Eb The water pump is disconnected
EU Communication failure
Eb The water pump has short-circuited
H1 The inlet water temperature sensor is faulty
H2 Voltage sensor failure
H3 The temperature of the heating element is too high
H4 Over-temperature protection
H5 Descaling failure

SAFETY INSTRUCTIONS

warning IMPORTANT SAFE GUARDS: To avoid the risk of serious injury when using your Reverse Osmosis Water Purifier, basic safety precautions must be followed, including but not limited to the following.

  • All contents in this chapter are related to safety, users must comply with it.
  • To protect against electric shock, do not place the power adapter, cord, base unit, or electronic module in water or other liquids.
  • Keep out of reach of children. Do not let children operate the machine.
  • Do not operate any appliance with a damaged electrical cord or plug or after the appliance malfunctions or has been dropped or damaged in any manner. If the power adapter cord is damaged, it must be replaced.
  • Do not try to repair the machine yourself. If you have any problems, please contact Airthereal customer service for help.
  • Use only factory-authorized replacement parts. The use of unauthorized replacement parts may degrade both the safety and the performance of this product and will void the limited warranty.
  • The appliance must be dry before connecting to electrical power and be dry and free of leaks during operation.
  • Avoid installing under direct sunlight and outdoor places.
  • Do not expose this appliance to an environment below 32°F.
  • Please make sure the temperature of the water source is 41-100°F.
  • Do not store flammable items near the machine.
  • When the machine will be inactive for more than 7 days, please empty the water tank and unplug the power supply.
  • Regularly inspect product for water leaks as water leaks can cause property damage.
  • Please only use accessories and filter cartridges from AIRTHEREAL.
  • Unplug from the electrical outlet before cleaning or performing routine maintenance (i.e.replacing the filter cartridge).


Cancer and Reproductive Harm www.p65warnings.ca.gov

For WARRANTY information please visit:
www.airthereal.com/warranty

Always here to help you:
www.airthereal.com
