Blue point YA1703 Owner's/Operator's Manual

SAVE THESE INSTRUCTIONS
For your safety, read, understand, and
follow the information provided with and
on this jack. The owner and operator of
this equipment shall have an
understanding of this jack and safe
operating procedures before attempting
to use. The owner and operator shall be
aware that the use and repair of this
product may require special skills and
knowledge. Instructions and safety
information shall be conveyed in the
operator's native language before use
of this jack is authorized. If any doubt
exists as to the safe and proper use of
this jack, remove from service
immediately.
Inspect before each use. Do not use if
there are broken, bent, cracked, or
damaged parts (including labels). Any
jack that appears damaged in any way,
operates abnormally or is missing
parts, shall be removed from service
immediately. If the jack has been or
suspected to have been subjected to a
shock load (a load dropped suddenly,
unexpectedly upon it), immediately
discontinue to use until jack has been
checked by a Snap-on authorized
service center. It is recommended that
an annual inspection be done by
qualified personnel. Labels and
Operator's Manual are available from
manufacturer.
PRODUCT DESCRIPTION
Blue-Point Hydraulic Service Jack is
designed to lift, not sustain, rated
capacity loads. It is designed to be used
in conjunction with jack stands. This
jack has a unique feature which provide
fast, no load lifts to the jacking point.
Intended use: To lift one wheel or one
axle of a vehicle for the purpose of
service and/or repair of vehicle
components. After lifting, loads must be
immediately supported by appropriately
rated jack stands. Check with vehicle
owner's manual for proper lift points.
OWNER/OPERATOR MANUAL
DO NOT DOLLY THE LOAD WITH THIS
DEVICE !
DO NOT USE FOR ANY PURPOSE
OTHER THAN THOSE USES OUTLINED!
BEFORE USE
1. Verify that the product and the applica-
tion are compatible, if in doubt call
Snap-on Technical Service.
2. Read the owners manual completely
and familiarize yourself thoroughly
with the product, its components and
recognize the hazards associated
with its use before using this product.
3. Assemble handle and secure it in the
handle fork with the provided bolt.
4. Locate and open the release valve by
turning it counterclockwise (no more
than 1/2 full turn).
5. With saddle fully lowered, remove air
vent screw.
6. Ensure the oil level is within 3/16"
from the inner cylinder as veiwed
from the vent screw hole.
7. Turn the handle clockwise until firm
resistance is felt to close the release
valve.
8. Roll the jack to ensure that it rolls
freely before putting into service.
9. Raise and lower the unloaded saddle
throughout the lift range to ensure
proper operation of the pump and
release valve before placing any load
on the product.
10. Replace worn or damaged parts
and assemblies with Snap-on
Authorized Replacement Parts only.
(See Replacement Parts Section).
Lubricate as instructed in
Maintenance Section.
11. Inspect before each use. Do not use
if there are bent, broken, or cracked
components.
1
MODEL YA1703
3 TON CAPACITY
HYDRAULIC
SERVICE JACK
! WARNING
• Study, understand, and follow all
instructions provided with and on
this device before operating this
device.
• Do not exceed rated capacity.
• This is a lifting device only.
• After lifting, immediately transfer the
load to appropriately rated vehicle
stands.
• Never work on, under, or around a
load supported by this device.
• Use only on hard, level surfaces
capable of sustaining rated capacity
loads.
• Do not move or dolly loads with this
device.
• Do not modify this device.
• Do not use adapters or accessories
that are not provided initially.
• Lift only on areas of the vehicle as
specified by the vehicle manufac-
turer.
• Failure to heed these markings may
result in personal injury and/or
property damage.
! ADVERTENCIA
• Leer, comprender, y seguir las
instrucciónes antes de utilizar el
aparato.
• El manual de instrucciónes y la
información de seguridad deben
estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede
causar daños personales o
materiales.
