Blue point YA1642A Owner's/Operator's Manual

SAFETY INSTRUCTIONS
For your safety, read, understand, and
follow the information provided with and
on this jack. The owner and operator of
this equipment shall
understanding of this jack and safe
operating procedures before attempting
to use. The owner and operator shall be
aware that the use and repair of this
product may require special skills and
knowledge. Instructions and safety
information shall be conveyed in the
operator's native language before use of
this jack is authorized. If any doubt exists
as to the safe and proper use of this jack,
remove from service immediately.
Inspect before each use. Do not use if
there are broken, bent, cracked, or
damaged parts (including labels). Any jack
that appears damaged in any way,
operates abnormally or is missing parts,
shall be removed
immediately. If the jack has been or
suspected to have been subjected to a
shock load (a load dropped suddenly,
unexpectedly upon it), immediately
discontinue to use until jack has been
checked by a Snap-on authorized service
center. It is recommended that an annual
inspection be done by qualified
personnel. Labels and Operator's Manual
are available from manufacturer.
PRODUCT DESCRIPTION
Blue-Point Hydraulic Service Jack is
designed to lift, not sustain, rated capacity
loads. It is designed to be used in
conjunction with jack stands. Intended
use: To lift one wheel or one axle of a
vehicle for the purpose of service and/or
repair of vehicle components. After lifting,
loads must be immediately supported by
appropriately rated jack stands. Check
with vehicle owner's manual for proper lift
points.
DO NOT DOLLY THE LOAD WITH THIS
DEVICE !
DO NOT USE FOR ANY PURPOSE OTHER
THAN THOSE USES OUTLINED!
OWNER/OPERATOR MANUAL
Familiarize yourself with the illustrations
in the operator's manual. Know your jack
and how it operates before attempting to
have an
use. Refer to Figure 1 on page 3 for
components location. Tighten securely to
prevent accidental removal of handle
while in use.
1. Assemble the two-piece handle with
provided bolt
2. Insert the handle into the handle fork.
3. Tighten the bolt securely to prevent
accidental removal of handle while in
use.
1. Verify that the product and the
application are compatible.
2. Read the owners manual completely
and familiarize yourself thoroughly with
the product, its components and
from service
recognize the hazards associated with
its use before using this product.
3. Locate and open the release valve by
turning it counterclockwise (no more
than 1/2 full turn).
4. With saddle fully lowered, remove oil
filler plug. Pump handle 6 to 8 strokes
to vent the air in reservoir.
5. Ensure that oil level is within 3/16" from
the inner cylinder as veiwed from the
oil filler hole. Reinstall the oil filler plug.
6. Close release valve by turning the
handle clockwise until firm resistance
is felt.
7. Roll the jack to ensure that it rolls freely
before putting into service.
8. Raise and lower the unloaded saddle
throughout the lift range to ensure
proper operation of the pump and
release valve before placing any load
on the product.
9. Replace worn or damaged parts and
assemblies with Snap-on Authorized
Replacement
Replacement Parts Section). Lubricate
as instructed in Maintenance Section.
10. Inspect before each use. Do not use if
there are bent, broken, or cracked
components.
ASSEMBLY
BEFORE USE
Parts only. (See
1
MODEL YA1642A
2 TON CAPACITY
HYDRAULIC
SERVICE JACK
! WARNING
• Study, understand, and follow all
instructions provided with and on
this device before operating this
device.
• Do not exceed rated capacity.
• This is a lifting device only.
• After lifting, immediately transfer the
load to appropriately rated vehicle
stands.
• Never work on, under, or around a
load supported only by this device.
• Use only on hard, level surfaces
capable of sustaining rated capacity
loads.
• Do not move or dolly loads with this
device.
• Do not modify this device.
• Do not use adapters or accessories
that are not provided initially.
• Lift only on areas of the vehicle as
specified by the vehicle manufac-
turer.
• Failure to heed these markings may
result in personal injury and/or
property damage.
!
ADVERTENCIA
Esta es una simple advertencia.
Por favor lea las instrucciones y
s
advertencias en inglé
