Summary of Contents for Raytheon Electronics Autohelm ST80
- Page 1 ST80 Remote Keypad Operation Manual...
- Page 3 ST80 Remote Keypad Operation and Setup Package Contents 1. Remote keypad 2. Thumb nuts (2) 3. Threaded fixing studs (2) 4. White sun cover 5. SeaTalk cable 6. Installation template 7. Operation manual 8. Warranty card 9. Operation cue card 10.
-
Page 4: Table Of Contents
ST80 Remote Keypad Operation and Setup Contents Chapter 1: Introduction .............. 3 I n t r o d u c t i o n ............... 3 Chapter 2: Operation .............. -
Page 5: Chapter 1: Introduction
ST80 Remote Keypad Operation and Setup Chapter 1: Introduction The remote keypad allows you to operate ST80 display heads from a remote location. Divided into two sections, the Remote consists of 10 keys – six dedicated to standard display heads and four to Maxiview display heads. -
Page 6: Chapter 2: Operation
ST80 Remote Keypad Operation and Setup Chapter 2: Operation The following illustration shows the functions assigned to each key or key sequence. • Display heads change to reverse video (white on black) when selected. 235oM • The display returns to normal (black on white) if there are no further key presses within 8 seconds. - Page 7 ST80 Remote Keypad Operation and Setup • The keypad beeps when a key is pressed. • The small red LED glows when the keypad is operational. • The brightness of the keypad illumination is governed by the system illumination setting.
-
Page 8: Chapter 3: Setup
ST80 Remote Keypad Operation and Setup Chapter 3: Setup The remote keypad allows you to operate ST80 display heads from a remote location. Divided into two sections, the Remote consists of 10 keys – six dedicated to standard display heads and four to Maxiview display heads. -
Page 9: Grouping
ST80 Remote Keypad Operation and Setup Grouping allows you to create up to 8 standard and 8 Maxiview display head groups. • Each group can have up to eight display heads. • Each group must have one or more remote keypads grouped to it. •... -
Page 10: Grouping Standard St80 Display Heads
ST80 Remote Keypad Operation and Setup Grouping Standard ST80 Display Heads 1. Press and hold the two lower keys on any remote for 4 seconds. All the standard display heads enter group setup mode. Also, one of the display heads will change to reverse video and the cursor will flash. - Page 11 ST80 Remote Keypad Operation and Setup 3. Use the following keys to assign an alpha numeric code to the currently selected display head (for example, A1). The letter “A” represents the remote keypad that will control the selected display head and the number the sequence of operation. All display heads are selected until they are grouped whilst in group setup mode.
-
Page 12: Grouping St80 Maxiview Display Heads
ST80 Remote Keypad Operation and Setup 11. If you are only creating one group, return to normal operation as described in actions 12 and 13. If you are creating more than one group, repeat the procedures described in actions 2 through 10 prior to returning to normal operation (described below). - Page 13 ST80 Remote Keypad Operation and Setup 7. If you are only creating one group, return to normal operation as described in actions 8 and 9. If you are creating more than one group, repeat the procedures described in actions 2 through 6 prior to returning to normal operation (described below).
-
Page 14: Chapter 4: Problem Solving
ST80 Remote Keypad Operation and Setup Chapter 4: Problem Solving Keypad does not operate - power LED not illuminated • Make sure the cable connecting the keypad to SeaTalk is connected properly. • Make sure the cable is not damaged. Replace the cable if it is damaged. -
Page 15: Chapter 5: Emc And Servicing Guidelines
ST80 Remote Keypad Operation and Setup Chapter 5: EMC and Servicing Guidelines All Autohelm equipment and accessories are designed to the best industry standards for use in the leisure marine environment. Their design and manufacture conforms to the appropriate Electromagnetic Compatibility (EMC) standards, but good installation is required to ensure that performance is not compromised. - Page 16 ST80 Remote Keypad Operation and Setup • Always check the installation before going to sea to make sure that it is not affected by radio transmissions, engine starting etc.. • In some installations, it may not be possible to prevent the equipment from being affected by external influences.
-
Page 17: Chapter 6: Specification
ST80 Remote Keypad Operation and Setup Chapter 6: Specification Dimensions: 110 x 68 x 17mm (4.33 x 2.67 x 0.66in) Power supply: 10 to 16 V DC Current consumption: 90 mA to 190mA (illumination full on) Operating temperature: -10 to +70°C (14°F to 158°F) Buzzer: Single tone buzzer... - Page 18 ST80 Remote Keypad Operation and Setup 81073-1...
- Page 20 Raytheon Marine Europe Ltd. Anchorage Park, Portsmouth, P03 5TD, England. Telephone: (44) 1705 693611 Fax: (44) 1705 694642...
