Summary of Contents for White-Westinghouse WM106
- Page 1 LAVABIANCHERIA MANUALE DELL’UTENTE WASHING MACHINE USER MANUAL mode d’emploi de machine à laver électronique...
-
Page 2: Table Of Contents
Water inlet filters • Pump filter • Detergent drawer • Siphon plug • The cabinet • The drum • Remove of your machine from lime SECTION 7: PRACTICAL INFORMATION SECTION 8:AVOIDING MINOR FAULTS SECTION 9:AUTOMATIC FAILURE DETECTION SYSTEM SECTION 10:INTERNATIONAL WASHING SIGNS... -
Page 3: Section 1:Before Using
Since the machine can reach high temperatures while running, do not touch the drain hose and water during draining. • In case of any failure, first unplug the device and close the water tap. Do not attempt to repair.Please apply to the nearest authorized service station. -
Page 4: Section 2:Installation
• If you will not use your machine for a long time, unplug your machine, close the water supply and leave the door open in order to keep the inside of the machine dry and for prevention from unpleasant odour. -
Page 5: Electrical Connection
10 ampere. The fuse flow value of the electricity line attached to this should also be 10 ampere. If you have no such sockets and fuses in your house, let it be made by a qualified electrician. -
Page 6: Water Drain Connection
Water drain hose should be mounted at a height of minimum 60 cm, maximum 100 cm from the ground. • The end of the water drain hose may directly be fitted to the dirty water outlet hole or a special apparatus mounted on the outlet bracket of the wash-stand. -
Page 7: Section 3:Technical Specifications
( rpm ) (*) Maximum spin cycles depend on the model you’ve chosen 1-Upper tray 5-Handle 2-Detergent drawer 6-Filter cover 3-Control panel 7-Kickplate 4-Door These technical specifications written above for single water inlet (cold) and double water inlet (cold/hot) in machines. -
Page 8: Section 4:Control Panel
9-Program end light 5-Program ready light WM60E 1-Detergent drawer 5-Program knob 2-Start/pause light 6-Start/pause button 3-Function indicator lights 7-Function buttons 4-Program ready light 8-Program end light Our product has electronic card and soft-touch buttons.To activate the functions touch the buttons slightly. -
Page 9: Start/Pause Button
START/PAUSE BUTTON Used to start a selected program or pause during running. WARNING! It is required for the program knob to be brought to O(off) position before selecting the program or changing a continuing program. FUNCTION INDICATOR LIGHTS When the start/pause button or any function button is pressed,the corresponding light turns on.The light turns off when the function... - Page 10 If you do not want your sensitive clothes to be spinned or you want them to be spinned sensitively, turn the program knob to O (off) position. Bring the program knob on one of the draining or spinning programs you desire and press the start/pause button.
-
Page 11: Spin Speed Selector
You must be careful that the adjustment sign of the program knob is exactly on the program you want to select. When you bring the program knob to O(off) position, while your machine is running,... -
Page 12: Section 5:Washing Your Laundry
Since your new coloured clothes may shed dye on the first wash, wash them separately. • Be careful that no metal pieces are found on or in the pockets of your clothes, remove if there is any. • Zip and button your clothes. - Page 13 • Wash your small clothes like socks and handkerchiefs in a washing bag. Wash up tol 90 ˚C Wash up to 60 ˚C Wash up to 30 ˚C Not washable in washing machine Placement of the clothes into the machine •...
-
Page 14: Running The Machine
• Run the program which you have selected by pressing the Start/Pause button. Changing the program If you have selected a program and you do not want if to continue: • Press the start/pause button. • Bring the program knob to O(off) status. -
Page 15: Section 6:Maintenance And Cleaning
Close the water tap. WARNING! If the power is off end on again after a while on any stage of the washing program, your machine will continue the program from the point where it was interrupted. This is not harmful for your machine. - Page 16 7-QUICK WASH coloured and linen textile Slightly dirty cotton, 8-COTTON coloured and linen textile. Washed without heating COLD the tap water. Dirty or very dirty, stain , 9-MIX cotton, coloured and linen WASH textile Dirty, synthetic or Nylon socks, 10-SYNTHETIC 60˚...
- Page 17 TABLE-1 CONTINUE (*) You can use softeners in all programs (except spinning and draining programs) optionally. When you arrange the quantity of the softener, comply with the warning of the softener producer. Fill your softener in its (softener) compartment of the detergent drawer.
-
Page 18: Pump Filter
After you have cleaned the pump, fit the filter cover by rotating clockwise. • Put the kickplate cover into the place. • Do not forget that if you do not fit in the filter cover properly, it will leak water. -
Page 19: Detergent Drawer
• Pull the detergent drawer to the end.(DIAGRAM-1) • Siphon plug to tread of the drawer, continue to pull until the drawer is pull out.(DIAGRAM-2) • Wash will an old toothbrush and excessiveamount of water. - Page 20 Chocolate and cocoa: By leaving your clothes in cold water and rubbing with soap or detergent, wash it in the highest temperature that the type of your cloth can endure. If there is still a stain of oil left, wipe with oxygenated water (in proportion of 3%).
- Page 21 Then it should be rubbed with detergent and washed. Burnt stain: If your cloth is suitable for use of lye, you can add lye into your washing water. For woolen fabric, a cloth damped in oxygenated water should be covered on the stain and it should be ironed with a dry cloth on it.
-
Page 22: Siphon Plug
Close the water tap and pull out the water inlet hose or hoses from the tap. • Place the ends of the water drain and water inlet hoses in a cup on the ground. • Adjust the program knob to “Draining” program. - Page 23 The feet of your machine are not Adjust the feet. (**) Your machine is adjusted. vibrating. Transportation screws Remove transportation are not removed. screws. (**) (*)See the section concerning the maintenance and cleaning of your machine. (**)See the section concerning installations your machine.
- Page 24 . Press the start/pause button.In order to stop the foam,dilute one table-spoon of softener in half liter of water and pour it in the detergent Too much detergent drawer.Press the has been used. start/pause button after Excessive foam in the 5-10 minutes.Arrange...
- Page 25 In the next washing These stains may be operation, use the There are gray stains caused by oil,cream or maximum detergent on the clothes. ointment . amount declared by the detergent producer. (**) See the section concerning instalations your machine.
-
Page 26: Section 9:Automatic Failure Detection System
SECTION 9: AUTOMATIC FAILURE DETECTION SYSTEM Your machine is equipped with systems which will both take the necessary precautions and warn you in case of any failure by controlling it self constantly during the washing processes. FAILURE FAILURE... - Page 27 The start/pause The pump has problem light and failed or the Err 03 persists,apply to program ready pump filter is the nearest light blinks . obstructed. authorized service.(*) (*) See the section regarding the maintenance and cleaning of your machine.
- Page 28 FAILURE FAILURE PROBABLE THE PROCESS CODE INDICATOR FAILURE TO BE DONE Shut down your The heater of your machine and The start/pause machine or the unplug. Turn off Err 05 light and program heat sensor has your tap and apply end light blink.
-
Page 29: Section 10:International Washing Signs
Do not bleach. Handy to bleach. All of these are dry cleaning symbols. The letters are to instruct the cleaner what type of solvent to be used. Garments bearing these symbols should not be washed in your machine unless the label says... - Page 30 52005725...
