Please read these instructions carefully before connecting and using the machine. An awareness of how the machine operates will help guarantee its correct and safe use. The instructions also contain some useful information on the machine’s functions that will help you get the most out of its use.
Page 4
Do not touch the door glass as this may also heat up during The machine must not be used by unsuper- the wash vised children.
The motor and all the other moving parts are built to ensure noiseless machine operation. The large stainless steel drum is well placed to guarantee a good wash quality and prolong the life of the washing. The easy to use control panel makes the selection of any wash or dry programme quick and simple (see control panel and table of programmes).
The machine can be installed anywhere, provided the temperature in the place of installation is not below 3°C and the cables and hoses at the rear of the machine are not crushed in any way. For transport purposes the swinging unit in the machine is blocked using 4 spacers with screws.
(fig. 6). The water supply tap must be fully open when washing. The water drain hose must be placed at least 60 cm and not more than 90 cm from the floor (fig. 7). If the drain hose is connected to a fixed drainage system, the free end must be inserted in a pipe of minimum internal diameter 40 mm.
Otherwise, the manufacturer will not be held responsible for any accidents (fig. 10). If the socket to which the machine will be connected is faulty or does not com- ply with the requirements, it must be replaced by a qualified electrician.
N.B. When using a liquid detergent (recommended for programs without pre-wash) proceed as follows: remove the baffle from its housing at the front of compartment 2 and insert it in the guides near the centre of the same compartment. Remember to replace it in its front housing when using soap powder.
Some stains cannot be removed by just washing in a washing machine. Before trying to remove any type of stain by hand, first try the removal procedure on a small area of hidden fabric starting from the edge of the stain and working inwards, this will prevent a dark ring from forming around the site of the stain.
Place a cloth or flat plate under the filter to collect any water that may still be inside it. Open the filter door, unscrew the filter and remove it, turning in an anticlockwise direction (fig.21).
When calling the service centre, inform them of the machine model, the serial number and the type of fault. The data relating the appliance can be found on the rating plate affixed to the filter door.
Page 15
“no-spin”. NB. the maximum spin speed will vary according to the model and is indicated by the Leds on the machine. The maximum spin speed that can be selected for each programme is indicated by the leds that light-up automatically when the wash programme is selected.
Page 16
“START” button. Warning!! only use this function if strictly necessary and then only if the program to reset has not been running for more than 3 minutes. Before opening the door after a reset, wait 2 minutes for the locking mechanism to release.
Page 17
(see technical characteristics table), the quantity of water used for the wash will be reduced by 2 litres for each kg less of washing. In the case of a half-load or less, the machine will automatically carry out one rinse less than programmed.
Page 18
Delicate cotton, viscous and QUICK mixed delicate fabrics WASH lightly soiled Delicate cotton fabrics, delicate DAILY coloureds that are lightly soiled WASH OPTIONAL WITH PREWASH BUTTON PRESSED FUNCTION ENABLED FUNCTION DISABLED Reference programme for energy classification purposes according to standard EN 60456 SM1638...
