Upright Freezer
Thank you for your trust and for buying this appliance. We hope it will
The upright freezer for domestic use is
intended for freezing fresh food and for long-
Before Putting Into Use.......................11
We Care for the Environment
Tips for Energy Saving
Important .............................................12
Storing Time During Power Supply
Interruption
Disposing of the Worn Out Appliance
Placing and Installation ......................13
Choosing the Right Place
Connection to Power Supply
Description of the Appliance ..............14
Operation Control ...............................14
Before Putting Into Use
•
Before connecting the appliance to the
mains supply, leave it stand for about 2
hours which will reduce the possibility of
malfunctions in the cooling system that
might have occurred due to transport
handling.
•
Clean the appliance thoroughly, especially
the interior (see Cleaning and
Maintenance).
Instructions for Use
These instructions for use were prepared for
the user. They describe the appliance and its
correct and safe use. They were prepared for
various types/models of appliances therefore
you might find in it description of some
functions and accesories that do not apply to
your appliance.
Mounting Instructions
Integrated appliances are equipped with
instructions for mounting the appliance into the
kitchen unit.
successfully serve the purpose for many years.
Instructions for Use
term storing of frozen food (up to one year,
depending on the kind of food).
Mode of Operation
Red Control Light
Use.........................................................15
Freezing Fresh Foods
Storing Frozen Foods
Defrosting of Frozen Food
Maintenance and Cleaning .................17
Freezer Defrosting
Cleaning the Appliance
Switch Off the Appliance When Not in Use
Trouble Shooting Guide......................17
The appliance should be professionally
mounted by qualified technician and
instructions are for his use only.
We Care for the Environment
•
Our products use environmentally friendly
packaging, which can be either recycled or
disposed of in an environmentally friendly
manner. To this end, individual packaging
materials are clearly marked.
•
These instructions are printed either on
recycled paper or chlorine free bleached
paper.
•
When your appliance finally wears out,
please try not to burden the environment
with it; call your nearest authorised service
agent. (See Disposing of the Worn Out
Appliance)
EN
11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smeg VI144AP
Summary of Contents for Smeg VI144AP
-
Page 1: Before Putting Into Use
Upright Freezer Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. The upright freezer for domestic use is term storing of frozen food (up to one year, depending on the kind of food). - Page 2 • especially when the weather is wet and hot. Ice and frost layer increase energy Once you open the door, mind to close it as consumption, so do clean the appliance as soon as possible. This is especially soon as the layer is 3-5 mm thick.
-
Page 3: Placing And Installation
The connection to the mains supply and least 30 cm away from the oil or coal stove. If earthing have to be made according to current this is not possible, use an appropriate standards and regulations. -
Page 4: Description Of The Appliance
Use two pointers of the same colour • These accumulators can as well be used - one for the kind of food and the other for the for maintaining lower temperatures of foods months the package was loaded into the and bottles, for example when you make a appliance. -
Page 5: Operation Control
(Red and yellow control light are on). When the freezing. red light goes off, wait for a couple of hours and • Choose correct packaging for each kind of load the freezer with packages of fresh foods. - Page 6 • you intend to freeze smaller amount of It is most important that the food is frozen as fresh foods (1-2 kg). quickly as possible. We therefore recommend the size of the package not to...
-
Page 7: Maintenance And Cleaning
• Avoid using defrosting sprays, as they may cause damage to the plastic parts and may If you do not intend to use the appliance for a be hazardous to health. longer period of time, disconnect the power supply, empty the appliance, defrost it and clean it. - Page 8 The Door is Hard to Open • After starting the appliance, the operation If you want to open the door that has just or of the compressor and the refrigerant flow recently been closed, you may find it hard to may be louder, which does not mean that open.
