INSTRUCTION MANUAL
DISHWASHER

Advertisement

loading
Need help?

Need help?

Do you have a question about the STC75NZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg STC75NZ

Summary of Contents for Smeg STC75NZ

  • Page 1 INSTRUCTION MANUAL DISHWASHER...

  • Page 2: Table Of Contents

    Cleaning and maintenance _______________________________ 28 Troubleshooting ________________________________________ 32 Thank you for choosing this product. We advise you to carefully read all the instructions contained in this manual, in order to understand how to operate your dishwasher safely and correctly. The manual is divided into paragraphs, which provide a step by step...

  • Page 3: Safety Instructions

    THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER AND MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE DOOR. THE NAME PLATE ON THE INNER EDGE OF THE DOOR MUST NEVER BE REMOVED. DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED WITHIN THE HOME.
  • Page 4 DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE WHICH MAY CAUSE AN EXPLOSION. DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINTS. LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK.
  • Page 5 WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER. The manufacturer declines all responsibility for damage to persons or property resulting from failure to observe the above precautions, from tampering with even a single component of the appliance, or from the use of non original spare parts.

  • Page 6: Installation And Hook-Up

    Some protective systems preventing access to the door opening and closing mechanisms are not active until the appliance has been installed. If the appliance is not built into a cabinet, or is built into a cabinet but without one or both front panels, some mechanical parts which may cause serious injury when the door is opened and closed are accessible.
  • Page 7 Installation instructions 2.1 Water supply connection Preventing the risk of clogging or damage: if the water pipe is new or has not been used for a long time, before connecting to the water supply check that the water is clear and free of impurities, to prevent damage to the appliance.
  • Page 8 N = blue = yellow-green In the event of damage to the supply cord, have it replaced by the an Authorized Technical Service Centre in order to avoid any risk. If this lamp needs changing, contact the manufacturer or an Authorised Service Centre.
  • Page 9 Fit replacement 13A fuse into fuse cover. Refit both into plug. The fuse cover must be refitted when changing a fuse and if the fuse cover is lost the plug must not be used until a correct replacement is fitted.

  • Page 10: Description Of The Controls

    Illumination of this light signals that rinse aid dispenser is empty EXTRA PROGRAM BUTTON This button gives access to the one of the five extra programs (see table). EXTRA PROGRAM LIGHT Illuminates to indicate that one of the five extra programs (see table) is going to be executed.
  • Page 11 "3/1" OPTION LIGHT Illuminates to indicate that the function is activated. PROGRAM DELAY BUTTON Press this button to delay the start of the program by up to 9 hours. INFORMATION DISPLAY SETTING THE WASHING PROGRAM AND SWITCHING ON To select the most suitable program for the dishes to be washed refer to the table below, which indicates the most appropriate program according to dish type and degree of soiling.
  • Page 12 (2) The cycle duration and power consumption may vary according to the water and room temperatures, and the type and amount of dishes. (3) The stated water and power consumption values refer to nominal conditions. Real values are affected by the type of load of dishes, room temperature and incoming water temperature.
  • Page 13 The 3/1 option (7) can be selected in alla programs except the soak program. To execute programs 6,7,8,9,10 users must first press the extra programs button (5). Reference program as AS/NZS 2007 (6 grams on the door + 15 grams in the detergent dispenser).
  • Page 14 User instructions The washing cycle will not take place if the dishwasher door is left open or not properly closed. 3.2 Washing programs Before starting a washing program make sure that: The water supply tap is open. The correct amount of detergent has been added to the dispenser.
  • Page 15 "main" program (1, 2, 3, 4 or 5). This function is retained in the memory, so the button has to be pressed again (the light goes out) if the user wishes to execute one of the 5 main programs at the next cycle.
  • Page 16 The PROGRAM DELAY button (9) can be pressed to delay the start of the program by up to 9 hours. This means that the dishwasher can be operated at the time of day of your choice. Press the button several times in succession and the display will show the delay with which the appliance will start, beginning from 9 hours.
  • Page 17 ° ADJUSTING THE WATER SOFTENING SYSTEM N.B.: for the setting below to be possible, a washing program other than the soak program must be set. Press the PROGRAM DELAY button (10) and keep it pressed until the preset value appears followed by a full stop (normally 3.).
  • Page 18 User instructions If the door has to be opened while washing is in progress, the program will be interrupted. The relative light will keep flashing and a beeper will signal that the cycle has not been completed. When the door is closed the program will continue from where it was interrupted.

  • Page 19: Operating Instructions

    Remove any salt residues around the opening before screwing the cap back on. When using the dishwasher for the first time, in addition to the salt it is also necessary to add one litre of water to the container.
  • Page 20 4.2 Using the rinse aid and detergent dispensers The detergent and rinse aid dispensers are on the inside of the door; rinse aid on the left and detergent on the right.
  • Page 21 Close the door S. Use a cloth to remove any spillage of rinse aid which might lead to the formation of excess foam. ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness.
  • Page 22 ADDING THE DETERGENT After adding the detergent, to close the lid slide it in the direction shown by the arrow as far as it will go then press gently to lock. During washing, the dispenser will be opened automatically. Use only detergents specially formulated for dishwashers. For optimal washing results it is important to use a good quality detergent.
  • Page 23 The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. 4.3 General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 24 If in doubt as to the fastness of the colours, it is advisable to wash just a few items at a time for approximately one month.
  • Page 25 User instructions 4.4 Using the baskets The dishwasher has a capacity of 7 place-settings, including serving dishes. CAUTION: do not place items in positions where they prevent the detergent dispenser hatch from opening properly.
  • Page 26 User instructions The basket is fitted with plate racks which can be stowed horizontal if required. CUTLERY BASKET Cutlery must be placed with the tips facing downward. The cutlery basket features an exclusive system of independent sliding tip-up supports, offering a series of combinations to allow...

  • Page 27: Cleaning And Maintenance

    To remove the orbital spray arm assembly, take hold of the longer arm and pull the orbital unit upward. Wash the arms under a jet of running water and return them carefully to their seat. After reassembly, check that the spray...
  • Page 28 User instructions To remove the top spray arm, take off the retainer ring-nut. Wash it in a jet of water and fit it into place correctly, checking that there are no impediments of any kind preventing it from turning freely.
  • Page 29 DISUSE: Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. Plug the power cord back into the socket.
  • Page 30 If there are visible traces of rust inside the tank: the tank is made of steel, and therefore any rust marks are due to external elements (fragments of rust from the water pipes, pots, cutlery, etc.).

  • Page 31: Troubleshooting

    User instructions 6. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Water heating malfunction The water is not heated or the heating parameters are not correct.
  • Page 32 To “reset” an alarm is necessary: Open and close the door, or turn off and on the machine. At this point is possible to program the dishwasher again.
  • Page 34 55 55 55 55 50 50 50 50 45 45 45 45 40 40 40 40 35 35 35 35 30 30 30 30 25 25 25 25 20 20 20 20 15 15 15 15 10 10 10 10...
