A
x1 Table Top
x1 Dessus de table
x1 Tablero de mesa
E
x17 Flat Washer Ø5/16"x19x2mm
x17 Rondelle plate Ø5/16"x19x2mm
x17 Arandela plana Ø5/16"x19x2mm
H
x16 Allen bolt Ø5/16"x38mm
x16 Vis à tête creuse hexagonale Ø5/16"x38mm
x16 Perno Allen Ø5/16"x38mm
Page 1 of 4
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
PRODUCT NUMBER(S) : P367DJ230/231
Description :
Round Ped Table Base/
Round Ped Table Top/
B
x1 Support panel
x1 Panneau de support
x1 Panel de soporte
F
*
x17 Lock washer Ø5/16"
x17 Rondelle de blocage Ø5/16"
x17 Arandela de Seguridad Ø5/16"
x1 Allen Key 5mm
*
x1 Clé hexagonale 5mm
x1 Llave Allen 5mm
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
Base de table
/ Base de mesa
Dessus de table
/ Tablero de mesa
C
x1Table Leg Lower
x1 Patte de table
x1 Pata de mesa
*
x1 Allen bolt Ø5/16"x64mm
x1 Vis à tête creuse hexagonale Ø5/16"x64mm
x1 Perno Allen Ø5/16"x64mm
J
*
D
x1Table Leg Upper
x1 Patte de table
x1 Pata de mesa
G
*
*
Replaceable part
