x1 Mirror
x1 Mirror Support
x1 Miroir
x1 Supporte de miroir
x1 Espejo
x1 Soporte del espejo
E
∅
x8 Flat Washer
1/4"x19x2mm
∅
x8 Rondelle plate
1/4"x19x2mm
∅
x8 Arandela plana
1/4"x19x2mm
Page 1 of 3
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
PRODUCT NUMBER(S) : P367DJ110
Description : Mirror / Miroir / Espejo
B
*
F
*
x1 Allen Key 4mm
x1 Clé hexagonale 4mm
x1 Llave Allen 4mm
C
∅
*
x8 Bolt
1/4"x38mm
∅
x8 Boulon
1/4"x38mm
∅
x8 Perno
1/4"x38mm
*
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
D
*
∅
x8 Lock washer
1/4"
∅
x8 Rondelle de blocage
x8 Arandela de Seguridad
*
Replaceable part
1/4"
∅
1/4"
