Installation and Operating Instructions
MODULAR FREESTANDING STOVES
STOVE-800
Save this manual and keep it in a safe place that it is easy to refer to it.
The Spartherm module stoves have been tested and certified by CSA based on
the following standards: UL-1482 & Can/ULC S 627-21. EPA : U.S.ENVIRONMENTAL
PROTECTION AGENCY Certified to comply with 2020 emissionstandards using
cord wood.
1
Spartherm Feuerungstechnik GmbH
Maschweg 38 · 49324 Melle
Phone +49 5422 94 41-0
www.spartherm.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STOVE-800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spartherm STOVE-800

Summary of Contents for Spartherm STOVE-800

  • Page 1 Installation and Operating Instructions MODULAR FREESTANDING STOVES The Spartherm module stoves have been tested and certified by CSA based on STOVE-800 the following standards: UL-1482 & Can/ULC S 627-21. EPA : U.S.ENVIRONMENTAL PROTECTION AGENCY Certified to comply with 2020 emissionstandards using Spartherm Feuerungstechnik GmbH cord wood.
  • Page 2 INTRODUCTION AND UNIT DESCRIPTION WARRANTY • Make sure not to create negative pressure in the SAFE WOOD-BURNING PRACTICES SPARTHERM MODULAR FREESTANDING STOVES-800. PLEASE REFER TO WARRANTY CONDITIONS IN THE installation room, e.g. by means of an exhaust fan MANUAL. or similar mechanical blower, as this could affect the...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. Installation overview 6. Operation 6.1 Fire extinguishers / smoke detectors 2. Introduction 6.2 Fuel 2.1 Example of identification plate 6.3 Lighting a fire 2.2 Dimensions 6.3.1 Flash fire 2.3 Specification 6.3.2 Extended fire 2.4 General instructions 6.3.3 Smoking 2.5 General Information 7.

  • Page 4: Installation Overview

    1. INSTALLATION OVERVIEW SPECIFICATIONS MODULAR FREESTANDING STOVE-800 Spartherm Modular Freestanding Stove Stove-800 Weight of Module 364 LBS Module exterior: Width/depth/height (inches) 32 1/8" 18 7/8" 24 13/16" Recommended amount of wood when fueling (lbs/kg) wood: 2-3 logs of wood of app.

  • Page 5: Introduction

    (e.g. rain, etc.) and keep the appliance dry at It is IMPORTANT to use dry wood that has a moisture The Spartherm modular freestanding stoves have been • Young children should be carefully supervised when all times. Wet insulation will produce an odour when content of less than 18%.

  • Page 6: Example Of Identification Plate

    1.3 g/hr emission rate 1.3 g/hr 24 13/16" (630 mm) Do not obstruct combustion air openings. Model: Spartherm Cassette 800 Module Model: Spartherm Cassette 800 Module AVERTISSEMENT; n’obstruez pas l’espace sous le radiateur. Date of Manufacture: Month/Year: 06/2023 N’obstruez pas les ouvertures d’air de combustion.

  • Page 7: Specification

    British Thermal Unit BTU/h to Watt: 1BTU/h = of exhaust through it. The wood burning appliance and The Spartherm modular freestanding stoves are not certified for gas log ing a vacation or a warm weather season, the appliance 0.293 Watt chimney vent system also require a sufficient supply of sets.

  • Page 8: Combustion Air

    2.6 COMBUSTION AIR 2.6.1 CONNECTION DIRECTLY TO THE UNIT When mounting the air system ensure that the air control system provides fresh air from the outside. In order for the To connect the separate combustion air directly to the unit you need to have the right separate combustion air con- air system to function, you have to ensure in the structure that no vacuum occurs in the housing.

  • Page 9: Installation Planning

    CLOSURE VALVE PLEASE NOTE: COMBUSTION AIR IN TAKE REQUIREMENTS. Please contact your dealer who offers suitable parts for CAN ALSO SET OFF SMOKE ALARMS. NEGATIVE PRES- air inlet ducts (pipes and damper). SURE WITHIN YOUR HOME MAY INADVERTENTLY AFFECT It is recommended that the 5" Combustion air intake YOUR APPLIANCE.

  • Page 10: Placement From Combustible Materials

    Failure to meet the required clearances can endanger property and personal safety. Valid for Stove-800 Important: Unit cannot use small base A on non com- bustible material - must be 9 1/2" off the floor from bottom of glass or 4 1/2"...

  • Page 11: Installation

    4. INSTALLATION 4.1.1 800 AND 800 MODULE 4.1 HEARTH EXTENSION clearances description 8" / 203 mm Canada each clearances side of unit WARNING 6" / 152 mm USA 8" / 203 mm hearth extension on the rear side 16" / 406 mm for USA hearth extension length INSTALL THE HEARTH EXTENSION ONLY AS ILLUSTRATED! 18"...

  • Page 12: Combustible Wall Chimney Connector Pass-Throughs

    4.2 COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A: 12" (304.8 MM) Minimum chimney clearance to brick CLEARANCE TO COMBUSTIBLE WALL and combustibles 2 in. (50.8 mm) MEMBER: Using a minimum thickness 3.5" (89 mm) brick and a Minimum clearance 5/8" (15.9 mm) minimum wall thickness clay liner, con- 12 in.
  • Page 13 METHOD C: 6" (152.4 MM) Minimum chimney clearance CLEARANCE TO COMBUSTIBLE WALL to sheet steel supports and combustibles 2 in. (50.8 mm) MEMBER: Starting with a minimum 24 gage (.024" [.61 mm]) Two air channels 8" (203.2 mm) metal chimney connector, and a min- each 1 in.

  • Page 14: Chimney Installation

    4.3 CHIMNEY INSTALLATION 4.3.2 EX AMPLES OF T YPICAL INSTALLATIONS This wood stove is designed and approved for installation with the following brands of chimneys measuring 6" and 7" (152 and 178 mm) in diameter as well as a minimum of 15’ (4,6 m) and maximum of 45’ (13,5 m) in height. straight chimney installation 4.3.1 LISTED CHIMNEYS This appliance must be installed with a listed 6"...
  • Page 15 rain cap less than 10 ft. chimney 10" 10 ft. to nearest roofline strom collar flashing roof pitched roof minimum chimney height wall or parapet recommended location 10 ft. or more less than 10 ft. recommended location marginal location location NOT recommended flat roof THIS APPLIANCE MUST BE INSTALLED WITH A LISTED 6"/153 MM AND 7"/178,5 MM CHIMNEY SYSTEM APPROVE- DUNDER THE FOLLOWING STANDARDS: CAN-ULC S629 (IN CANADA) OR UL 103HT (IN U.S.).

  • Page 16: Convection

    5. FINISHING 4.4 CONVECTION WARNING Circulation of convection air 5.1 BRICKS AND BAFFLES OPERATION OF THE APPLIANCE WITHOUT THE BAF- INSTALLATION The convection air enters into the wood stove via the inlet FLES CAN RESULT IN EXCESSIVE TEMPERATURES at the bottom of the wood stove. The hot air for convec- THAT COULD DAMAGE THE APPLIANCE, CHIMNEY tion comes out of the wood stove via the front outlet and AND THE SURROUNDING ENCLOSURE.

  • Page 17: Door Removal / Installation

    5.2 DOOR REMOVAL / INSTALLATION WARNING BURNING YOUR APPLIANCE WITH THE DOORS OPEN OR AJAR CREATES A FIRE HAZARD THAT MAY RESULT IN A HOUSE AND/OR CHIMNEY FIRE. DO NOT STRIKE OR SLAM DOOR. NEVER REMOVE THE DOOR WHEN THE APPLIANCE IS HOT.

  • Page 18: Operation

    Pre-set combustion air setting. AFTER USE!!! pattern. The flames will get smaller and lazier because Spartherm Modules are equipped with an air control ALWAYS OPERATE THIS APPLIANCE WITH THE less oxygen is getting into the combustion chamber. system that you have a fire that burns clean and well.
  • Page 19 CAUTION: DOOR ASSEMBLY - SPARE PARTS. WARNING The Spartherm Module 800 has a pre-set combustion ROBAX 4 MM CERAMIC GLASS. air setting. USE ONLY AS PER MANUFACTURERS STANDARD AND SPARE PARTS. The combustion-air damper should NOT be altered for increased firing for any reason!

  • Page 20: Fire Extinguishers / Smoke Detectors

    6.1 FIRE EXTINGUISHERS / SMOKE height and burn at a medium low setting. The whiteness Firewood should be split, stacked in a manner that air 6.3 LIGHTING A FIRE of the bricks and the cleanliness of the glass are good can get to all parts of it and covered in early spring to DETECTORS indicators of your operating efficiency.

  • Page 21: Flash Fire

    7. MAINTENANCE 12. Always open the firebox door slowly. This will ensure 6.3.3 SMOKING to help maintain a hot charcoal bed. Keep the closed that you avoid sudden low pressure in the firebox and container on a noncombustible floor or ground, well prevent exhaust gases leaking into the living room.

  • Page 22: Chimney Cleaning

    NOT OPERATE APPLIANCE WITH GLASS REMOVED, Both the chimney and the appliance must be inspected WARNING CRACKED, BROKEN OR SCRATCHED. All Spartherm modules are supplied with Robax glass in and cleaned at least once a year. the door. Installation: Robax is a ceramic glass.

  • Page 23: Exploded View

    Please refer to the following drawing and speficy the spare part number and WHICH UNIT SIZE YOU HAVE FOR REPLACEMENTS SPARTHERM ACCESSORIES Frame Firebox door with ceramic glass Modular Freestanding Stoves Description Part Firebox lining Spartherm Stove-800 Firebox Optional Combustion Air Exhaust gas sockets, rotatable Appliance Connector Required Accessories (vertically or horizontally)

  • Page 24: Troubleshooting

    DO NOT USE ABRASIVE CLEANERS. you to have your wood stove module/ Setting up or installing this product requires specialized If such proof is not produced Spartherm Feuerungstech- stove serviced regularly by a stove fitter. knowledge. Our products may therefore only be installed nik GmbH shall not be obliged to honour the warranty.

  • Page 25: Service History

    11. SERVICE HISTORY Appliance Service History This heater must be serviced annually depending on usage. Date Dealer Name Service Technician Name Service Performed Special Concerns...
  • Page 28 SPARTHERM THE GLOBAL BRAND FOR YOUR LIVING ROOM Your specialist dealer Spartherm Feuerungstechnik GmbH · Maschweg 38 · 49324 Melle Phone +49 5422 94 41-0 · www.spartherm.com...
