- Page 1 VESA Compatible Laptop Tray with RGB Fan SKU: STAND-LAP5F Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-lap5f...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents A (x1) B (x2) C (x2) Laptop Tray Latch Included Hardware & Tools M-A (x4) M-B (x4) M4x12mm Screw M5 Washer Tools Needed: Weight Capacity: 19.8lbs (9kg) Phillips Screwdriver...
-
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Install Arms (B) onto the Laptop Tray (A) using Latches (C). Lay Latches (C) over the Laptop Tray (A) with one set of the hooks aligned with the slot on the tray and the other offset from the edge of the tray. - Page 5 STEP 2 Install Laptop Tray (A) to a VESA plate using the M4x12mm Screws (M-A) and M5 Washers (M-B). Tighten the screws using a Phillips screwdriver. M-A (x4) M-B (x4)
- Page 6 STEP 3 Adjust the Laptop Tray (A) size by pulling down the levers on Arms (B). Adjust the Arms (B) to your desired width.
- Page 7 STEP 4 Place the laptop on the Laptop Tray (A) and tighten the Arms (B) to secure. Press the levers on the Arms (B) back in to lock in place. Plug the USB-A cable into any 5V power supply to...
- Page 8 LAST UPDATED: 01/11/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
