Black Sliding Under Desk Laptop Tray
Instruction Manual
SKU: DESK-AC02A
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-ac02a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-AC02A and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo DESK-AC02A

Summary of Contents for Vivo DESK-AC02A

  • Page 1 Black Sliding Under Desk Laptop Tray Instruction Manual SKU: DESK-AC02A Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-ac02a GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 STEP 2 WARNING! Pre-drill 15mm/.59" holes into desktop using 5/32" drill bit. Install two ST5.5x19mm screws (S-A) into left holes, as shown below, leaving a 5mm gap. If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician.
  • Page 3 STEP 4 STEP 3 Slide Mount (A) onto previously installed screws using keyhole slots. Use a Phillips screwdriver to Secure Tray (B) to Mount (A) using M6x12mm Screws (S-B), M6 Lock Washers (S-C), M6 Washers (S-D), secure. and a Phillips screwdriver. Tray can be installed using upper or lower holes to achieve desired height. Install remaining ST5.5x19mm Screws (S-A) to secure Mount (A) to desktop using a Phillips screwdriver.
  • Page 4 STEP 5 STEP 6 Swivel assembly left or right to achieve desired position. Loosen knobs on Tray (B) to adjust tray extension. Tighten knobs when desired adjustment is reached.
  • Page 5 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
