- Page 1 f o r S T M 3 2 R E S I S T I V E F P I...
- Page 2 Thank you for choosing MIKROE! We present you the ultimate multimedia solution for embedded development. Elegant on the surface, yet extremely powerful on the inside, we have designed it to inspire outstanding achievements. And now, it’s all yours. Enjoy premium.
-
Page 3: Table Of Contents
Ta b l e o f c o n t e n t s Introduction 4.2 External flash storage 1.Key microcontroller features 5. Connectivity 1.1 MCU programming/debugging 5.1 USB 1.2 MCU reset 5.2 RF 2. Power supply unit 5.3 WiFi 2.1 Detailed description 5.4 mikroBUS shuttle connectors... - Page 4 Pick your own look Identical in the back, choices up front. mikromedia 5 for STM32 Resistive FPI with bezel mikromedia 5 for STM32 Resistive FPI with frame...
-
Page 5: Introduction
5 for STM32 RESISTIVE FPI is a compact development The usability of mikromedia 5 FPI does not end with its ability to board designed as a complete solution for the rapid development of accelerate the prototyping and application development stages: it multimedia and GUI-centric applications. -
Page 6: Key Microcontroller Features
∫ Operating frequency up to 168 MHz ∫ 210 DMIPS / 1.25 DMIPS/MHz (Dhrystone 2.1) For the complete list of MCU features, please refer to the STM32F407ZGT6 datasheet mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... - Page 7 ∫ Operating frequency up to 216 MHz ∫ 462 DMIPS / 2.14 DMIPS/MHz (Dhrystone 2.1) For the complete list of MCU features, please refer to datasheet . the STM32F746ZGT6 mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L...
-
Page 8: Mcu Programming/Debugging
The board is equipped with the Reset button (2), which is located on the back side of the board. It is used to generate a LOW logic level on the microcontroller reset pin. mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 10: Power Supply Unit
Figure 4: Power supply unit view mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 11: Detailed Description
2.1 Detailed description The next PSU stage uses two MIC28511, synchronous step- The PSU has a very demanding task of providing power for the host down (buck) regulators, capable of providing up to 3A. The MCU and all the peripherals onboard, as well as for the externally MIC28511 IC utilizes the HyperSpeed Control and HyperLight ®... -
Page 12: Psu Connectors
USB host (typically PC), USB power bank, or USB wall adapter. When powered over the USB connector, the available power will depend on the source capabilities. Figure 5: Power supply connectors view mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... - Page 13 2.3.2 12VDC screw terminal Maximum power ratings, along with the allowed input voltage range in the case when the USB power supply is used, are given in the table Figure 6: An external 12V power supply can be connected over the 2-pole screw terminal (labeled as TB1).
- Page 14 Using low-quality USB hubs, and too long or low-quality USB cables, may cause a significant USB voltage drop, which can obstruct the battery charging process. mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L...
-
Page 15: Power Redundancy & Ups
5 FPI during the LED indicator labeled as PWR indicates that the mikromedia 5 FPI transition period). is powered ON. Figure 9: Battery power supply connection mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 16: Resistive Display
5 for STM32 RESISTIVE FPI U S E R M A N U A L... - Page 17 Figure 10: Display and SSD1963 view...
-
Page 18: Data Storage
100 years. It also uses the SPI a proper software/firmware running on the host MCU is required. interface for the communication with the MCU. mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 19: Connectivity
When mikromedia 5 FPI is working in USB HOST mode, it must not N O T E indication functions. be mounted to another USB HOST (such as PC). mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... - Page 20 GPIO pins for the SPI Chip Select, Chip Enable, and for the interrupt. The RF section of the mikromedia 5 FPI also features a small chip antenna as well as SMA connector for external antenna. mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L...
-
Page 21: Wifi
Figure 13: RF and WiFi view There is a chip antenna integrated on the PCB of the mikromedia 5 FPI as well as SMA connector for external WiFi antenna. mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 22: Mikrobus ™ Shuttle Connectors
∫ An arbitrary length of flat cables may be used (depending on the particular use cases) ∫ Connectivity can be additionally expanded, by cascading these connectors using Shuttle click mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... - Page 23 For more information about mikroBUS Shuttle extension board and Shuttle ™ Click, please visit web pages: www.mikroe.com/mikrobus-shuttle www.mikroe.com/shuttle-click For additional information about the mikroBUS , please visit the official web ™ page at www.mikroe.com/mikrobus Figure 14: mikromedia 5 FPI connected to mikroBUS Shuttle view...
-
Page 24: Sound-Related Peripherals
5 for STM32 RESISTIVE FPI U S E R M A N U A L mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 25: Audio Codec
5 FPI development board. The mikromedia 5 FPI board is equipped with the 3.5mm four-pole headphones jack (3), allowing to connect Figure 15: mikromedia 5 FPI back view a headset with a microphone. mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L... -
Page 26: Sensors And Other Peripherals
SMD jumpers grouped under the ADDR SEL label (1). mikromedia 5 for STM32 RESISTIVE FPI U S E R M A N U A L mikromedia 5 for STM32 RESISTIVE U S E R M A N U A L... -
Page 27: Real-Time Clock (Rtc)
SR60, LR60, 364 button cell battery types, allowing it to include a real time clock within the applications. Figure 16: mikromedia 5 FPI back view mikromedia 5 for STM32 RESISTIVE U S E R M A N U A L... - Page 28 I D E A L C O D I N G PICK NECTO DESIGNER FOR GUI APPS Build Smart GUI apps easily with NECTO Studio designer and LVGL Graphics Library.
-
Page 30: What's Next
What’s next? You have now completed the journey through each and every feature of mikromedia 5 for STM32 RESISTIVE FPI development board. You got to know its modules and organization. Now you are ready to start using your new board. We are suggesting several steps which are probably the best way to begin. - Page 31 (including damages for loss of business profits and business information, business interruption or any other pecuniary loss) arising out of the use of this manual or product, even if MIKROE has been advised of the possibility of such damages. MIKROE reserves the right to change information contained in this manual at any time without prior notice, if necessary.
- Page 32 If you want to learn more about our products, please visit our website at www.mikroe.com If you are experiencing some problems with any of our products or just need additional information, please place your ticket at www.mikroe.com/support Time-saving embedded tools If you have any questions, comments or business proposals, do not hesitate to contact us at office@mikroe.com...
