- Page 1 DV42H5400* DV42H5200* DV42H5000* Gas and Electric Dryer User manual Imagine the possibilities Thank you for purchasing this Samsung product.
-
Page 2: Table Of Contents
Contents Safety instructions What you need to know about safety instructions Important safety symbols and precautions ............. .4 CALIFORNIA PROPOSITION 65 WARNING Important safety instructions Installing your dryer... - Page 3 Operating instructions, tips Overview of the control panel Load the dryer properly ................29 Getting started .
-
Page 4: Safety Instructions
Safety instructions Congratulations on your new Samsung Dryer. This manual contains important information on the installation, use, and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many benefits and features. -
Page 5: California Proposition 65 Warning
CALIFORNIA PROPOSITION 65 WARNING WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov. WARNING - RISK OF FIRE • Clothes dryer installation must be performed by a qualified installer. • Install the clothes dryer according to the manufacturer’s instructions and local codes. •... -
Page 6: Important Safety Instructions
Important safety instructions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: Read all instructions before using this appliance. Do not dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry- cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode. - Page 7 CAUTION 1. Do not sit on top of the dryer. 2. Because of continuing product improvements, Samsung reserves the right to change specifications without notice. For complete details, see the Installation Instructions packed with your product before selecting cabinetry, making cutouts, or beginning installation.
-
Page 8: Installing Your Dryer
Unpacking your dryer Unpack your Dryer and inspect it for shipping damage. Make sure you have received all the items shown below. If your Dryer was damaged during shipping, or you do not have all the items, contact 1-800-SAMSUNG (726-7864). WARNING Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. -
Page 9: Accessories (Steam Model Only)
Accessories (Steam model only) “Y”-connector Short inlet hose Long inlet hose Important to installer Please read the following instructions carefully before installing the dryer. These instructions should be kept for future reference. WARNING: Remove the door from all discarded appliances to avoid the danger of a child being trapped and suffocating. -
Page 10: Location Considerations
Location considerations The dryer should be located where there is enough space at the front for loading the dryer, and enough space behind for the exhaust system. This dryer is factory-ready for the rear exhaust option. To exhaust out the bottom, right or the left, use the accessory exhaust kit. - Page 11 External exhaust elbow requires additional space (L). Stacking (MODEL NO: SKK-7A/SKK-8K) Samsung’s Washer and Dryer can be stacked to maximize usable space. You can purchase an optional stacking kit from your Samsung retailer. For details about stacking and compatible models, refer to the user manual included in the stacking kit you purchase.
-
Page 12: Ducting Requirements
Ducting requirements Weather hood type 4” (10 .16 cm) 2.5” (6.35 cm) No. of 90° elbows Recommended Use only for short-run installation Rigid Rigid 24.4 m (80 ft.) 22.6 m (74 ft.) 20.7 m (68 ft.) 18.9 m (62 ft.) 17.4 m (57 ft.) 15.5 m (51 ft.) 14.3 m (47 ft.) -
Page 13: Exhausting
If the new dryer is installed into an existing exhaust system you must make sure: • The exhaust system meets all local, state, and national codes. • That a flexible plastic duct is not used. • To inspect and clean all lint buildup from inside the existing duct. •... -
Page 14: Dryer Exhaust Tips
Dryer exhaust tips WARNING: A plastic or non-metal flexible duct presents a potential fire hazard. • Make sure your dryer is installed properly so it exhausts air easily. • Use a 4” diameter rigid metal duct. Tape all joints, including at the dryer. 4”... -
Page 15: Gas Requirements
Gas requirements The installation must be conformed with local codes, or in the absence of local codes, with the national fuel gas code, ANSI Z223.1/NFPA 54, latest revision(for the UNITED STATES), or with the natural gas and propane installation code, CSA B149.1(for Canada). •... -
Page 16: Exhaust Ducting Guide
Exhaust ducting guide Ducting 1. Make sure the dryer is installed properly so the air exhausts freely. 2. Use 4-inch rigid metal ducts. Tape all joints including the dryer connection. Never use lint-trapping screws. 3. To facilitate the exhaust, keep the ducts as straight as possible. Cleaning Clean all old ducts before installing the dryer, and make sure the vent flap opens and closes freely. -
Page 17: Electrical Connections
Electrical connections Before operating or testing, follow all grounding instructions in the “Grounding” section on page 9. An individual branch (or separate) circuit serving only your dryer is recommended. DO NOT USE AN EXTENSION CORD. Gas models – U.S. and Canada A 120 volt, 60 Hz AC approved electrical service, with a 15-ampere fuse or circuit breaker is required. - Page 18 3-WIRE system connections 1. Loosen or remove the center terminal block screw. 2. Connect the neutral wire (white or center wire) of the power cord to the center, silver-colored terminal screw of the terminal block. Tighten the screw. 3. Connect the other wires to the outer terminal block screws. Tighten the screws. 4.
-
Page 19: Connecting The Inlet Hose (Steam Model Only)
Connecting the inlet hose (Steam model only) The dryer must be connected to the cold water faucet using the new inlet hoses. Do not use old hoses. 1. Turn the cold water faucet off. 2. Attach the brass female end of the Y connector (A) to the cold water faucet. -
Page 20: Replacement Parts And Accessories
Replacement parts and accessories If your dryer requires replacement parts or accessories, contact the dealer where you purchased your dryer or the SAMSUNG customer care center at 1-800-SAMSUNG (726-7864). Installation For the proper installation, we recommend that you hire a qualified installer. -
Page 21: Door Reversal
6. Review the “Gas requirements” section on page 15. Remove the pipe thread protective cap. Apply a pipe joint compound or about 1½ wraps of Teflon tape over all threaded connections. The pipe joint compound must be resistant to the actions of any liquefied petroleum gas. Connect the gas supply to your dryer. -
Page 22: Type 2
8. Remove a screw from the door hinge. The screw is for pre-fixing the door to the frame front. 9. Reassemble the screw in the other hole. 10. Place the door on the other side and reattach it to the dryer. 11. - Page 23 5. Remove the two screws from the opposite side of the door hinge. 6. While holding down the upper hook (A) using the flat-head screwdriver in your right hand, pull out the upper area of the holder lever with your left hand to remove. 7.
-
Page 24: Final Installation Checklist
11. Fit the lower area of the holder lever in the frame-front hole in the arrow direction, and push in the holder lever to the end while holding down the hook (A). 12. Reattach the screws in the remaining holes. 13. -
Page 25: Overview Of The Control Panel
Operating instructions, tips To reduce the risk of fire, electric shock, or injury to persons,read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. Overview of the control panel The courses and functions differ depending on the model. Please check your model before proceeding. DV42H5400* DV42H5200* DV42H5000*... - Page 26 1. Cycle selector To select a cycle, rotate the Cycle selector dial to the desired cycle. The indicator light by the cycle name will illuminate. The ECO NORMAL, NORMAL, HEAVY DUTY, BEDDING, SANITIZE, PERM PRESS, WOOL and DELICATES cycles are Sensor Dry cycles. Sensor Dry automatically senses the moisture in the load and shuts the dryer off when the selected dryness level (Very Dry to Damp Dry) is reached.
- Page 27 CYCLE RECOMMENDED ITEMS DETAILS This cycle is best for smoothing out wrinkles and Shirts, Trouser, Comforter, reducing odors from loads consisting of one to four dry REFRESH Pillows (Confirm that the items. In this cycle a small amount of water is sprayed laundry load is dry) into the dryer drum after several minutes of tumbling with heat.
- Page 28 3. Dry Level To select the dry level in the NORMAL, HEAVY DUTY, or other Sensor Dry cycles, press the Dry Level button. An indicator light will illuminate next to the desired dryness level. Press the button repeatedly to scroll through the settings. Larger or bulkier loads may require the Very Dry or More Dry setting for complete dryness.
-
Page 29: Load The Dryer Properly
Load the dryer properly • Place only one washload in your dryer at a time. • Mixed loads of heavy and lightweight fabrics will dry differently, which may result in lightweight fabrics being dry while heavy fabrics remain damp at the end of a drying cycle. •... - Page 30 Cycle overview Predefined DRY LEVEL TEMPERATURE CYCLE LOAD SIZE Predefined Adjustable Predefined Adjustable NORMAL Large Normal Dry High HEAVY DUTY Large Normal Dry High BEDDING Large Normal Dry High SANITIZE Large Very Dry High Sensor Dry PERM PRESS Medium Normal Dry Medium WOOL Small...
-
Page 31: Rack Dry (Applicable Models Only)
Drying foam rubber, plastic, or rubber on a heat setting may cause damage to the items and lead to a fire hazard. The drying rack is not included in the DV42H5200* and DV42H5000* models. You can purchase the drying rack (part code: DC93-00374G) at a local Samsung service center. English - 31... -
Page 32: Child Lock
Child Lock Prevents children from playing with your dryer. Setting/Releasing To turn Child Lock on or off, press both the Temp. and Time buttons simultaneously for 3 seconds. Child Lock Details 1. You can turn Child Lock on while your dryer is running. 2. -
Page 33: My Cycle
Smart Care app. Downloading the Smart Care app Download the Samsung Laundry App into your mobile phone from the Android market or Apple App store. (Search word : Samsung Smart Washer/Dryer) Precautions when using Smart Care •... -
Page 34: Care And Cleaning
Care and cleaning WARNING Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service Personnel - Do not contact the following parts while the appliance is energized: Control board and inlet valve. Control panel Clean with a soft, damp cloth. -
Page 35: Special Laundry Tips
Special laundry tips Special laundry tips Please follow the care label or manufacturer’s instructions for drying special items. If care label instructions are not available, use the following information as a guide. Follow the care label instructions or dry on the BEDDING cycle. Bedspreads &... -
Page 36: Troubleshooting
Troubleshooting Check these points if your dryer… PROBLEM SOLUTION • Make sure the door is latched shut. • Be sure the power cord is plugged into a live electrical outlet. Doesn’t run. • Check the home’s circuit breaker and fuses. •... -
Page 37: Information Codes
Electronic Control Problem Call for service. (Over Voltage Error.) Electronic Control Problem Call for service. (Communication Error.) Invalid state of Eeprom Call for service. communication. Invalid door. Call for service. For any codes not listed above, call 1-800-SAMSUNG (726-7864) English - 37... - Page 38 Appendix Fabric care chart The following symbols provide garment care direction. The Clothing care labels include symbols for washing, bleaching, drying, and ironing, or dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to maximize garment life and reduce laundering problems.
- Page 39 Protecting the environment This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance. Declaration of conformity This appliance complies with UL2158.
- Page 40 SAMSUNG authorized servicers within the customer’s geographic area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of the product to and from an authorized service center. If the product is located in an area where service by a SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring the product to a SAMSUNG authorized service center for service.
- Page 41 FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
- Page 42 If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized service center. SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
- Page 43 NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 44 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support www.samsung.com/ca/support (English) CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca_fr/support (French) DC68-03381A-19...
