DV425000_DC68-03381A.indd 1
Gas and Electric Dryer
User manual
Imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service or accessory parts,
please register your product at or contact:
www.samsung.com/register
1-800-SAMSUNG (726-7864)
DV42H5400*
DV42H5200*
DV42H5000*
2013-12-19
1:07:09
Advertisement
Table of Contents
Related Manuals for Samsung DV42H5400 Series
Summary of Contents for Samsung DV42H5400 Series
-
Page 1: User Manual
DV42H5400* DV42H5200* DV42H5000* Gas and Electric Dryer User manual Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service or accessory parts, please register your product at or contact: www.samsung.com/register 1-800-SAMSUNG (726-7864) DV425000_DC68-03381A.indd 1 2013-12-19... -
Page 2: Installing Your Dryer
Unpacking your dryer Unpack your Dryer and inspect it for shipping damage. Make sure you have received all the items shown below. If your Dryer was damaged during shipping, or you do not have all the items, contact 1-800-SAMSUNG (726-7864). WARNING •... -
Page 3: Important To Installer
Important to installer Please read the following instructions carefully before installing the dryer. These instructions should be kept for future reference. WARNING: Remove the door from all discarded appliances to avoid the danger of a child being trapped and suffocating. Basic requirements Make sure you have everything necessary for the proper installation •... -
Page 4: Location Considerations
Location considerations The dryer should be located where there is enough space at the front for loading the dryer, and enough space behind for the exhaust system. This dryer is factory-ready for the rear exhaust option. To exhaust out the bottom, right or the left, use the accessory exhaust kit. - Page 5 External exhaust elbow requires additional space (L). Stacking (MODEL NO: SK-5A) Samsung’s Washer and Dryer can be stacked to maximize usable space. The dryer legs need to be removed to stack the Washer and Dryer. You can purchase an optional stacking kit from your Samsung retailer.
-
Page 6: Ducting Requirements
Ducting requirements Weather hood type 4” (10 .16 cm) 2.5” (6.35 cm) No. of 90° elbows Recommended Use only for short-run installation Rigid Metallic Flexible* Rigid Metallic Flexible* 24.4 m (80 ft.) 12.4 m (41 ft.) 22.6 m (74 ft.) 10.1 m (33 ft.) 20.7 m (68 ft.) 11.2 m (37 ft.) - Page 7 If the new dryer is installed into an existing exhaust system you must make sure: • The exhaust system meets all local, state, and national codes. • That a flexible plastic duct is not used. • To inspect and clean all lint buildup from inside the existing duct. •...
-
Page 8: Dryer Exhaust Tips
Dryer exhaust tips WARNING: A plastic or non-metal flexible duct presents a potential fire hazard. • Make sure your dryer is installed properly so it exhausts air easily. • Use a 4” diameter rigid metal duct. Tape all joints, including at the dryer. 4”... -
Page 9: Gas Requirements
Gas requirements THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL FUEL GAS CODE ANSI/Z223.1, LATEST REVISION (FOR THE UNITED STATES), OR WITH THE CAN/CGA-B149 INSTALLATION CODES (FOR CANADA). • Use only natural or LP (liquid propane) gases. •... -
Page 10: Electrical Requirements
Electrical requirements The wiring diagram is located on the plate below the control panel. WARNING • The improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether your dryer is properly grounded. - Page 11 3-WIRE system connections 1. Loosen or remove the center terminal block screw. 2. Connect the neutral wire (white or center wire) of the power cord to the center, silver-colored terminal screw of the terminal block. Tighten the screw. 3. Connect the other wires to the outer terminal block screws. Tighten the screws. 4.
- Page 12 Connecting the inlet hose (Steam model only) The dryer must be connected to the cold water faucet using the new inlet hoses. Do not use old hoses. 1. Turn the cold water faucet off. 2. Attach the brass female end of the Y connector (A) to the cold water faucet.
-
Page 13: Replacement Parts And Accessories
Replacement parts and accessories If your dryer requires replacement parts or accessories, contact the dealer where you purchased your dryer or the SAMSUNG customer care center at 1-800-SAMSUNG (726-7864). Installation For the proper installation, we recommend that you hire a qualified installer. -
Page 14: Door Reversal
6. Review the “Gas requirements” section on page 15. Remove the pipe thread protective cap. Apply a pipe joint compound or about 1½ wraps of Teflon tape over all threaded connections. The pipe joint compound must be resistant to the actions of any liquefied petroleum gas. Connect the gas supply to your dryer. -
Page 15: Final Installation Checklist
8. Remove a screw from the door hinge. The screw is for pre-fixing the door to the frame front. 9. Reassemble the screw in the other hole. 10. Place the door on the other side and reattach it to the dryer. 11.
