RESETTING OPEN AND CLOSE LIMITS
Resetting the open and close limits is easily accomplished by accessing the Installer Menu.
Access to the Installer Menu is through the User Menu. See the flowchart (Figure 9) below. See Figure 10.
Status Display
GATE CLOSED
User Menu
To access the Installer Menu,
press and hold Reset & Open,
and then release them.
ARM POSITION SENSOR — SETTING LIMITS
Press Menu twice at
the Run Mode static
display.
Installer Menu
Learn Limits
To activate the learn limits
function, press Next which
changes the display to LL1.
Figure 9. Learn Limits Menu Layout
LL 1 (ON)
LEARN LIMITS
Figure 10. S.T.A.R.T. Learn Limits
Press Next, and then Select.
The "LL" characters blink.
Learn Close
Press Select. The
Learn Close blinks in
the display indicating
that the operator is
ready to relearn the
closed limit.
