- Page 1 T-40 User Manual T-40 User Manual...
- Page 2 Note: There may be small design differences between what you see in this manual and your actual treadmill. Your treadmill will match the one advertised on ITM.
- Page 3 Contents 1. Product Brief....................1 2. Security Precautions and Warnings..............2 3. Assembly Instructions..................5 4. Usage Instructions....................6 5. Maintenance ..................11...
- Page 4 1. Product Brief Product name: T-40 Treadmill Console Upright column Motor cover Side rail Running belt End cap Main parameters and parts list Parameters Description Input power voltage 220-240V Motor power 2.5HP Speed 1-16km/h Running area 470*1200mm Max user weight...
- Page 5 2.Security Precautions and Warnings Tips: Before folding the treadmill, make sure that the gradient is "zero". Please read the instructions carefully before use. Indoor usage and storage only. Avoid dampness and avoid water spillages. Please wear suitable clothes and trainers before exercise. Do not use the treadmill without suitable footwear, ...
- Page 6 Don't damage or bend the power cord. Don’t place heavy objects on the machine, don't squeeze the power cord in any way. Don't use the machine with more than one person or do not allow people too close to the machine when it is in use ...
- Page 7 When assembling, lightly fix all screws first, then tighten screws fully when the assembly of the frame is fully complete. 1.Carefully lift the machine out of the carton, lay it flat on the ground, and remove the nylon cable tie on the left and right sides of the main frame and bottom frame. nylon cable ………...
- Page 8 the side cover is divided into left and right), and tap it in. Side cover 4. Put safety key on the yellow area of the console to use the treadmill. Note: The safety key is red in colour. It is in a plastic bag together with the screws and tools.
- Page 9 Unfold the treadmill: Kick the pressure rod, hold the running deck and then let the running deck to fall gradually. Kick this part lower the running deck. 5)Console instructions Start The treadmill starts after pressing the start button. Amount of programs 24 automatic programs and 3 modes.
- Page 10 Program button In standby mode, press this key to cycle from manual mode to automatic program; Manual mode is the default operation mode of the system 4. Shock absorption key: press the "shock absorption +" key to increase the hardness of the running deck; Press the "shock absorption"...
- Page 11 Automatic program Time Time set / 10 = Running time of each period Program SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE...
- Page 12 SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE Code Meaning of error messages Fault code Failure Description Fault handling Communication Abnormal: Possible Cause: the communication between the lower when the power is on, the controller and console is blocked, check each joints between the connection between lower...
- Page 13 Over current protection: Possible Cause: In working , the lower Overloading leads to excessive current, and the system stops out controller detects of self-protection, or some part is stuck, causing the motor to current to be over 6A for stop. Adjust the treadmill and restart it. Check if there is liquid more than 3 seconds.
- Page 14 recommended that after your continued use of two hours, turn off the machine and let it rest for 10 minutes before using again. 2.If the treadmill belt is too loose, there will be skid phenomenons while running; if it’s too tight, it may reduces motor performance and harden the abrasion of roller and the running belt.
- Page 15 Lubrication of Running Belt The friction between the running belt and the running board has a significant impact on the service life and performance of the electric treadmill. The running belt of this treadmill adopts advanced automatic refueling technology, allowing you to release your hands and no longer worry about adding lubricating oil to the running belt too often.
