OPTIMUS BOATPORT

INSTALLATION GUIDE

Need help?

Do you have a question about the OPTIMUS BOATPORT and is the answer not in the manual?

Page 2 EZ DOCK - OPTIMUS BOATPORT INSTALLATION GUIDE 80510SS 80514SS 80528SS 104015 110031 117003 117004 117005 117012 BPKIT1 (no clip) BPKIT2 (no clip) Bunk w/ Rollers S20815 S20817 S20818 S20825 S20826 SP1347800 SP1835400 © 2023 EZ Dock, Inc. All rights reserved.
Page 3 EZ DOCK - OPTIMUS BOATPORT INSTALLATION GUIDE S20818 place under and into opening on end of BP208120ENT (Entry). Line up same opening on BP208120EXT (Extension) (Fig.1), slightly lift up and place S20818 into opening (Fig.2). Fig.1 Fig.2 © 2023 EZ Dock, Inc. All rights reserved.
Page 4 EZ DOCK - OPTIMUS BOATPORT INSTALLATION GUIDE Fig.3 Place S20817 on top (Fig.3), use 104015- Bolt 5/16-18 x1-1/2”, SP1835400 washer, and 117004 lock washer, tighten hardware together at 10 ft.lbs. of torque using ½” socket with long extension (4 places).
Page 5 EZ DOCK - OPTIMUS BOATPORT INSTALLATION GUIDE Installing clips and rollers. Install S20821 in the 2 space across from each other using 80510SS Bolt 5/16-18 x 1” in each area that a roller will go (Fig.5). Fig.6 shows rollers going into place and (Fig.7) all rollers in place.
Page 6 Fig.9 - MAX WIDTH Fig.10 - MIN WIDTH US/Canada 1-800-654-8168 EZ Dock, Inc | 878 HWY 60, Monett, MO 65708 417-235-2223 | 800-654-8168 Europe +46 (0) 380 47 300 © 2023 EZ Dock, Inc. All rights reserved. International +1 888-654-8168...
