LG UltraFine 32UQ750-W.AUS Owner's Manual

LG UltraFine 32UQ750-W.AUS Owner's Manual

Led lcd monitor
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and
retain it for future reference.
32UQ750
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.

Advertisement

loading

Related Manuals for LG UltraFine 32UQ750-W.AUS

Summary of Contents for LG UltraFine 32UQ750-W.AUS

  • Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32UQ750 www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered OPEN SOURCE SOFTWARE NOTICE trademarks of HDMI Licensing Administrator, Inc.

  • Page 3: Open Source Software Notice

    The power cord provided may differ depending upon the region. other relevant documents, please visit https://opensource.lge.com. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Supported Drivers and Software such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
  • Page 4 Product and Button Description Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. •...
  • Page 5 Installing on a Table Adjusting the Stand Height • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm (3.94 Place the monitor mounted on the stand base in an upright position. inches) away from the wall to ensure sufficient ventilation.
  • Page 6 Pivot Feature NOTE • The left or right side of the monitor head can be slightly rotated up or down (up to 3°). Adjust the horizontal The pivot feature allows the monitor to rotate 90° clockwise. level of the monitor head. Monitor head Head Stand...
  • Page 7 Using the Kensington Lock Rotate the monitor clockwise as shown in the figure. The connector for the Kensington security system is located at the bottom of the monitor. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website at http://www.kensington.com.
  • Page 8 NOTE tilting wall mounting bracket. • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. • The wall mount kit includes the installation guide and all necessary parts.
  • Page 9 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this way will not be covered by the product warranty.

  • Page 10: Using The Monitor

    USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NOTE Press the joystick button, go to [Settings] [Input], and then select the input option. •...
  • Page 11 Connecting AV Devices CAUTION Cautions When Using a USB Device HDMI Connection • A USB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. HDMI transmits digital video and audio signals from your AV device to the monitor. •...

  • Page 12: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • When [Beep Guide] is activated, pressing the joystick button will take you to [Settings] right away. Activating the Main Menu Press the joystick button on the bottom of the monitor.
  • Page 13 Main Menu Features Main Menu Description [Input] Sets input mode. Power Off [Power Off] Turns off the monitor. [Settings] Configures the screen settings. Settings Input Exit [Picture Mode] Sets the picture mode. [Exit] Exits the main menu. Picture Mode Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings].
  • Page 14 Quick Settings [Settings] > [Quick Settings] Description [Brightness] Adjusts the contrast and brightness of the screen. [Contrast] [Volume] Adjusts the volume level. NOTE • You can adjust [Mute] / [Unmute] by moving the joystick button to in the [Volume] menu. [Color Temp] [Custom] The user can adjust it to red, green, or blue by customization.
  • Page 15 Picture NOTE • The [Picture Mode] that can be set depends on the Input signal. [[Picture Mode] on SDR (Non HDR) signal] [Settings] > [Picture] Description [Picture Mode] [Custom] Allows the user to adjust each element. [Vivid] Heightens contrast, brightness and sharpness to display vivid images. [HDR Effect] Optimizes the screen for high dynamic range.
  • Page 16 [[Picture Mode] on HDR signal] [Settings] > [Picture] Description [Picture Mode] [Custom] Allows the user to adjust each element. [Vivid] Optimized the screen for HDR vivid colors. [Cinema] Optimized the screen for HDR video. [FPS] This mode is optimized for FPS games.It is suitable for very dark FPS games. [RTS] This mode is optimized for RTS Game.
  • Page 17 [Settings] > [Picture] Description [Picture Adjust] [Brightness] Adjusts the color contrast and brightness of the screen. [Contrast] [Sharpness] Adjusts the sharpness of the screen. [SUPER RESOLUTION+] [High] Optimizes the screen for crystal clear images. Best for high-definition video or games. [Middle] Optimizes the screen for comfortable viewing, with images at the middle level between the low and high modes.
  • Page 18 [Settings] > [Picture] Description [Game Adjust] [Response Time] Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is recommended that you use [Faster]. Setting to [Faster] may cause image sticking.
  • Page 19 [Settings] > [Picture] Description [Color Adjust] [Gamma] [Mode 1], [Mode 2], The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes. [Mode 3] [Mode 4] If you do not need to adjust the gamma settings, select [Mode 4]. [Color Temp] Set your own color temperature.
  • Page 20 Sound [Settings] > [Sound] Description [Volume] To adjust the Volume of headphone or speaker. [MaxxAudio] [On] MaxxAudio® by Waves, recipient of a Technical GRAMMY Award® is a suite of studio-quality sound tools for a superior listening experience. [Off] Disables the MaxxAudio function.
  • Page 21 General [Settings] > [General] Description [Language] Sets the menu screen to the desired language. [SMART ENERGY SAVING] Conserve energy by using luminance compensation algorithm. [High] Saves energy using the high-efficiency [SMART ENERGY SAVING] feature. [Low] Saves energy using the low-efficiency [SMART ENERGY SAVING] feature. [Off] Disables the feature.
  • Page 22 [Settings] > [General] Description [Input Compatibility Version] Please set the Input Compatibility Version to match the version of the connected external device. [HDMI] 2.1(PC)/2.1(AV)/1.4 If you want to use the HDR, select the Input Compatibility Version to 2.1(PC) or 2.1(AV). [DisplayPort] 1.4(DSC)/1.4/1.2 If you want to use the HDR, select the Input Compatibility Version to 1.4(DSC) or 1.4.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? Check the power cable connection and press the power button. •...
  • Page 24 Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message? • Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.

  • Page 25: Product Specification

    PRODUCT SPECIFICATION Color Depth 8-bit/10-bit color is supported. Resolution Max Resolution 3840 x 2160 @ 144 Hz (HDMI / DP) 3840 x 2160 @ 60 Hz (USB-C) Recommended Resolution 3840 x 2160 @ 144 Hz (HDMI / DP) 3840 x 2160 @ 60 Hz (USB-C) Power Sources Power Rating 19.5 V...
  • Page 26 Factory Support Mode (Preset Mode, PC) USB-C/DisplayPort Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 66.59 59.93 USB-C 1920 x 1080 67.5 DisplayPort 1920 x 1080...
  • Page 27 HDMI Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 1920 x 1080 166.587 143.98 2560 x 1440 182.996 2560 x 1440 222.151 143.97 3840 x 2160...
  • Page 28 HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 576P 31.25 720P 37.5 720P 1080P 1080P 33.75 1080P 56.25 1080P 67.5 1080P 2160P 2160P 56.25 2160P 67.5 2160P 112.5 2160p 2160P...
  • Page 29 Beep Guide Menu Location Menu Location Menu Location Quick Settings Picture Picture - Picture Adjust - Black Level - High 3 2 5 1 Quick Settings - Brightness Picture - Picture Mode Picture - Picture Adjust - Black Level - Low 3 2 5 2 Quick Settings - Brightness 1 1 1 Slider...
  • Page 30 Menu Location Menu Location Menu Location Picture - Color Adjust - Color Temp - Cool 3 4 2 4 Picture - Color Adjust - Six Color - Cyan_Hue 3 4 6 7 General - Language - French 5 1 3 3 4 6 7 1 Picture - Color Adjust - Color Temp - Manual 3 4 2 5...
  • Page 31 Menu Location General - Input Compatibility Version General - Input Compatibility Version - 1.4(DSC) / 5 6 1 2.1(PC) General - Input Compatibility Version - 1.4 / 2.1(AV) 5 6 2 General - Input Compatibility Version - 1.2 / 1.4 5 6 3 General - Buzzer 5 7 Toggle...
  • Page 32 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com The model and serial number of the product are located on the back and on one side of the product.
