Domus TWIN-SPOT-EM Installation Manual

TWIN-SPOT-EM
Specifications
Voltage: 240V
Power: 2.5/5W
IP Rating: IP65
Frequency: 60Hz
1
Use the screws to lock the brackets on the
back cover.
4
Thread the water proof head into the side
hole and lock the waterproof head with
the waterproof head nut. Screw the Lamp
to the wall.
Note:
-The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product
Charge Time: 16/24Hrs
Emergency Time: 2/3Hrs
Operation: Non Maintained Operations Mounting:
Function: Manual Test Switch & LED
Indicator
2
Open the left or right side holes on
the bottom cover. (The holes should be
opened as much as required.)
5
Pave the power wire through the
waterproof head, connect according
to the terminal mark, then tighten with
waterproof nut.
Test Swift:
The TEST SWITCH is provided to simulate the main power failure. PRESS and HOLD
the test switch, the lamp will light ON in emergency mode. After releasing the TEST
SWITCH, the light will be back to normal and the light will be OFF.
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia
Phone: 02 9554 9600 | Fax: 02 9554 9433
enquiries@domuslighting.com.au | www.domuslighting.com.au
Working Temp:
Battery:
Unscrew the four screws on the front cover
and take it out.
Rescrew the surface cover back to the unit
with the 4 screws.
-Do not touch the lamp when in use
-Keep away from hot steam and corrosive gas
Installation Manual
Date: October 23, 2023 11:09 AM
0-40°C
LiFePO4
Wall Mounted
3
6
