- Page 1 TMBK Roof Top Tent CAREFULLY READ INSTRUCTIONS PRIOR TO THE FIRST USE OF THE TMBK ROOF TOP TENT FEBRUARY 2024...
-
Page 2: Getting Started
TENT ORIENTATION ON YOUR VEHICLE There are two mounting options for the orientation of your new Overland Vehicle Systems Tent. Either the tent will open so that the ladder extends off the back of your vehicle, "Rear Mounted," or the ladder extends off the side of your vehicle, "Side Mounted."... -
Page 3: Tent Assembly
TMBK Roof Top Tent 18119933 TMBK 3 Roof Top Tent with Green Rain Fly SET-UP & CARE INSTRUCTIONS TENT ASSEMBLY Four pre-drilled holes are in the center area of the tent base for attaching the mounting tracks. Align the holes in the monting tracks over the holes in the base. - Page 4 TMBK Roof Top Tent 18119933 TMBK 3 Roof Top Tent with Green Rain Fly SET-UP & CARE INSTRUCTIONS TENT ASSEMBLY The mounting extrusion fitted to the base of the tent with slide plate and bolt fitted. 6mm stainless steel bolt...
- Page 5 TMBK Roof Top Tent 18119933 TMBK 3 Roof Top Tent with Green Rain Fly SET-UP & CARE INSTRUCTIONS COVER ATTATCHMENT To attach the travel cover, slide the round- ed fabric end of the ocver into the rounded C-Channel at the hinge side of the tent base.
- Page 6 TMBK Roof Top Tent 18119933 TMBK 3 Roof Top Tent with Green Rain Fly SET-UP & CARE INSTRUCTIONS ATTACHMENT TO THE ROOF RACK Place the tent on top of your vehicle rack sys- tem, ensuring the mounting tracks are perpen- dicular to the bars they will mount to, and the tent is centered on the roof rack.
-
Page 7: Tent Set Up
TMBK Roof Top Tent 18119933 TMBK 3 Roof Top Tent with Green Rain Fly SET-UP & CARE INSTRUCTIONS TENT SET UP Release the straps over the travel cover Unzip the travel cover. You can remove it, roll it up, or let it hang off the side of your vehicle... - Page 8 1. Open the tent fully and brush / vacuum inside. 2. Clean the fabric as needed using a mild detergent, warm • THE TMBK ROOF TOP TENT HAS BEEN DE- water, and a soft to medium brush. Rinse fabric of all detergent SIGNED FOR GENERAL CAMPING USE UNDER prior to drying.
